| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
IXA12IF1200HBIGBT 1200V 20A 85W TO247 |
486 | 4.86 |
RFQ |
Datasheet |
Tube | - | Active | PT | 1200 V | 20 A | - | 2.1V @ 15V, 10A | 85 W | 1.1mJ (on), 1.1mJ (off) | Standard | 27 nC | - | 600V, 10A, 100Ohm, 15V | 350 ns | -40°C ~ 150°C (TJ) | Through Hole |
|
IXDH20N120IGBT 1200V 38A 200W TO247AD |
2,397 | 7.29 |
RFQ |
Datasheet |
Tube | - | Active | NPT | 1200 V | 38 A | 50 A | 3V @ 15V, 20A | 200 W | 3.1mJ (on), 2.4mJ (off) | Standard | 70 nC | - | 600V, 20A, 82Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXYH60N90C3IGBT 900V 140A 750W C3 TO-247 |
131 | 8.13 |
RFQ |
Datasheet |
Tube | GenX3™, XPT™ | Active | - | 900 V | 140 A | 310 A | 2.7V @ 15V, 60A | 750 W | 2.7mJ (on), 1.55mJ (off) | Standard | 107 nC | 30ns/87ns | 450V, 60A, 3Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXDH20N120D1IGBT 1200V 38A 200W TO247AD |
298 | 8.23 |
RFQ |
Datasheet |
Tube | - | Active | NPT | 1200 V | 38 A | 50 A | 3V @ 15V, 20A | 200 W | 3.1mJ (on), 2.4mJ (off) | Standard | 70 nC | - | 600V, 20A, 82Ohm, 15V | 40 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
IXYH16N170CV1IGBT 1.7KV 40A TO247 |
2,411 | 13.72 |
RFQ |
Datasheet |
Tube | XPT™ | Active | - | 1700 V | 40 A | 100 A | 3.8V @ 15V, 16A | 310 W | 2.1mJ (on), 1.5mJ (off) | Standard | 56 nC | 11ns/140ns | 850V, 16A, 10Ohm, 15V | 150 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXYH24N170CV1IGBT 1.7KV 58A TO247 |
721 | 16.68 |
RFQ |
Tube | XPT™ | Active | - | 1700 V | 58 A | 140 A | 4V @ 15V, 24A | 500 W | 3.6mJ (on), 1.76mJ (off) | Standard | 96 nC | 16ns/155ns | 850V, 24A, 5Ohm, 15V | 170 ns | -55°C ~ 175°C (TJ) | Through Hole | |
|
IXGR72N60B3H1IGBT 600V 75A 200W ISOPLUS247 |
2,731 | 21.74 |
RFQ |
Datasheet |
Tube | GenX3™ | Active | PT | 600 V | 75 A | 450 A | 1.8V @ 15V, 60A | 200 W | 1.4mJ (on), 1mJ (off) | Standard | 225 nC | 31ns/152ns | 480V, 50A, 3Ohm, 15V | 140 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXBH20N300IGBT 3000V 50A 250W TO247 |
126 | 42.68 |
RFQ |
Datasheet |
Tube | BIMOSFET™ | Active | - | 3000 V | 50 A | 140 A | 3.2V @ 15V, 20A | 250 W | - | Standard | 105 nC | - | - | 1.35 µs | -55°C ~ 150°C (TJ) | Through Hole |
|
IXYN30N170CV11700V/85A HIGH VOLTAGE XPT IGBT |
564 | 43.32 |
RFQ |
Datasheet |
Tube | XPT™ | Active | - | 1700 V | 88 A | 275 A | 3.7V @ 15V, 30A | 680 W | 5.9mJ (on), 3.3mJ (off) | Standard | 140 nC | 28ns/150ns | 850V, 30A, 2.7Ohm, 15V | 160 ns | -55°C ~ 175°C (TJ) | Chassis Mount |
|
IXYH24N170CIGBT 1.7KV 58A TO247-3 |
287 | 13.84 |
RFQ |
Datasheet |
Tube | XPT™ | Active | - | 1700 V | 58 A | 145 A | 3.8V @ 15V, 20A | 500 W | 4.9mJ (on), 1.95mJ (off) | Standard | 96 nC | 12ns/160ns | 960V, 30A, 15Ohm, 15V | 30 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXYH50N120C3IGBT 1200V 100A 750W TO247AD |
