| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Configuration | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Power-Max | Vce(on)(Max)@VgeIc | Current-CollectorCutoff(Max) | InputCapacitance(Cies)@Vce | Input | NTCThermistor | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FS660R08A6P2FBBPSA1HYBRID PACK DRIVE |
2,997 | 546.00 |
RFQ |
Datasheet |
Tray | HybridPACK™ | Active | Trench Field Stop | Three Phase Inverter | 750 V | 450 A | 1053 W | 1.35V @ 15V, 450A | 1 mA | 80 nF @ 50 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
FS660R08A6P2FLBBPSA1HYBRID PACK DRIVE |
2,046 | 556.50 |
RFQ |
Datasheet |
Tray | HybridPACK™ | Active | Trench Field Stop | Three Phase Inverter | 750 V | 450 A | 1053 W | 1.35V @ 15V, 450A | 1 mA | 80 nF @ 50 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
FS300R12KE4BOSA1IGBT MOD 1200V 450A 1600W |
2,316 | 504.22 |
RFQ |
Datasheet |
Bulk,Tray | EconoPACK™+ B | Not For New Designs | Trench Field Stop | Three Phase Inverter | 1200 V | 450 A | 1600 W | 2.1V @ 15V, 300A | 3 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
FF900R12IE4PBOSA1IGBT MOD 1200V 900A 20MW |
3,237 | 664.71 |
RFQ |
Datasheet |
Tray | PrimePACK™2 | Active | Trench Field Stop | Half Bridge | 1200 V | 900 A | 20 mW | 2.1V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF600R12IE4VBOSA1IGBT MOD 1200V 600A 3350W |
2,524 | 573.64 |
RFQ |
Datasheet |
Bulk | PrimePACK™2 | Not For New Designs | Trench Field Stop | 2 Independent | 1200 V | 600 A | 3350 W | 2.05V @ 15V, 600A | 5 mA | 37 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF600R12IP4VBOSA1IGBT MOD 1200V 600A 3350W |
2,021 | 437.04 |
RFQ |
Datasheet |
Bulk,Bulk | PrimePACK™2 | Not For New Designs | Trench Field Stop | 2 Independent | 1200 V | 600 A | 3350 W | 2.05V @ 15V, 600A | 5 mA | 37 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
DF600R12IP4DVBOSA1IGBT MODULE VCES 1200V 600A |
2,480 | 583.49 |
RFQ |
Bulk | PrimePACK™2 | Not For New Designs | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
FS820R08A6P2BPSA1IGBT MODULE PACK DRV HYBRIDD-1 |
2,829 | 682.50 |
RFQ |
Datasheet |
Tray | HybridPACK™ | Active | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
FD900R12IP4DBOSA1IGBT MOD 1200V 900A 5100W |
2,703 | 598.46 |
RFQ |
Datasheet |
Bulk | PrimePACK™2 | Active | - | Single Chopper | 1200 V | 900 A | 5100 W | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
DF900R12IP4DBOSA1IGBT MOD 1200V 900A 5100W |
3,027 | 598.46 |
RFQ |
Datasheet |
Bulk | PrimePACK™2 | Active | Trench Field Stop | Single Chopper | 1200 V | 900 A | 5100 W | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FS225R17KE4BOSA1IGBT MOD 1700V 340A 1500W |
2,311 | 543.74 |
RFQ |
Datasheet |
Bulk,Tray | EconoPACK™+ | Not For New Designs | Trench Field Stop | Three Phase Inverter | 1700 V | 340 A | 1500 W | 2.3V @ 15V, 225A | 3 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FS225R17KE3BOSA1IGBT MOD 1700V 340A 1400W |
678 | 550.99 |
RFQ |
Datasheet |
Bulk,Tray | EconoPACK™+ | Not For New Designs | Trench Field Stop | Three Phase Inverter | 1700 V | 340 A | 1400 W | 2.45V @ 15V, 225A | 3 mA | 20.5 nF @ 25 V | Standard | Yes | -40°C ~ 125°C | Chassis Mount |
|
|
FS770R08A6P2BBPSA1HYBRID PACK DRIVE |
2,052 | 479.98 |
RFQ |
Datasheet |
Bulk,Tray | HybridPACK™ | Active | Trench Field Stop | Three Phase Inverter | 750 V | 450 A | 654 W | 1.35V @ 15V, 450A | 1 mA | 80 nF @ 50 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
|
FS300R17OE4PBOSA1MOD IGBT MED PWR ECONOPP-2 |
2,123 | 565.75 |
RFQ |
Bulk,Tray | EconoPACK™+ | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
|
FS450R12OE4PBOSA1IGBT MOD 1200V 900A 20MW |
3,204 | 565.75 |
RFQ |
Datasheet |
Bulk,Tray | EconoPACK™+ | Active | Trench Field Stop | Full Bridge | 1200 V | 900 A | 20 mW | 2.1V @ 15V, 450A | 3 mA | 1.55 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FS770R08A6P2LBBPSA1HYBRID PACK DRIVE |
3,028 | 640.50 |
RFQ |
Datasheet |
Tray | HybridPACK™ | Active | Trench Field Stop | Three Phase Inverter | 750 V | 450 A | 654 W | 1.35V @ 15V, 450A | 1 mA | 80 nF @ 50 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
|
FD900R12IP4DVBOSA1IGBT MOD 1200V 900A 5100W |
2,024 | 496.98 |
RFQ |
Datasheet |
Bulk,Bulk | PrimePACK™2 | Not For New Designs | Trench Field Stop | Single | 1200 V | 900 A | 5100 W | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
DF900R12IP4DVBOSA1IGBT MOD 1200V 900A 5100W |
3,935 | 496.98 |
RFQ |
Datasheet |
Bulk,Bulk | PrimePACK™2 | Not For New Designs | Trench Field Stop | Single Chopper | 1200 V | 900 A | 5100 W | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF650R17IE4PBOSA1IGBT MODULE 1700V 650A |
2,058 | 654.57 |
RFQ |
Datasheet |
Bulk | PrimePACK™2 | Active | Trench Field Stop | 2 Independent | 1700 V | 650 A | - | 2.45V @ 15V, 650A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF900R12IP4PBOSA1IGBT MODULE 1200V 900A |
120 | 506.43 |
RFQ |
Datasheet |
Bulk,Bulk | PrimePACK™2 | Active | Trench Field Stop | 2 Independent | 1200 V | 900 A | - | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
