| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ECA-1JM100CAP ALUM 10UF 20% 63V RADIAL |
17,781 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 10 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 70 mA @ 120 Hz | 119 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
ECA-1JM330CAP ALUM 33UF 20% 63V RADIAL |
3,065 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 33 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 221 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
ECE-A1VKS100CAP ALUM 10UF 20% 35V RADIAL |
15,994 | 0.32 |
RFQ |
Datasheet |
Bulk | KS | Active | 10 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 30 mA @ 120 Hz | 51 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.197 (5.00mm) | - | Through Hole |
|
|
ECA-1CM101CAP ALUM 100UF 20% 16V RADIAL |
7,544 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 100 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 180 mA @ 120 Hz | 306 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECA-1AM331CAP ALUM 330UF 20% 10V RADIAL |
13,526 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 330 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 330 mA @ 120 Hz | 561 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
|
ECA-1VM470CAP ALUM 47UF 20% 35V RADIAL |
26,139 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 47 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 221 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECA-1HM330CAP ALUM 33UF 20% 50V RADIAL |
7,314 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 33 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 110 mA @ 120 Hz | 187 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECE-A1EKS100CAP ALUM 10UF 20% 25V RADIAL |
10,478 | 0.32 |
RFQ |
Datasheet |
Bulk | KS | Active | 10 µF | ±20% | 25 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 28 mA @ 120 Hz | 47.6 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.197 (5.00mm) | - | Through Hole |
|
|
ECE-A1CKS220CAP ALUM 22UF 20% 16V RADIAL |
3,361 | 0.32 |
RFQ |
Datasheet |
Bulk | KS | Active | 22 µF | ±20% | 16 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 39 mA @ 120 Hz | 66.3 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.197 (5.00mm) | - | Through Hole |
|
|
ECA-1HM220CAP ALUM 22UF 20% 50V RADIAL |
15,619 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 22 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 100 mA @ 120 Hz | 170 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECA-1AM221CAP ALUM 220UF 20% 10V RADIAL |
1,992 | 0.32 |
RFQ |
Datasheet |
Bulk | M-A | Active | 220 µF | ±20% | 10 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | 425 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
|
ECE-A1HKS4R7CAP ALUM 4.7UF 20% 50V RADIAL |
4,410 | 0.32 |
RFQ |
Datasheet |
Bulk | KS | Active | 4.7 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 23 mA @ 120 Hz | 39.1 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.197 (5.00mm) | - | Through Hole |
|
|
ECE-A1AKS220CAP ALUM 22UF 20% 10V RADIAL |
163 | 0.32 |
RFQ |
Datasheet |
Bulk | KS | Active | 22 µF | ±20% | 10 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.197 (5.00mm) | - | Through Hole |
|
EEU-FR1H101BCAP ALUM 100UF 20% 50V RADIAL |
9,618 | 0.66 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 100 µF | ±20% | 50 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 609 mA @ 120 Hz | 870 mA @ 100 kHz | 61 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
|
ECA-2AM4R7CAP ALUM 4.7UF 20% 100V RADIAL |
55,813 | 0.33 |
RFQ |
Datasheet |
Bulk | M-A | Active | 4.7 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
ECA-1HHG100CAP ALUM 10UF 20% 50V RADIAL |
21,729 | 0.33 |
RFQ |
Datasheet |
Bulk | NHG-A | Active | 10 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 39 mA @ 120 Hz | 78 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECA-1EHG470CAP ALUM 47UF 20% 25V RADIAL |
25,390 | 0.33 |
RFQ |
Datasheet |
Bulk | NHG-A | Active | 47 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 91 mA @ 120 Hz | 136.5 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
ECE-A1HKA4R7CAP ALUM 4.7UF 20% 50V RADIAL |
24,232 | 0.33 |
RFQ |
Datasheet |
Bulk | KA | Active | 4.7 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 23 mA @ 120 Hz | 39.1 mA @ 10 kHz | - | 0.059 (1.50mm) | 0.157 Dia (4.00mm) | 0.276 (7.00mm) | - | Through Hole |
|
ECE-A1VKA4R7CAP ALUM 4.7UF 20% 35V RADIAL |
10,320 | 0.33 |
RFQ |
Datasheet |
Bulk | KA | Active | 4.7 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | 37.4 mA @ 10 kHz | - | 0.059 (1.50mm) | 0.157 Dia (4.00mm) | 0.276 (7.00mm) | - | Through Hole |
|
|
ECA-1VHG470CAP ALUM 47UF 20% 35V RADIAL |
17,203 | 0.33 |
RFQ |
Datasheet |
Bulk | NHG-A | Active | 47 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 90 mA @ 120 Hz | 135 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
