| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BUK7S2R5-40HJBUK7S2R5-40H/SOT1235/LFPAK88 |
3,670 | 2.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 140A (Ta) | 10V | 2.51mOhm @ 25A, 10V | 3.6V @ 1mA | 54 nC @ 10 V | +20V, -10V | 3793 pF @ 25 V | - | 135W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
BUK9660-100APFET, 26A I(D), 100V, 0.067OHM |
3,160 | 0.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 26A (Tc) | 4.5V, 10V | 58mOhm @ 15A, 10V | 2V @ 1mA | - | ±10V | 1924 pF @ 25 V | - | 106W (Tc) | -55°C ~ 175°C (TJ) | |
|
BUK9Y8R8-60ELXSINGLE N-CHANNEL 60 V, 5.6 MOHM |
2,606 | 2.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 110A (Ta) | 4.5V, 10V | 5.6mOhm @ 25A, 10V | 2.1V @ 1mA | 123 nC @ 10 V | ±10V | 6695 pF @ 25 V | - | 194W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
PMN48XPA,115MOSFET P-CH 20V 4.1A 6TSOP |
2,366 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.1A (Ta) | - | 55mOhm @ 2.4A, 4.5V | 1.25V @ 250µA | 13 nC @ 4.5 V | ±12V | 1000 pF @ 10 V | - | 530mW (Ta), 6.25W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
BUK9Y7R0-60ELXSINGLE N-CHANNEL 60 V, 4.5 MOHM |
3,855 | 2.60 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 125A (Ta) | 4.5V, 10V | 4.5mOhm @ 25A, 10V | 2.1V @ 1mA | 152 nC @ 10 V | ±10V | 8327 pF @ 25 V | - | 238.4W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
PMV100XPEA,215MOSFET P-CH 20V 2.4A TO236AB |
3,093 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.4A (Ta) | - | 128mOhm @ 2.4A, 4.5V | 1.25V @ 250µA | 6 nC @ 4.5 V | ±12V | 386 pF @ 10 V | - | 463mW (Ta), 4.45W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
PMPB20XNEA,1157.5A, 20V, N CHANNEL, SILICON, M |
2,509 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PSMN1R4-40YLD,115-NEX100A, 40V, 0.00185OHM, N CHANNEL |
3,837 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 4.5V, 10V | 1.4mOhm @ 25A, 10V | - | - | ±20V | - | - | 238W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
BUK764R0-75C,118-NEXPFET, 100A I(D), 75V, 0.004OHM |
3,317 | 0.00 |
RFQ |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 100A (Tc) | 10V | 4mOhm @ 25A, 10V | 4V @ 1mA | 142 nC @ 10 V | ±20V | 11659 pF @ 25 V | - | 333W (Tc) | -55°C ~ 175°C (TJ) | ||
|
PSMN130-200D,118-NEXPOWER FIELD-EFFECT TRANSISTOR, 2 |
3,417 | 1.00 |
RFQ |
Bulk | TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 20A (Tc) | 10V | 130mOhm @ 25A, 10V | 4V @ 1mA | 65 nC @ 10 V | ±20V | 2470 pF @ 25 V | - | 150W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
PSMN085-150K,518-NEXPOWER FIELD-EFFECT TRANSISTOR, 3 |
3,888 | 1.00 |
RFQ |
Bulk | TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 3.5A (Tc) | 10V | 85mOhm @ 3.5A, 10V | 4V @ 1mA | 40 nC @ 10 V | ±20V | 1310 pF @ 25 V | - | 3.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
BUK6211-75C,118-NEXMOSFET N-CH 75V 74A DPAK |
2,772 | 1.00 |
RFQ |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 74A (Ta) | - | 11mOhm @ 25A, 10V | 2.8V @ 1mA | 81 nC @ 10 V | ±16V | 5251 pF @ 25 V | - | 158W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
BUK6212-40C,118-NEXMOSFET N-CH 40V 50A DPAK |
3,679 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 50A (Ta) | - | 11.2mOhm @ 12A, 10V | 2.8V @ 1mA | 33.9 nC @ 10 V | ±16V | 1900 pF @ 25 V | - | 80W | -55°C ~ 175°C (TJ) | Surface Mount |
|
PHK12NQ03LT,518-NEXPOWER FIELD-EFFECT TRANSISTOR, 1 |
2,933 | 1.00 |
RFQ |
Bulk | TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 11.8A (Tj) | 4.5V, 10V | 10.5mOhm @ 12A, 10V | 2V @ 250µA | 17.6 nC @ 5 V | ±20V | 1335 pF @ 16 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
BUK6218-40C,118-NEXPFET, 42A I(D), 40V, 0.028OHM, 1 |
3,882 | 1.00 |
RFQ |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 42A (Tc) | 10V | 16mOhm @ 10A, 10V | 2.8V @ 1mA | 22 nC @ 10 V | ±16V | 1170 pF @ 25 V | - | 60W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
PSMN070-200B,118-NEXMOSFET N-CH 200V 35A D2PAK |
3,893 | 1.00 |
RFQ |
Bulk | TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 35A (Ta) | - | 70mOhm @ 17A, 10V | 4V @ 1mA | 77 nC @ 10 V | ±20V | 4570 pF @ 25 V | - | 250W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
BUK7509-55A,127-NEXPFET, 75A I(D), 55V, 0.009OHM, 1 |
3,250 | 1.00 |
RFQ |
Tube | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 75A (Tc) | 10V | 9mOhm @ 25A, 10V | 4V @ 1mA | 62 nC @ 0 V | ±20V | 3271 pF @ 25 V | - | 211W (Tc) | -55°C ~ 175°C (TJ) | Through Hole | |
|
|
BUK663R2-40C,118-NEXPFET, 100A I(D), 40V, 0.0057OHM |
3,597 | 0.00 |
RFQ |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 3.2mOhm @ 25A, 10V | 2.8V @ 1mA | 125 nC @ 10 V | ±16V | 8020 pF @ 25 V | - | 204W (Tc) | -55°C ~ 175°C (TJ) | ||
|
|
PMZB370UNE,315-NEXEFFECT TRANSISTOR, 0.9A I(D), 30 |
3,294 | 1.00 |
RFQ |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 900mA (Ta) | 1.8V, 4.5V | 490mOhm @ 500mA, 4.5V | 1.05V @ 250µA | 1.16 nC @ 15 V | ±8V | 78 pF @ 25 V | - | 360mW (Ta), 2.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
BUK6215-75C,118-NEXMOSFET N-CH 75V 57A DPAK |
3,826 | 1.00 |
RFQ |
Bulk | Automotive, AEC-Q101, TrenchMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 57A (Ta) | - | 15mOhm @ 15A, 10V | 2.8V @ 1mA | 61.8 nC @ 10 V | ±16V | 3900 pF @ 25 V | - | 128W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
