| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEU-ED2W330CAP ALUM 33UF 20% 450V RADIAL |
1,462 | 3.06 |
RFQ |
Datasheet |
Bulk | ED-A | Active | 33 µF | ±20% | 450 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 340 mA @ 120 Hz | 850 mA @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.240 (31.50mm) | - | Through Hole |
|
EEV-EB2D680MCAP ALUM 68UF 20% 200V SMD |
446 | 4.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EB | Last Time Buy | 68 µF | ±20% | 200 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 412.5 mA @ 120 Hz | 750 mA @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
ECA-1CHG103CAP ALUM 10000UF 20% 16V RADIAL |
206 | 3.35 |
RFQ |
Datasheet |
Bulk | NHG-A | Active | 10000 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 2.06 A @ 120 Hz | 2.369 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
EEU-FC0J153CAP ALUM 15000UF 20% 6.3V RADIAL |
180 | 3.32 |
RFQ |
Datasheet |
Bulk | FC | Active | 15000 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 3.128 A @ 120 Hz | 3.68 A @ 100 kHz | 15 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.398 (35.50mm) | - | Through Hole |
|
EEU-EE2V820SCAP ALUM 82UF 20% 350V RADIAL |
200 | 3.36 |
RFQ |
Datasheet |
Bulk | EE-A | Active | 82 µF | ±20% | 350 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 535.5 mA @ 120 Hz | 1.53 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
EEU-EE2V680SCAP ALUM 68UF 20% 350V RADIAL |
2,255 | 3.36 |
RFQ |
Datasheet |
Bulk | EE-A | Active | 68 µF | ±20% | 350 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 465.5 mA @ 120 Hz | 1.33 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
ECA-2CHG331CAP ALUM 330UF 20% 160V RADIAL |
120 | 3.81 |
RFQ |
Datasheet |
Bulk | NHG-A | Active | 330 µF | ±20% | 160 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 705 mA @ 120 Hz | 1.058 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.319 (33.50mm) | - | Through Hole |
|
EEU-FC1V392CAP ALUM 3900UF 20% 35V RADIAL |
500 | 3.95 |
RFQ |
Datasheet |
Bulk | FC | Active | 3900 µF | ±20% | 35 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 3.175 A @ 120 Hz | 3.735 A @ 100 kHz | 14 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.575 (40.00mm) | - | Through Hole |
|
EEU-ED2W470CAP ALUM 47UF 20% 450V RADIAL |
583 | 4.54 |
RFQ |
Datasheet |
Bulk | ED-A | Active | 47 µF | ±20% | 450 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 400 mA @ 120 Hz | 1 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.240 (31.50mm) | - | Through Hole |
|
EEE-HA1E101APCAP ALUM 100UF 20% 25V SMD |
840 | 0.83 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HA | Not For New Designs | 100 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 130 mA @ 120 Hz | 221 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEE-FN0J271UVCAP ALUM 270UF 20% 6.3V SMD |
1,000 | 1.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 270 µF | ±20% | 6.3 V | 360mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 156 mA @ 120 Hz | 240 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.252 (6.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEU-HD1H330CAP ALUM 33UF 20% 50V RADIAL |
378 | 0.65 |
RFQ |
Datasheet |
Bulk | HD | Active | 33 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 90 mA @ 120 Hz | 180 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EEU-HD1H3R3CAP ALUM 3.3UF 20% 50V RADIAL |
305 | 0.65 |
RFQ |
Datasheet |
Bulk | HD | Active | 3.3 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 22 mA @ 120 Hz | 44 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EEE-FN1V151VCAP ALUM 150UF 20% 35V SMD |
500 | 1.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 150 µF | ±20% | 35 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN0J152VCAP ALUM 1.5UF 20% 6.3V SMD |
500 | 1.62 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 1.5 µF | ±20% | 6.3 V | 80mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 595 mA @ 120 Hz | 850 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEU-TP1V271BCAP ALUM 270UF 20% 35V RADIAL |
625 | 1.92 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | TP-A | Active | 270 µF | ±20% | 35 V | - | 3000 Hrs @ 125°C | -40°C ~ 135°C | Polar | AEC-Q200 | Automotive | 715 mA @ 120 Hz | 945 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.689 (17.50mm) | - | Through Hole |
|
EEU-HD1C221CAP ALUM 220UF 20% 16V RADIAL |
781 | 0.91 |
RFQ |
Datasheet |
Bulk | HD | Active | 220 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 180 mA @ 120 Hz | 270 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.500 (12.70mm) | - | Through Hole |
|
|
EEU-HD1A331CAP ALUM 330UF 20% 10V RADIAL |
378 | 0.91 |
RFQ |
Datasheet |
Bulk | HD | Active | 330 µF | ±20% | 10 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 200 mA @ 120 Hz | 300 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.500 (12.70mm) | - | Through Hole |
|
EEU-HD1A471CAP ALUM 470UF 20% 10V RADIAL |
643 | 1.05 |
RFQ |
Datasheet |
Bulk | HD | Active | 470 µF | ±20% | 10 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 250 mA @ 120 Hz | 375 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
EEU-FR0J822BCAP ALUM 8200UF 20% 6.3V RADIAL |
516 | 2.20 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 8200 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.056 A @ 120 Hz | 3.82 A @ 100 kHz | 14 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
