| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRFH8337TRPBFMOSFET N-CH 30V 12A/35A PQFN |
2,617 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 12A (Ta), 35A (Tc) | 4.5V, 10V | 12.8mOhm @ 16.2A, 10V | 2.35V @ 25µA | 10 nC @ 10 V | ±20V | 790 pF @ 10 V | - | 3.2W (Ta), 27W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRLR7833TRLPBFMOSFET N-CH 30V 140A DPAK |
2,623 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 140A (Tc) | 4.5V, 10V | 4.5mOhm @ 15A, 10V | 2.3V @ 250µA | 50 nC @ 4.5 V | ±20V | 4010 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRLZ44ZMOSFET N-CH 55V 51A TO220AB |
3,686 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 51A (Tc) | 4.5V, 10V | 13.5mOhm @ 31A, 10V | 3V @ 250µA | 36 nC @ 5 V | ±16V | 1620 pF @ 25 V | - | 80W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRF8788PBFMOSFET N-CH 30V 24A 8SO |
2,439 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 24A (Ta) | 4.5V, 10V | 2.8mOhm @ 24A, 10V | 2.35V @ 100µA | 66 nC @ 4.5 V | ±20V | 5720 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRF4905STRLAUIRF4905S - 20V-150V P-CHANNEL |
2,107 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, HEXFET® | Active | P-Channel | MOSFET (Metal Oxide) | 55 V | 42A (Tc) | 10V | 20mOhm @ 42A, 10V | 4V @ 250µA | 180 nC @ 10 V | ±20V | 3500 pF @ 25 V | - | 200W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRFR540ZTRLMOSFET N-CH 100V 35A DPAK |
2,381 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 35A (Tc) | 10V | 28.5mOhm @ 21A, 10V | 4V @ 50µA | 59 nC @ 10 V | ±20V | 1690 pF @ 25 V | - | 91W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFR4105PBFMOSFET N-CH 55V 27A DPAK |
2,629 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 27A (Tc) | 10V | 45mOhm @ 16A, 10V | 4V @ 250µA | 34 nC @ 10 V | ±20V | 700 pF @ 25 V | - | 68W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF1324S-7PPBFMOSFET N-CH 24V 240A D2PAK |
3,139 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 24 V | 240A (Tc) | 10V | 1mOhm @ 160A, 10V | 4V @ 250µA | 252 nC @ 10 V | ±20V | 7700 pF @ 19 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFS4010TRL7PPIRFS4010 - 12V-300V N-CHANNEL PO |
3,809 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 190A (Tc) | 10V | 4mOhm @ 110A, 10V | 4V @ 250µA | 230 nC @ 10 V | ±20V | 9830 pF @ 50 V | - | 380W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF3315PBFMOSFET N-CH 150V 23A TO220AB |
2,027 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 23A (Tc) | - | 70mOhm @ 12A, 10V | 4V @ 250µA | 95 nC @ 10 V | ±20V | 1300 pF @ 25 V | - | 94W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRLL024ZPBFMOSFET N-CH 55V 5A SOT223 |
3,001 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 5A (Tc) | 4.5V, 10V | 60mOhm @ 3A, 10V | 3V @ 250µA | 11 nC @ 5 V | ±16V | 380 pF @ 25 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRLS3813PBFMOSFET N-CH 30V 160A D2PAK |
3,614 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 160A (Tc) | 10V | 1.95mOhm @ 148A, 10V | 2.35V @ 150µA | 83 nC @ 4.5 V | ±20V | 8020 pF @ 25 V | - | 195W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRF1405ZSTRLMOSFET N-CH 55V 150A D2PAK |
2,212 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 150A (Tc) | 10V | 4.9mOhm @ 75A, 10V | 4V @ 250µA | 180 nC @ 10 V | ±20V | 4780 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRL3713PBFMOSFET N-CH 30V 260A TO220AB |
2,510 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 260A (Tc) | 4.5V, 10V | 3mOhm @ 38A, 10V | 2.5V @ 250µA | 110 nC @ 4.5 V | ±20V | 5890 pF @ 15 V | - | 330W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRF7424TRPBFIRF7424 - 20V-250V P-CHANNEL POW |
2,667 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 13.5mOhm @ 11A, 10V | 2.5V @ 250µA | 110 nC @ 10 V | ±20V | 4030 pF @ 25 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRFS8407AUIRFS8407 - 20V-40V N-CHANNEL A |
3,875 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 195A (Tc) | 10V | 1.8mOhm @ 100A, 10V | 4V @ 150µA | 225 nC @ 10 V | ±20V | 7330 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
AUIRFZ44ZSMOSFET N-CH 55V 51A D2PAK |
3,465 | 0.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 51A (Tc) | 10V | 13.9mOhm @ 31A, 10V | 4V @ 250µA | 43 nC @ 10 V | ±20V | 1420 pF @ 25 V | - | 80W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRF7738L2TRMOSFET N-CH 40V 35A/130A DIRECT |
3,370 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 35A (Ta), 130A (Tc) | 10V | 1.6mOhm @ 109A, 10V | 4V @ 250µA | 194 nC @ 10 V | ±20V | 7471 pF @ 25 V | - | 3.3W (Ta), 94W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFR13N15DPBFMOSFET N-CH 150V 14A DPAK |
2,758 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 14A (Tc) | 10V | 180mOhm @ 8.3A, 10V | 5.5V @ 250µA | 29 nC @ 10 V | ±30V | 620 pF @ 25 V | - | 86W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFR8314TRPBFIRFR8314 - 12V-300V N-CHANNEL PO |
2,068 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 90A (Tc) | 4.5V, 10V | 2.2mOhm @ 90A, 10V | 2.2V @ 100µA | 54 nC @ 4.5 V | ±20V | 4945 pF @ 15 V | - | 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
