| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PJE8402_R1_0000120V N-CHANNEL ENHANCEMENT MODE M |
8,000 | 0.47 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 700mA (Ta) | 1.8V, 4.5V | 150mOhm @ 700mA, 4,5V | 1V @ 250µA | 1.6 nC @ 4.5 V | ±8V | 92 pF @ 10 V | - | 300mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
PJT7413_S1_0000120V P-CHANNEL ENHANCEMENT MODE M |
3,000 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.5A (Ta) | 1.5V, 4.5V | 85mOhm @ 2.5A, 4.5V | 1.2V @ 250µA | 7 nC @ 4.5 V | ±12V | 522 pF @ 10 V | - | 750mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
PJS6412_S1_0000130V N-CHANNEL ENHANCEMENT MODE M |
3,000 | 0.52 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8A (Ta) | 4.5V, 10V | 23mOhm @ 8A, 10V | 2.5V @ 250µA | 4.3 nC @ 4.5 V | ±20V | 392 pF @ 25 V | - | 2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
PJL9408_R2_0000130V N-CHANNEL ENHANCEMENT MODE M |
2,500 | 0.52 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8A (Ta) | 4.5V, 10V | 18mOhm @ 8A, 10V | 2.5V @ 250µA | 4.3 nC @ 4.5 V | ±20V | 392 pF @ 25 V | - | 1.7W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
PJQ2410_R1_00001DFN2020B-6L, MOSFET |
3,000 | 0.54 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta) | 4.5V, 10V | 12mOhm @ 5A, 10V | 2.5V @ 250µA | 7.1 nC @ 4.5 V | ±20V | 660 pF @ 25 V | - | 2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
PJQ4414P_R2_0000130V N-CHANNEL ENHANCEMENT MODE M |
4,990 | 0.52 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8A (Ta), 25A (Tc) | 4.5V, 10V | 18mOhm @ 9A, 10V | 2.5V @ 250µA | 4.3 nC @ 4.5 V | ±20V | 392 pF @ 25 V | - | 2W (Ta), 21W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
PJD9N10A_L2_00001100V N-CHANNEL MOSFET |
11,682 | 0.58 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 2.4A (Ta), 9A (Tc) | 4.5V, 10V | 152mOhm @ 4.5A, 10V | 2.5V @ 250µA | 19 nC @ 10 V | ±20V | 1021 pF @ 25 V | - | 2W (Ta), 31W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
PJQ5411_R2_0000130V P-CHANNEL ENHANCEMENT MODE M |
8,920 | 0.62 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta), 45A (Tc) | 4.5V, 10V | 15.5mOhm @ 10A, 10V | 2.5V @ 250µA | 14 nC @ 4.5 V | ±20V | 1556 pF @ 15 V | - | 2W (Ta), 40W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
PJQ5450-AU_R2_000A140V N-CHANNEL ENHANCEMENT MODE M |
3,000 | 0.67 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 5.9A (Ta), 21A (Tc) | 4.5V, 10V | 32mOhm @ 12A, 10V | 2.5V @ 250µA | 4.4 nC @ 4.5 V | ±20V | 425 pF @ 25 V | - | 2.4W (Ta), 30W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
PJQ4402P-AU_R2_000A130V N-CHANNEL ENHANCEMENT MODE M |
4,998 | 0.72 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 16A (Ta), 70A (Tc) | 4.5V, 10V | 3.8mOhm @ 10A, 10V | 2.5V @ 250µA | 23 nC @ 4.5 V | ±20V | 2436 pF @ 25 V | - | 2W (Ta), 39W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
PJQ4403P_R2_0000130V P-CHANNEL ENHANCEMENT MODE M |
3,386 | 0.64 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 9.8A (Ta), 35A (Tc) | 4.5V, 10V | 15.5mOhm @ 10A, 10V | 2.5V @ 250µA | 15 nC @ 4.5 V | ±20V | 1730 pF @ 15 V | - | 2W (Ta), 30W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
PJQ5446-AU_R2_000A140V N-CHANNEL ENHANCEMENT MODE M |
6,000 | 0.77 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 12A (Ta), 70A (Tc) | 4.5V, 10V | 9.5mOhm @ 12A, 10V | 2.5V @ 250µA | 22 nC @ 10 V | ±20V | 1258 pF @ 25 V | - | 2.4W (Ta), 83.3W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
PJQ4468AP_R2_0000160V N-CHANNEL ENHANCEMENT MODE M |
5,000 | 0.92 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 5A (Ta), 18A (Tc) | 4.5V, 10V | 34mOhm @ 10A, 10V | 2.5V @ 250µA | 20 nC @ 10 V | ±20V | 1173 pF @ 25 V | - | 2W (Ta), 24W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
PJD45P04_L2_0000140V P-CHANNEL ENHANCEMENT MODE M |
2,900 | 0.87 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 8.5A (Ta), 45A (Tc) | 4.5V, 10V | 17mOhm @ 15A, 10V | 2.5V @ 250µA | 19 nC @ 4.5 V | ±20V | 2030 pF @ 25 V | - | 2W (Ta), 63W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
PJD50N04-AU_L2_000A140V N-CHANNEL ENHANCEMENT MODE M |
3,000 | 1.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 9.6A (Ta), 50A (Tc) | 4.5V, 10V | 9.5mOhm @ 8A, 10V | 2.5V @ 250µA | 22 nC @ 10 V | ±20V | 1258 pF @ 25 V | - | 2.4W (Ta), 64.9W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
PJQ5442-AU_R2_000A140V N-CHANNEL ENHANCEMENT MODE M |
3,000 | 0.99 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 14A (Ta), 90A (Tc) | 4.5V, 10V | 5.5mOhm @ 20A, 10V | 2.5V @ 250µA | 25 nC @ 4.5 V | ±20V | 1258 pF @ 25 V | - | 2.4W (Ta), 99.3W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
PJL9480_R2_00001150V N-CHANNEL ENHANCEMENT MODE |
2,500 | 1.07 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 4A (Ta) | 6V, 10V | 65mOhm @ 4A, 10V | 4V @ 250µA | 29.5 nC @ 10 V | ±25V | 1764 pF @ 30 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
PJD80N04-AU_L2_000A140V N-CHANNEL ENHANCEMENT MODE M |
3,000 | 1.22 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 14A (Ta), 80A (Tc) | 4.5V, 10V | 5.5mOhm @ 20A, 10V | 2.5V @ 250µA | 25 nC @ 4.5 V | ±20V | 1258 pF @ 25 V | - | 2.4W (Ta), 79.4W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
PJMF900N60E1_T0_00001600V/ 900MOHM SUPER JUNCTION EAS |
1,998 | 1.44 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 4.4A (Tc) | 10V | 900mOhm @ 1.5A, 10V | 4V @ 250µA | 11.5 nC @ 10 V | ±30V | 344 pF @ 400 V | - | 23.6W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
|
PJMD900N60EC_L2_00001600V SUPER JUNCITON MOSFET |
5,845 | 2.19 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 5A (Tc) | 10V | 900mOhm @ 2.3A, 10V | 4V @ 250µA | 8.8 nC @ 10 V | ±30V | 310 pF @ 400 V | - | 47.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
