| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RJK1054DPB-00#J5MOSFET N-CH 100V 20A LFPAK |
2,049 | 1.07 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 20A (Ta) | 10V | 22mOhm @ 10A, 10V | - | 27 nC @ 10 V | ±20V | 2000 pF @ 10 V | - | 55W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0455DPB-00#J5MOSFET N-CH 40V 45A LFPAK |
2,629 | 1.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 45A (Ta) | 10V | 3.8mOhm @ 22.5A, 10V | - | 34 nC @ 10 V | ±20V | 2550 pF @ 10 V | - | 60W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0652DPB-00#J5MOSFET N-CH 60V 35A LFPAK |
3,013 | 1.17 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 35A (Ta) | 4.5V, 10V | 7mOhm @ 17.5A, 10V | - | 29 nC @ 4.5 V | ±20V | 4100 pF @ 10 V | - | 55W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0330DPB-01#J0MOSFET N-CH 30V 45A LFPAK |
2,557 | 1.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 45A (Ta) | 4.5V, 10V | 2.7mOhm @ 22.5A, 10V | - | 27 nC @ 4.5 V | ±20V | 4300 pF @ 10 V | - | 55W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0452DPB-00#J5MOSFET N-CH 40V 45A LFPAK |
3,278 | 1.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 45A (Ta) | 4.5V, 10V | 3.5mOhm @ 22.5A, 10V | - | 26 nC @ 4.5 V | ±20V | 4030 pF @ 10 V | - | 55W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK1052DPB-00#J5MOSFET N-CH 100V 20A LFPAK |
2,717 | 1.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 20A (Ta) | 4.5V, 10V | 20mOhm @ 10A, 10V | - | 29 nC @ 4.5 V | ±20V | 4160 pF @ 10 V | - | 55W (Tc) | 150°C (TJ) | Surface Mount |
|
RJK0346DPA-01#J0BMOSFET N-CH 30V 65A 8WPAK |
3,752 | 1.19 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 65A (Ta) | 4.5V, 10V | 1.8mOhm @ 25A, 10V | - | 49 nC @ 10 V | ±20V | 7650 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
RJK0331DPB-01#J0POWER FIELD-EFFECT TRANSISTOR |
3,935 | 1.00 |
RFQ |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 40A (Ta) | - | 3.4mOhm @ 20A, 10V | - | 22 nC @ 4.5 V | - | 3380 pF @ 10 V | - | 50W (Tc) | 150°C (TJ) | Surface Mount | |
|
RJK0332DPB-01#J0SILICON N CHANNEL POWER SWITCHI |
2,577 | 1.00 |
RFQ |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 35A (Ta) | 4.5V, 10V | 4.7mOhm @ 17.5A, 10V | 2.5V @ 1mA | 14 nC @ 4.5 V | ±20V | 2180 pF @ 10 V | - | 45W (Tc) | 150°C (TJ) | Surface Mount | |
|
|
RJK0655DPB-00#J5MOSFET N-CH 60V 35A LFPAK |
3,940 | 1.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 35A (Ta) | 10V | 6.7mOhm @ 17.5A, 10V | - | 35 nC @ 10 V | ±20V | 2550 pF @ 10 V | - | 60W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0855DPB-00#J5MOSFET N-CH 80V 30A LFPAK |
2,500 | 1.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 30A (Ta) | 10V | 11mOhm @ 15A, 10V | - | 35 nC @ 10 V | ±20V | 2550 pF @ 10 V | - | 60W (Tc) | 150°C (TJ) | Surface Mount |
|
NP180N04TUG-E1-AY180A, 40V, N-CHANNEL MOSFET |
2,345 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 180A (Tc) | 10V | 1.5mOhm @ 90A, 10V | 4V @ 250µA | 390 nC @ 10 V | ±20V | 25700 pF @ 25 V | - | 1.8W (Ta), 288W (Tc) | 175°C (TJ) | Surface Mount |
|
|
RJK0456DPB-00#J5MOSFET N-CH 40V 50A LFPAK |
3,032 | 1.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 50A (Ta) | 10V | 3.2mOhm @ 25A, 10V | - | 39 nC @ 10 V | ±20V | 3000 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0656DPB-00#J5MOSFET N-CH 60V 40A LFPAK |
2,511 | 1.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 40A (Ta) | 10V | 5.6mOhm @ 20A, 10V | - | 40 nC @ 10 V | ±20V | 3000 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK1056DPB-00#J5MOSFET N-CH 100V 25A LFPAK |
3,458 | 1.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 25A (Ta) | 10V | 14mOhm @ 12.5A, 10V | - | 41 nC @ 10 V | ±20V | 3000 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
NP89N055PUK-E1-AYMOSFET N-CH 55V 90A TO263-3 |
3,466 | 2.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 90A (Tc) | 10V | 4mOhm @ 45A, 10V | 4V @ 250µA | 102 nC @ 10 V | ±20V | 6000 pF @ 25 V | - | 1.8W (Ta), 147W (Tc) | 175°C (TJ) | Surface Mount |
|
|
RJK0853DPB-00#J5MOSFET N-CH 80V 40A LFPAK |
2,452 | 1.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 40A (Ta) | 4.5V, 10V | 8mOhm @ 20A, 10V | - | 40 nC @ 4.5 V | ±20V | 6170 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0653DPB-00#J5MOSFET N-CH 60V 45A LFPAK |
2,703 | 1.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Ta) | 4.5V, 10V | 4.8mOhm @ 22.5A, 10V | 2.5V @ 1mA | 42 nC @ 4.5 V | ±20V | 6100 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0328DPB-01#J0MOSFET N-CH 30V 60A LFPAK |
3,058 | 1.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 60A (Ta) | 4.5V, 10V | 2.1mOhm @ 30A, 10V | 2.5V @ 1mA | 42 nC @ 4.5 V | ±20V | 6380 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
|
|
RJK0856DPB-00#J5MOSFET N-CH 80V 35A LFPAK |
3,380 | 1.49 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 35A (Ta) | 10V | 8.9mOhm @ 17.5A, 10V | - | 40 nC @ 10 V | ±20V | 3000 pF @ 10 V | - | 65W (Tc) | 150°C (TJ) | Surface Mount |
