| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AUIRGSL30B60KAUIRGSL30B60K - AUTOMOTIVE IGBT |
2,195 | 2.17 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
IRG6B330UDPBFIRG6B330UD - IGBT WITH ANTI-PARA |
3,641 | 2.18 |
RFQ |
Datasheet |
Bulk | - | Obsolete | Trench | 330 V | 70 A | - | 2.76V @ 15V, 120A | 160 W | - | Standard | 85 nC | 47ns/176ns | 196V, 25A, 10Ohm | 60 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
IRG8P08N120KD-EPBFIRG8P08N120 - DISCRETE IGBT WITH |
3,018 | 2.35 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 15 A | 15 A | 2V @ 15V, 5A | 89 W | 300µJ (on), 300µJ (off) | Standard | 45 nC | 20ns/160ns | 600V, 5A, 47Ohm, 15V | 50 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
IRGS4062DTRLPBFIRGS4062 - INSULATED GATE BIPOLA |
2,771 | 2.56 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
IRG7PH35U-EPIRG7PH35 - DISCRETE IGBT WITHOUT |
3,907 | 2.80 |
RFQ |
Datasheet |
Bulk | - | Obsolete | Trench | 1200 V | 55 A | 60 A | 2.2V @ 15V, 20A | 210 W | 1.06mJ (on), 620µJ (off) | Standard | 130 nC | 30ns/160ns | 600V, 20A, 10Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRG8P15N120KD-EPBFIRG8P15N120 - DISCRETE IGBT WITH |
3,107 | 3.11 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 30 A | 30 A | 2V @ 15V, 10A | 125 W | 600µJ (on), 600µJ (off) | Standard | 98 nC | 15ns/170ns | 600V, 10A, 10Ohm, 15V | 60 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IRG8P75N65UD1-EPBFIRG8P75N65 - 650V 75A, IGBT |
3,815 | 3.50 |
RFQ |
Bulk | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
IRGP4072DPBFIRGP4072D - IGBT WITH ULTRAFAST |
3,751 | 3.64 |
RFQ |
Bulk | - | Obsolete | Trench | 300 V | 70 A | 120 A | 1.7V @ 15V, 40A | 180 W | 409µJ (on), 838µJ (off) | Standard | 73 nC | 18ns/144ns | 240V, 40A, 10Ohm, 15V | 122 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IRG8P25N120KD-EPBFIRG8P25N120 - DISCRETE IGBT WITH |
3,313 | 3.82 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 40 A | 45 A | 2V @ 15V, 15A | 180 W | 800µJ (on), 900µJ (off) | Standard | 135 nC | 20ns/170ns | 600V, 15A, 10Ohm, 15V | 70 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
IRG7PH35UD-EPIRG7PH35UD - IGBT WITH ANTI-PARA |
3,311 | 4.27 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
IRG8P45N65UD1PBFIRG8P45N65 - 65V, 45A IGBT |
2,617 | 4.32 |
RFQ |
Bulk | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
IRG8P45N65UD1-EPBFIRG8P45N65 - 650V 45A, IGBT |
3,150 | 4.48 |
RFQ |
Bulk | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
IRGP50B60PD1-EPIRGP50B60 - DISCRETE IGBT WITH A |
3,899 | 4.49 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPT | 600 V | 75 A | 150 A | 2.85V @ 15V, 50A | 390 W | 255µJ (on), 375µJ (off) | Standard | 205 nC | 30ns/130ns | 390V, 33A, 3.3Ohm, 15V | 42 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IRG8P40N120KDPBFIRG8P40N120 - DISCRETE IGBT WITH |
2,046 | 4.74 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 60 A | 75 A | 2V @ 15V, 25A | 305 W | 1.6mJ (on), 1.8mJ (off) | Standard | 240 nC | 40ns/245ns | 600V, 25A, 10Ohm, 15V | 80 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IRGP4690DPBFIRGP4690 - DISCRETE IGBT WITH AN |
2,532 | 5.57 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 600 V | 140 A | 225 A | 2.1V @ 15V, 75A | 454 W | 2.47mJ (on), 2.16mJ (off) | Standard | 150 nC | 50ns/200ns | 400V, 75A, 10Ohm, 15V | 155 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
AUIRGP4062D-EAUIRGP4062D-E - AUTOMOTIVE IGBT |
3,016 | 6.12 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 48 A | 72 A | 1.95V @ 15V, 24A | 250 W | 115µJ (on), 600µJ (off) | Standard | 50 nC | 41ns/104ns | 400V, 24A, 10Ohm, 15V | 89 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRG8P50N120KD-EPBFIRG8P50N120 - DISCRETE IGBT WITH |
3,515 | 6.50 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 80 A | 105 A | 2V @ 15V, 35A | 350 W | 2.3mJ (on), 1.9mJ (off) | Standard | 315 nC | 35ns/190ns | 600V, 35A, 5Ohm, 15V | 170 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IRGPS40B120UDPIRGPS40B120 - DISCRETE IGBT WITH |
112 | 6.54 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
IRG8P60N120KD-EPBFIRG8P60N120 - DISCRETE IGBT WITH |
2,524 | 6.91 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | 1200 V | 100 A | 120 A | 2V @ 15V, 40A | 420 W | 2.8mJ (on), 2.3mJ (off) | Standard | 345 nC | 40ns/240ns | 600V, 40A, 5Ohm, 15V | 210 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IRG7PSH50UDPBFIRG7PSH50 - DISCRETE IGBT WITH A |
2,075 | 7.71 |
RFQ |
Datasheet |
Bulk | - | Obsolete | Trench | 1200 V | 116 A | 150 A | 2V @ 15V, 50A | 462 W | 3.6mJ (on), 2.2mJ (off) | Standard | 440 nC | 35ns/430ns | 600V, 50A, 5Ohm, 15V | 190 ns | -55°C ~ 150°C (TJ) | Through Hole |
