| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HGTP14N44G3VLIGBT, 27A, 490V, N-CHANNEL |
3,412 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 490 V | 27 A | - | 1.9V @ 4.5V, 8A | 231 W | - | Logic | - | -/18µs | 300V, 7.5A, 1kOhm, 5V | - | -40°C ~ 175°C (TJ) | Through Hole |
|
HGTP5N120CNIGBT, 25A, 1200V, N-CHANNEL |
3,627 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 1200 V | 25 A | 40 A | 2.4V @ 15V, 5.5A | 167 W | 400µJ (on), 640µJ (off) | Standard | 75 nC | 22ns/180ns | 960V, 5.5A, 25Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
|
FGP90N30TUIGBT, 90A, 300V, N-CHANNEL |
2,795 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 300 V | 90 A | 130 A | 1.4V @ 15V, 20A | 192 W | - | Standard | 130 nC | - | - | - | -55°C ~ 150°C (TJ) | Through Hole |
|
FGL40N150DTUIGBT, 40A, 1500V, N-CHANNEL |
2,155 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 1500 V | 40 A | 120 A | 4.5V @ 15V, 40A | 200 W | - | Standard | 170 nC | - | - | 170 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SGL25N120RUFTUIGBT, 40A, 1200V, N-CHANNEL |
2,814 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 1200 V | 40 A | 75 A | 3V @ 15V, 25A | 270 W | 1.6mJ (on), 1.63mJ (off) | Standard | 165 nC | 30ns/70ns | 600V, 25A, 10Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
SGH20N120RUFDTUIGBT, 32A, 1200V, N-CHANNEL |
3,551 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 1200 V | 32 A | 60 A | 3V @ 15V, 20A | 230 W | 1.3mJ (on), 1.3mJ (off) | Standard | 140 nC | 30ns/70ns | 600V, 20A, 15Ohm, 15V | 80 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
FGD3440G2IGBT 26.9A, 450V, N CHANNEL, DPA |
3,016 | 1.00 |
RFQ |
Bulk | EcoSPARK® | Active | - | 400 V | 26.9 A | - | 1.2V @ 4V, 6A | 166 W | - | Logic | 24 nC | -/5.3µs | 300V, 6.5A, 1kOhm, 5V | - | -40°C ~ 175°C (TJ) | Surface Mount | |
|
FGI3040G2-F085IGBT, 41A, 390V, N-CHANNEL |
2,503 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, EcoSPARK® | Active | - | 400 V | 41 A | - | 1.25V @ 4V, 6A | 150 W | - | Logic | 21 nC | -/4.8µs | 300V, 6.5A, 1kOhm, 5V | 1.9 µs | -55°C ~ 175°C (TJ) | Through Hole |
|
FGA90N33ATDTUIGBT, 90A, 330V, N-CHANNEL |
3,406 | 1.00 |
RFQ |
Bulk | - | Active | Trench | 330 V | 90 A | 330 A | 1.4V @ 15V, 20A | 223 W | - | Standard | 95 nC | - | - | 23 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
HGTG12N60C3D24A, 600V, UFS SERIES N-CHANNEL |
2,725 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 24 A | 96 A | 2.2V @ 15V, 15A | 104 W | 380µJ (on), 900µJ (off) | Standard | 48 nC | - | - | 42 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
SGS23N60UFDTUIGBT, 23A I(C), 600V V(BR)CES, N |
3,139 | 1.00 |
RFQ |
Bulk | - | Active | - | 600 V | 23 A | 92 A | 2.6V @ 15V, 12A | 73 W | 115µJ (on), 135µJ (off) | Standard | 49 nC | 17ns/60ns | 300V, 12A, 23Ohm, 15V | 60 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
FGB3245G2ECOSPARK2 450V IGNITION IGBT |
3,542 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
FGH40T65SHD-F155IGBT, 80A, 650V, N-CHANNEL, TO-2 |
2,535 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | Trench Field Stop | 650 V | 80 A | 120 A | 2.1V @ 15V, 40A | 268 W | 1.01mJ (on), 297µJ (off) | Standard | 72.2 nC | 19.2ns/65.6ns | 400V, 40A, 6Ohm, 15V | 31.8 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
HGT1S10N120BNSIGBT, 35A, 1200V, N-CHANNEL, TO- |
3,413 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 1200 V | 35 A | 80 A | 2.7V @ 15V, 10A | 298 W | 320µJ (on), 800µJ (off) | Standard | 100 nC | 23ns/165ns | 960V, 10A, 10Ohm, 15V | - | -55°C ~ 150°C (TJ) | Surface Mount |
|
HGTG40N60B3-FS70A, 600V, UFS N-CHANNEL IGBT |
3,779 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
FGD3N60LSDTM-T-FSIGBT, 6A, 600V, N-CHANNEL |
2,494 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 600 V | 6 A | 25 A | 1.5V @ 10V, 3A | 40 W | 250µJ (on), 1mJ (off) | Standard | 12.5 nC | 40ns/600ns | 480V, 3A, 470Ohm, 10V | 234 ns | -55°C ~ 150°C (TJ) | Surface Mount |
|
HGT1S14N36G3VLT_NLIGBT, 18A, N-CHANNEL |
3,253 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 390 V | 18 A | - | 2.2V @ 5V, 14A | 100 W | - | Logic | 24 nC | -/7µs | 300V, 7A, 28Ohm, 5V | - | -40°C ~ 175°C (TJ) | Through Hole |
|
SGS5N150UFTUIGBT, 10A, 1500V, N-CHANNEL |
3,804 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | - | 1500 V | 10 A | 20 A | 5.5V @ 10V, 5A | 50 W | 190µJ (on), 100µJ (off) | Standard | 30 nC | 10ns/30ns | 600V, 5A, 10Ohm, 10V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
|
HGTG30N60B3_NLIGBT, 60A, 600V, N-CHANNEL |
2,477 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPT | 600 V | 60 A | 220 A | 1.9V @ 15V, 30A | 208 W | 550µJ (on), 680µJ (off) | Standard | 250 nC | 36ns/137ns | 480V, 60A, 3Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
|
FGA6540WDFINSULATED GATE BIPOLAR TRANSISTO |
3,718 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | Trench Field Stop | 650 V | 80 A | 120 A | 2.3V @ 15V, 40A | 238 W | 1.37mJ (on), 250µJ (off) | Standard | 55.5 nC | 16.8ns/54.4ns | 400V, 40A, 6Ohm, 15V | 101 ns | -55°C ~ 175°C (TJ) | Through Hole |
