| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-FN1E681UVCAP ALUM 680UF 20% 25V SMD |
475 | 1.76 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 680 µF | ±20% | 25 V | 80mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 595 mA @ 120 Hz | 850 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
ECO-S2AP561BACAP ALUM 560UF 20% 100V SNAP |
884 | 2.09 |
RFQ |
Datasheet |
Bulk,Bulk | TS-UP | Obsolete | 560 µF | ±20% | 100 V | 385mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.32 A @ 120 Hz | 1.518 A @ 100 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 0.984 (25.00mm) | - | Through Hole |
|
EEE-FK1K151AVCAP ALUM 150UF 20% 80V SMD |
3,308 | 2.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK, Anti-Vibration | Active | 150 µF | ±20% | 80 V | 320mOhm @ 100kHz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 375 mA @ 120 Hz | 500 mA @ 100 kHz | - | - | 0.492 Dia (12.50mm) | 0.555 (14.10mm) | 0.531 L x 0.531 W (13.50mm x 13.50mm) | Surface Mount |
|
EEV-FK1A682MCAP ALUM 6800UF 20% 10V SMD |
3,284 | 2.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK | Active | 6800 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.545 A @ 120 Hz | 2 A @ 100 kHz | 33 mOhms | - | 0.709 Dia (18.00mm) | 0.669 (17.00mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
|
EEV-FK1K471MCAP ALUM 470UF 20% 80V SMD |
20,503 | 2.59 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK | Active | 470 µF | ±20% | 80 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 687.8 mA @ 120 Hz | 917 mA @ 100 kHz | 153 mOhms | - | 0.709 Dia (18.00mm) | 0.669 (17.00mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
EEU-FS2A181BCAP ALUM 180UF 20% 100V RADIAL |
420 | 1.88 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 180 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.26 A @ 120 Hz | 1.8 A @ 100 kHz | 34 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEU-FS0J912BCAP ALUM 9100UF 20% 6.3V RADIAL |
249 | 2.66 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 9100 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.056 A @ 120 Hz | 3.82 A @ 100 kHz | 14 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEU-TP1E511BCAP ALUM 510UF 20% 25V RADIAL |
419 | 1.92 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | TP-A | Active | 510 µF | ±20% | 25 V | - | 3000 Hrs @ 125°C | -40°C ~ 135°C | Polar | AEC-Q200 | Automotive | 825 mA @ 120 Hz | 945 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.689 (17.50mm) | - | Through Hole |
|
|
EEU-TP1E331BCAP ALUM 330UF 20% 25V RADIAL |
380 | 1.92 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | TP-A | Active | 330 µF | ±20% | 25 V | - | 3000 Hrs @ 125°C | -40°C ~ 135°C | Polar | AEC-Q200 | Automotive | 715 mA @ 120 Hz | 945 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.689 (17.50mm) | - | Through Hole |
|
ECE-A1HN331UBCAP ALUM 330UF 20% 50V RADIAL |
248 | 1.96 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | SU | Active | 330 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 450 mA @ 120 Hz | 765 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEV-FK0J682VCAP ALUM 6800UF 20% 6.3V SMD |
318 | 2.74 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FK, Anti-Vibration | Active | 6800 µF | ±20% | 6.3 V | 35mOhm @ 100kHz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.673 (17.10mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
EEU-TA1C102BCAP ALUM 1000UF 20% 16V RADIAL |
499 | 2.12 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | TA | Active | 1000 µF | ±20% | 16 V | - | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 1.118 A @ 120 Hz | 1.49 A @ 100 kHz | 42 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.866 (22.00mm) | - | Through Hole |
|
ECO-S2DA101BACAP ALUM 100UF 20% 200V SNAP |
350 | 2.85 |
RFQ |
Datasheet |
Bulk | TS-HA | Obsolete | 100 µF | ±20% | 200 V | 1.658Ohm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 700 mA @ 100 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEE-FK1E272SMCAP ALUM 2700UF 20% 25V SMD |
152 | 2.86 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 2700 µF | ±20% | 25 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.669 (17.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
|
EEE-FK1C432SMCAP ALUM 4300UF 20% 16V SMD |
2,349 | 2.86 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 4300 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.669 (17.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
EEU-FC1C332SBCAP ALUM 3300UF 20% 16V RADIAL |
249 | 2.17 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 3300 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.117 A @ 120 Hz | 2.49 A @ 100 kHz | 28 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEU-FC1E222SBCAP ALUM 2200UF 20% 25V RADIAL |
234 | 2.17 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 2200 µF | ±20% | 25 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.992 A @ 120 Hz | 2.49 A @ 100 kHz | 28 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
ECA-1EHG332BCAP ALUM 3300UF 20% 25V RADIAL |
146 | 2.17 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | NHG-A | Active | 3300 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.4 A @ 120 Hz | 1.61 A @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
EET-HC2C561BACAP ALUM 560UF 20% 160V SNAP |
3,167 | 2.95 |
RFQ |
Datasheet |
Bulk | TS-HC | Obsolete | 560 µF | ±20% | 160 V | 355mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.5 A @ 120 Hz | 2.1 A @ 10 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
EEV-TG1H681UMCAP ALUM 680UF 20% 50V SMD |
340 | 3.03 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TG | Active | 680 µF | ±20% | 50 V | 150mOhm @ 100kHz | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 585 mA @ 120 Hz | 900 mA @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.650 (16.50mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
