| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Configuration | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Power-Max | Vce(on)(Max)@VgeIc | Current-CollectorCutoff(Max) | InputCapacitance(Cies)@Vce | Input | NTCThermistor | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FZ800R33KL2CNOSA1IGBT MOD 3300V 1500A 9800W |
3,967 | 1046.99 |
RFQ |
Datasheet |
Tray,Tray | - | Obsolete | - | - | 3300 V | 1500 A | 9800 W | 3.65V @ 15V, 800A | 5 mA | 97 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount |
|
|
FZ800R33KL2CB5NOSA1IGBT MOD 3300V 1500A 9800W |
3,118 | 0.00 |
RFQ |
Datasheet |
Tray | - | Obsolete | - | - | 3300 V | 1500 A | 9800 W | 3.65V @ 15V, 800A | 5 mA | 97 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount |
|
FA300R12ME4BOSA1MODULE IGBT ECONO DUAL 3 |
3,954 | 0.00 |
RFQ |
Datasheet |
Bulk | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
FP30R06YE3BOMA1MODULE IGBT CBI E2 |
3,391 | 0.00 |
RFQ |
Datasheet |
Tray | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
BSM50GB170DN2HOSA1IGBT MOD 1700V 72A 500W |
3,094 | 0.00 |
RFQ |
Datasheet |
Bulk,Tray | - | Obsolete | - | Half Bridge | 1700 V | 72 A | 500 W | 3.9V @ 15V, 50A | - | 8 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount |
|
|
BSM75GB170DN2HOSA1IGBT MOD 1700V 110A 625W |
642 | 93.33 |
RFQ |
Datasheet |
Bulk,Tray | - | Obsolete | - | Half Bridge | 1700 V | 110 A | 625 W | 3.9V @ 15V, 75A | - | 11 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount |
|
FP25R12KE3BOSA1IGBT MOD 1200V 40A 155W |
3,200 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Discontinued at Mosen | Trench Field Stop | Three Phase Inverter | 1200 V | 40 A | 155 W | 2.15V @ 15V, 25A | 1 mA | 1.8 nF @ 25 V | Standard | Yes | -40°C ~ 125°C (TJ) | Chassis Mount |
|
DDB6U134N16RRBOSA1IGBT MOD 1600V 70A 500W |
2,113 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Discontinued at Mosen | NPT | Single | 1600 V | 70 A | 500 W | 2.75V @ 15V, 70A | 500 µA | 5.1 nF @ 25 V | Standard | Yes | 150°C (TJ) | Chassis Mount |
|
|
BSM35GP120BOSA1IGBT MOD 1200V 45A 230W |
2,963 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Discontinued at Mosen | NPT | Three Phase Inverter | 1200 V | 45 A | 230 W | - | 500 µA | 1.5 nF @ 25 V | - | Yes | 150°C (TJ) | Surface Mount |
|
FP50R12KT4B11BOSA1IGBT MOD 1200V 50A 280W |
2,477 | 1.00 |
RFQ |
Datasheet |
Bulk,Bulk | EconoPIM™ 2 | Discontinued at Mosen | Trench Field Stop | Three Phase Inverter | 1200 V | 50 A | 280 W | 2.15V @ 15V, 50A | 1 mA | 2.8 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
DDB6U84N16RRBOSA1IGBT MOD 1200V 50A 350W |
3,494 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Discontinued at Mosen | NPT | Single Chopper | 1200 V | 50 A | 350 W | 3.2V @ 20V, 50A | 1 mA | 3.3 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount |
|
|
BSM50GD120DN2GIGBT MOD 1200V 78A 400W |
2,040 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | Full Bridge | 1200 V | 78 A | 400 W | 3.7V @ 15V, 50A | - | 33 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount |
|
|
DDB6U180N16RRIGBT MOD 1200V 140A 515W |
3,719 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | Trench Field Stop | Dual Brake Chopper | 1200 V | 140 A | 515 W | 2.2V @ 15V, 100A | 1 mA | 6.3 nF @ 25 V | Standard | No | 150°C (TJ) | Surface Mount |
|
|
DF400R07PE4R_B6IGBT MOD 650V 450A 1100W |
2,473 | 0.00 |
RFQ |
Datasheet |
Bulk | EconoPACK™ 4 | Obsolete | NPT | Single Chopper | 650 V | 450 A | 1100 W | 1.95V @ 15V, 400A | 20 nA | 18.5 nF @ 25 V | Standard | Yes | 150°C (TJ) | Chassis Mount |
|
F1235R12KT4GBOSA1IGBT MOD 1200V 35A 210W |
3,210 | 1.00 |
RFQ |
Datasheet |
Bulk,Bulk | - | Obsolete | Trench Field Stop | Single | 1200 V | 35 A | 210 W | 2.15V @ 15V, 35A | 1 mA | 2 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount |
|
|
FS100R12KE3_B3IGBT MOD 1200V 140A 480W |
2,632 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPT | Three Phase Inverter | 1200 V | 140 A | 480 W | 2.15V @ 15V, 100A | 5 mA | 7.1 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount |
|
|
FS75R12KE3_B3IGBT MOD 1200V 100A 355W |
3,529 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPT | Three Phase Inverter | 1200 V | 100 A | 355 W | 2.15V @ 15V, 75A | 5 mA | 5.3 nF @ 25 V | Standard | Yes | 150°C (TJ) | Chassis Mount |
|
|
FT150R12KE3G_B4IGBT MOD 1200V 200A 700W |
3,749 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | - | Three Phase Inverter | 1200 V | 200 A | 700 W | 2.15V @ 15V, 150A | 5 mA | 10.5 nF @ 25 V | Standard | Yes | 150°C (TJ) | Chassis Mount |
|
|
IFS100B12N3E4_B39IGBT MOD 1200V 100A 515W |
2,157 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | Trench Field Stop | Three Phase Inverter | 1200 V | 100 A | 515 W | 2.1V @ 15V, 100A | 1 mA | 6.3 nF @ 25 V | Standard | Yes | 175°C (TJ) | Chassis Mount |
|
DDB6U180N16RRB37BOSA1IGBT MODULE |
3,540 | 0.00 |
RFQ |
Datasheet |
Tray | - | Discontinued at Mosen | - | - | - | - | - | - | - | - | - | - | - | Surface Mount |
