| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NP40N10VDF-E1-AYMOSFET N-CH 100V 40A TO252 |
4,059 | 0.48 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 40A (Tc) | - | 26mOhm @ 20A, 10V | 2.5V @ 250µA | 71 nC @ 10 V | ±20V | 3150 pF @ 25 V | - | 1.2W (Ta), 120W (Tc) | 175°C | Surface Mount |
|
RJK03J3DPA-00#J5AN-CHANNEL POWER SWITCHING MOSFET |
27,000 | 0.55 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
RJK03M2DPA-00#J5AMOSFET N-CH 30V 45A 8WPAK |
3,000 | 0.85 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 45A (Ta) | 4.5V, 10V | 2.8mOhm @ 22.5A, 10V | - | 21.2 nC @ 4.5 V | ±20V | 3850 pF @ 10 V | - | 40W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK03P1DPA-00#J5AN-CHANNEL POWER MOSFET |
960,000 | 0.75 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
RJK03N4DPA-02#J5AN-CHANNEL POWER MOSFET |
432,000 | 0.75 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RJK0397DPA-0G#J7APOWER TRANSISTOR, MOSFET |
5,048,700 | 0.51 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
RJK03E0DNS-02#J5N-CHANNEL POWER MOSFET |
490,000 | 0.51 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
RJK03P5DPA-00#J5AN-CHANNEL POWER MOSFET |
468,000 | 0.51 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
RJK03B7DPA-00#J5AMOSFET N-CH 30V 30A 8WPAK |
197,615 | 0.51 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 7.8mOhm @ 15A, 10V | - | 11 nC @ 4.5 V | - | 1670 pF @ 10 V | - | 30W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0397DPA-00#J53MOSFET N-CH 30V 30A 8WPAK |
188,485 | 0.51 |
RFQ |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 10.1mOhm @ 15A, 10V | - | 7.4 nC @ 4.5 V | - | 1110 pF @ 10 V | - | 25W (Tc) | - | Surface Mount | |
|
2SJ557-T1B-ASMALL SIGNAL P-CHANNEL MOSFET |
179,000 | 0.51 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RJK03B8DPA-00#J53MOSFET N-CH 30V 30A 8WPAK |
115,327 | 0.51 |
RFQ |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 9.3mOhm @ 15A, 10V | - | 9 nC @ 4.5 V | - | 1330 pF @ 10 V | - | 28W (Tc) | - | Surface Mount | |
|
|
RJK03B9DPA-00#J53MOSFET N-CH 30V 30A 8WPAK |
21,000 | 0.51 |
RFQ |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 10.6mOhm @ 15A, 10V | - | 7.4 nC @ 4.5 V | - | 1110 pF @ 10 V | - | 25W (Tc) | 150°C (TJ) | Surface Mount | |
|
|
RJK03B7DPA-00#J53MOSFET N-CH 30V 30A 8WPAK |
12,000 | 0.51 |
RFQ |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 7.8mOhm @ 15A, 10V | - | 11 nC @ 4.5 V | - | 1670 pF @ 10 V | - | 30W (Tc) | - | Surface Mount | |
|
NP23N06YDG-E1-AYMOSFET N-CH 60V 23A 8HSON |
5,000 | 0.61 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 23A (Tc) | 5V, 10V | 27mOhm @ 11.5A, 10V | 2.5V @ 250µA | 41 nC @ 10 V | ±20V | 1800 pF @ 25 V | - | 1W (Ta), 60W (Tc) | 175°C (TJ) | Surface Mount |
|
RJK03M8DNS-00#J5MOSFET N-CH 30V 30A 8HWSON |
315,000 | 0.53 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 30A (Ta) | - | 5.2mOhm @ 15A, 10V | - | 14.5 nC @ 4.5 V | - | 2590 pF @ 10 V | - | 20W (Tc) | 150°C (TJ) | Surface Mount |
|
RJK0352DSP-00#J0MOSFET N-CH 30V 18A 8SOP |
182,500 | 0.53 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A (Ta) | - | 5.6mOhm @ 9A, 10V | - | 16 nC @ 4.5 V | - | 2440 pF @ 10 V | - | 2W (Ta) | 150°C (TJ) | Surface Mount |
|
|
RJK0212DPA-00#J5AMOSFET N-CH WPAK |
27,000 | 0.53 |
RFQ |
Bulk | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | |
|
RJK0358DSP-00#J0N-CHANNEL POWER MOSFET |
787,500 | 0.55 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
UPA2680T1E-E2-ATMOSFET N-CH 20V 3A 6MLP |
564,000 | 0.55 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 3A (Ta) | - | 50mOhm @ 3A, 10V | 2V @ 250µA | 3.1 nC @ 4.5 V | - | 190 pF @ 10 V | Schottky Diode (Isolated) | - | - | Surface Mount |
