| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | TransistorType | Current-Collector(Ic)(Max) | Voltage-CollectorEmitterBreakdown(Max) | VceSaturation(Max)@IbIc | Current-CollectorCutoff(Max) | DCCurrentGain(hFE)(Min)@IcVce | Power-Max | Frequency-Transition | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STBV45-APTRANS NPN 400V 0.75A TO92AP |
2,557 | 0.51 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | - | Obsolete | NPN | 750 mA | 400 V | 1.5V @ 135mA, 400mA | 250µA | 5 @ 400mA, 5V | 950 mW | - | 150°C (TJ) | Through Hole |
,TO-226_straightlead.jpg)
|
STL73DTRANS NPN 400V 1.5A TO92-3 |
3,464 | 0.33 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPN | 1.5 A | 400 V | 1V @ 250mA, 1A | - | 10 @ 600mA, 3V | 1.5 W | - | - | Through Hole |
|
2STF2280TRANS PNP 80V 2A SOT89 |
2,553 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | PNP | 2 A | 80 V | 250mV @ 100mA, 1A | 1mA | 140 @ 100mA, 2V | 1.4 W | 50MHz | -65°C ~ 150°C (TJ) | Surface Mount |
|
2STR1215TRANS NPN 15V 1.5A SOT23-3 |
2,513 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 1.5 A | 15 V | 850mV @ 200mA, 2A | 100nA (ICBO) | 200 @ 500mA, 2V | 500 mW | - | -65°C ~ 150°C (TJ) | Surface Mount |
|
|
STPSA92-APTRANS PNP 300V 0.5A TO92AP |
2,575 | 0.00 |
RFQ |
Datasheet |
Tape & Box (TB) | - | Obsolete | PNP | 500 mA | 300 V | 500mV @ 2mA, 20mA | 100nA (ICBO) | 40 @ 30mA, 10V | 625 mW | 50MHz | 150°C (TJ) | Through Hole |
|
|
STPSA92TRANS PNP 300V 0.5A TO92-3 |
3,066 | 0.45 |
RFQ |
Datasheet |
Bulk | - | Obsolete | PNP | 500 mA | 300 V | 500mV @ 2mA, 20mA | 100nA (ICBO) | 40 @ 30mA, 10V | 625 mW | 50MHz | 150°C (TJ) | Through Hole |
|
2STF1525TRANS NPN 25V 5A SOT89 |
2,417 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | NPN | 5 A | 25 V | 500mV @ 40mA, 3.5A | 100nA (ICBO) | 150 @ 500mA, 2V | 1.4 W | 120MHz | 150°C (TJ) | Surface Mount |
|
|
STX83003-APTRANS NPN 400V 1A TO92-3 |
3,482 | 0.54 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | - | Obsolete | NPN | 1 A | 400 V | 1V @ 50mA, 350mA | 1mA | 16 @ 350mA, 5V | 1.5 W | - | 150°C (TJ) | Through Hole |
|
2N5191TRANS NPN 60V 4A SOT32-3 |
3,016 | 0.58 |
RFQ |
Datasheet |
Tube,Tube | - | Obsolete | NPN | 4 A | 60 V | 1.4V @ 1A, 4A | 1mA | 25 @ 1.5A, 2V | 40 W | 2MHz | 150°C (TJ) | Through Hole |
|
STK13003TRANS NPN 400V 1.5A SOT82-3 |
3,707 | 0.61 |
RFQ |
Datasheet |
Tube | - | Obsolete | NPN | 1.5 A | 400 V | 1.5V @ 500mA, 1.5A | 5mA | 5 @ 1A, 2V | 40 W | - | 150°C (TJ) | Through Hole |
|
|
2STF1360TRANS NPN 60V 3A SOT89-3 |
656 | 0.62 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 3 A | 60 V | 500mV @ 150mA, 3A | 100nA (ICBO) | 160 @ 1A, 2V | 1.4 W | 130MHz | 150°C (TJ) | Surface Mount |
|
BUL805TRANS NPN 450V 5A TO220 |
3,003 | 0.66 |
RFQ |
Datasheet |
Tube,Tube | - | Obsolete | NPN | 5 A | 450 V | 800mV @ 600mA, 3A | 250µA | 10 @ 2A, 5V | 80 W | - | 150°C (TJ) | Through Hole |
|
|
3STR1630TRANS NPN 30V 6A SOT23-3 |
3,411 | 0.69 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | NPN | 6 A | 30 V | 300mV @ 500mA, 5A | 100nA (ICBO) | 180 @ 500mA, 2V | 500 mW | 100MHz | 150°C (TJ) | Surface Mount |
|
|
STL73TRANS NPN 400V 1.5A TO92-3 |
2,373 | 0.70 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPN | 1.5 A | 400 V | 1V @ 250mA, 1A | - | 10 @ 600mA, 3V | 1.1 W | - | 150°C (TJ) | Through Hole |
|
BULB128-1TRANS NPN 400V 4A TO262 |
3,717 | 0.70 |
RFQ |
Datasheet |
Tube | - | Obsolete | NPN | 4 A | 400 V | 500mV @ 1A, 4A | 250µA | 14 @ 2A, 5V | 70 W | - | 150°C (TJ) | Through Hole |
|
|
ST13003D-KTRANS NPN 400V 1.5A SOT32-3 |
3,448 | 0.71 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPN | 1.5 A | 400 V | 3V @ 500mA, 1.5A | 1mA | 5 @ 1A, 2V | 40 W | - | 150°C (TJ) | Through Hole |
;;2.jpg)
|
MJD32CT4-ATRANS PNP 100V 3A DPAK |
3,872 | 1.11 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | PNP | 3 A | 100 V | 1.2V @ 375mA, 3A | 50µA | 10 @ 3A, 4V | 15 W | - | 150°C (TJ) | Surface Mount |
|
|
MJD361T4-ATRANS PNP 60V 3A DPAK |
3,403 | 0.89 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | PNP | 3 A | 60 V | 900mV @ 150mA, 3A | 20µA (ICBO) | 60 @ 1A, 4V | 15 W | - | 150°C (TJ) | Surface Mount |
|
STI13005-1TRANS NPN 400V 3A TO251 |
2,121 | 0.92 |
RFQ |
Datasheet |
Tube | - | Obsolete | NPN | 3 A | 400 V | 5V @ 750mA, 3A | 1mA | 8 @ 2A, 5V | 30 W | - | 150°C (TJ) | Through Hole |
|
|
STT13005FPTRANS NPN 400V 2A SOT32FP |
2,400 | 0.92 |
RFQ |
Datasheet |
Bulk | - | Obsolete | NPN | 2 A | 400 V | 1.5V @ 400mA, 1.6A | 250µA | 10 @ 500mA, 5V | 30 W | - | 150°C (TJ) | Through Hole |
