| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-FK0J271SVCAP ALUM 270UF 20% 6.3V SMD |
928 | 1.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FKS, Anti-Vibration | Active | 270 µF | ±20% | 6.3 V | 360mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 156 mA @ 120 Hz | 240 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.252 (6.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEE-FP1C680AVCAP ALUM 68UF 20% 16V SMD |
332 | 1.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FP, Anti-Vibration | Active | 68 µF | ±20% | 16 V | 260mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 195 mA @ 120 Hz | 300 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.252 (6.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEU-FR1A152LBCAP ALUM 1500UF 20% 10V RADIAL |
551 | 0.88 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 1500 µF | ±20% | 10 V | - | 9000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.248 A @ 120 Hz | 1.56 A @ 100 kHz | 30 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
EEE-0JA471UAPCAP ALUM 470UF 20% 6.3V SMD |
348 | 0.88 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Active | 470 µF | ±20% | 6.3 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 380 mA @ 120 Hz | 646 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FKA331XSVCAP ALUM 330UF 20% 10V SMD |
2,643 | 1.31 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FKS, Anti-Vibration | Active | 330 µF | ±20% | 10 V | 340mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 182 mA @ 120 Hz | 280 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.327 (8.30mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEE-FPJ331XAVCAP ALUM 330UF 20% 6.3V SMD |
680 | 1.31 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FP, Anti-Vibration | Active | 330 µF | ±20% | 6.3 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.327 (8.30mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEU-FR1C681BCAP ALUM 680UF 20% 16V RADIAL |
140 | 0.88 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 680 µF | ±20% | 16 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 967.5 mA @ 120 Hz | 1.29 A @ 100 kHz | 43 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
EEU-EB2W100BCAP ALUM 10UF 20% 450V RADIAL |
168 | 1.34 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | EB-A | Active | 10 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 155 mA @ 120 Hz | 310 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.866 (22.00mm) | - | Through Hole |
|
EEU-HD1E101BCAP ALUM 100UF 20% 25V RADIAL |
948 | 0.91 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | HD | Active | 100 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 195 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.500 (12.70mm) | - | Through Hole |
|
EEE-HD1V330APCAP ALUM 33UF 20% 35V SMD |
866 | 0.91 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HD | Active | 33 µF | ±20% | 35 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 53 mA @ 120 Hz | 90.1 mA @ 10 kHz | 2 Ohms | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEU-FR1V271BCAP ALUM 270UF 20% 35V RADIAL |
419 | 0.91 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 270 µF | ±20% | 35 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 903 mA @ 120 Hz | 1.29 A @ 100 kHz | 43 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
|
EEU-HD1H680BCAP ALUM 68UF 20% 50V RADIAL |
333 | 0.91 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | HD | Active | 68 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 110 mA @ 120 Hz | 165 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.500 (12.70mm) | - | Through Hole |
|
EEU-FM1A332BCAP ALUM 3300UF 20% 10V RADIAL |
326 | 1.36 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FM-A | Active | 3300 µF | ±20% | 10 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.552 A @ 120 Hz | 3.19 A @ 100 kHz | 15 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEU-FS1J121LBCAP ALUM 120UF 20% 63V RADIAL |
976 | 0.94 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 120 µF | ±20% | 63 V | - | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 518.7 mA @ 120 Hz | 741 mA @ 100 kHz | 68 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.610 (15.50mm) | - | Through Hole |
|
EEE-FP1E101AVCAP ALUM 100UF 20% 25V SMD |
6,633 | 1.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FP, Anti-Vibration | Active | 100 µF | ±20% | 25 V | 180mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 325 mA @ 120 Hz | 500 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.268 (6.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEU-EB1H331BCAP ALUM 330UF 20% 50V RADIAL |
496 | 0.96 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | EB-A | Active | 330 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 293 mA @ 120 Hz | 380.9 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEU-EB1C102BCAP ALUM 1000UF 20% 16V RADIAL |
494 | 0.96 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | EB-A | Active | 1000 µF | ±20% | 16 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 430 mA @ 120 Hz | 494.5 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
EEE-FTJ681XAPCAP ALUM 680UF 20% 6.3V SMD |
574 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FT | Active | 680 µF | ±20% | 6.3 V | 160 mohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 420 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEU-FS2A470BCAP ALUM 47UF 20% 100V RADIAL |
435 | 1.01 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 47 µF | ±20% | 100 V | - | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 420 mA @ 120 Hz | 600 mA @ 100 kHz | 112 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
EEU-ED2E220BCAP ALUM 22UF 20% 250V RADIAL |
495 | 1.02 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ED-A | Active | 22 µF | ±20% | 250 V | - | 8000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 224 mA @ 120 Hz | 560 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.866 (22.00mm) | - | Through Hole |