113 | 12.52 |
RFQ |
Datasheet |
Tube | GenX3™, XPT™ | Active | - | 1200 V | 100 A | 240 A | 3.5V @ 15V, 50A | 750 W | 3mJ (on), 1mJ (off) | Standard | 142 nC | 28ns/133ns | 600V, 50A, 5Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
IXYX110N120A4IGBT 1200V 110A GNX4 XPT PLUS247 |
3,737 | 37.22 |
RFQ |
Datasheet |
Tube | XPT™, GenX4™ | Active | PT | 1200 V | 375 A | 900 A | 1.8V @ 15V, 110A | 1360 W | 2.5mJ (on), 8.4mJ (off) | Standard | 305 nC | 42ns/550ns | 600V, 50A, 1.5Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
IXYK110N120A4IGBT 1200V 110A GENX4 XPT TO-264 |
2,119 | 37.22 |
RFQ |
Datasheet |
Tube | XPT™, GenX4™ | Active | PT | 1200 V | 375 A | 900 A | 1.8V @ 15V, 110A | 1360 W | 2.5mJ (on), 8.4mJ (off) | Standard | 305 nC | 42ns/550ns | 600V, 50A, 1.5Ohm, 15V | - | -55°C ~ 175°C (TJ) | Through Hole |
|
IXBT14N300HVREVERSE CONDUCTING IGBT |
2,025 | 45.96 |
RFQ |
Tube | BIMOSFET™ | Active | - | 3000 V | 38 A | 120 A | 2.7V @ 15V, 14A | 200 W | - | Standard | 62 nC | - | 960V, 14A, 20Ohm, 15V | 1.4 µs | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IXA70R1200NADISC IGBT XPT-GENX3 SOT-227B(MIN |
3,894 | 27.00 |
RFQ |
Tube | XPT™ | Active | PT | 1200 V | 100 A | - | 2.1V @ 15V, 50A | 350 W | 4.5mJ (on), 5.5mJ (off) | Standard | 190 nC | 70ns/250ns | 600V, 50A, 15Ohm, 15V | - | - | Chassis Mount | |
|
|
IXGH28N60B3D1IGBT 600V 66A 190W TO247AD |
143 | 7.98 |
RFQ |
Datasheet |
Tube | PolarHV™ | Active | PT | 600 V | 66 A | 150 A | 1.8V @ 15V, 24A | 190 W | 340µJ (on), 650µJ (off) | Standard | 62 nC | 19ns/125ns | 400V, 24A, 10Ohm, 15V | 25 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXGH24N120C3IGBT 1200V 48A 250W TO247 |
166 | 8.39 |
RFQ |
Datasheet |
Tube | GenX3™ | Active | PT | 1200 V | 48 A | 96 A | 4.2V @ 15V, 20A | 250 W | 1.16mJ (on), 470µJ (off) | Standard | 79 nC | 16ns/93ns | 600V, 20A, 5Ohm, 15V | - | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXGH48N60A3D1IGBT 600V 300W TO247AD |
254 | 9.50 |
RFQ |
Datasheet |
Tube | GenX3™ | Active | PT | 600 V | - | 300 A | 1.35V @ 15V, 32A | 300 W | 950µJ (on), 2.9mJ (off) | Standard | 110 nC | 25ns/334ns | 480V, 32A, 5Ohm, 15V | 25 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXYH50N65C3H1IGBT 650V 130A 600W TO247 |
227 | 11.16 |
RFQ |
Datasheet |
Tube | GenX3™, XPT™ | Active | PT | 650 V | 130 A | 250 A | 2.1V @ 15V, 36A | 600 W | 1.3mJ (on), 370µJ (off) | Standard | 80 nC | 22ns/80ns | 400V, 36A, 5Ohm, 15V | 120 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXXH80N65B4D1DISC IGBT XPT-GENX4 TO-247AD |
264 | 11.20 |
RFQ |
Tube | XPT™, GenX4™ | Active | PT | 650 V | 180 A | 430 A | 2.1V @ 15V, 80A | 625 W | 3.36mJ (on), 1.83mJ (off) | Standard | 120 nC | 26ns/112ns | 400V, 80A, 3Ohm, 15V | 100 ns | -55°C ~ 175°C (TJ) | Through Hole |
