| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | TransistorType | Current-Collector(Ic)(Max) | Voltage-CollectorEmitterBreakdown(Max) | Resistor-Base(R1) | Resistor-EmitterBase(R2) | DCCurrentGain(hFE)(Min)@IcVce | VceSaturation(Max)@IbIc | Current-CollectorCutoff(Max) | Frequency-Transition | Power-Max | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PDTA124EMB,315NOW NEXPERIA PDTA124EMB - SMALL |
2,358 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 22 kOhms | 22 kOhms | 60 @ 5mA, 5V | 150mV @ 500µA, 10mA | 100nA | 180 MHz | 250 mW | Surface Mount |
|
|
PDTA143TMB,315NOW NEXPERIA PDTA143TMB - SMALL |
3,297 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | - | 200 @ 1mA, 5V | 150mV @ 250µA, 5mA | 1µA | 180 MHz | 250 mW | Surface Mount |
|
|
PDTC143TMB,315NOW NEXPERIA PDTC143TMB - SMALL |
3,156 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | - | 200 @ 1mA, 5V | 100mV @ 250µA, 5mA | 1µA | 230 MHz | 250 mW | Surface Mount |
|
|
PDTA123TMB,315NOW NEXPERIA PDTA123TMB - SMALL |
3,552 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 2.2 kOhms | - | 30 @ 20mA, 5V | 150mV @ 500µA, 10mA | 1µA | 180 MHz | 250 mW | Surface Mount |
|
|
PDTC123TMB,315NOW NEXPERIA PDTC123TMB - SMALL |
2,294 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 2.2 kOhms | - | 30 @ 20mA, 5V | 150mV @ 500µA, 10mA | 1µA | 230 MHz | 250 mW | Surface Mount |
|
PDTC124ET,235NOW NEXPERIA PDTC124ET - SMALL S |
2,876 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 22 kOhms | 22 kOhms | 60 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 250 mW | Surface Mount |
|
PDTC144WU,115NOW NEXPERIA PDTC144WU - SMALL S |
3,752 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 47 kOhms | 22 kOhms | 60 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 200 mW | Surface Mount |
|
|
PDTA144EU,115NOW NEXPERIA PDTA144EU - SMALL S |
3,331 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 47 kOhms | 47 kOhms | 80 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 200 mW | Surface Mount |
|
|
PDTC123TT,215NOW NEXPERIA PDTC123TT - SMALL S |
3,401 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 2.2 kOhms | - | 30 @ 20mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 250 mW | Surface Mount |
|
PDTC114EK,115NEXPERIA PDTC114E - NPN RESISTOR |
2,544 | 0.03 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - |
|
|
PDTB143EUFNOW NEXPERIA PDTB143EUF - SMALL |
2,731 | 0.03 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 500 mA | 50 V | 4.7 kOhms | 4.7 kOhms | 60 @ 50mA, 5V | 100mV @ 2.5mA, 50mA | 500nA | 140 MHz | 300 mW | Surface Mount |
|
PDTC123JM,315NOW NEXPERIA PDTC123JM - SMALL S |
2,220 | 0.03 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 100 mA | 50 V | 2.2 kOhms | 47 kOhms | 100 @ 10mA, 5V | 100mV @ 250µA, 5mA | 1µA | - | 250 mW | Surface Mount |
|
PDTC114EE,115-NXP0.1A, 50V, NPN, SC-75 |
3,256 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - |
|
PDTA114EMB,315NOW NEXPERIA PDTA114 - SMALL SIG |
3,301 | 1.00 |
RFQ |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 10 kOhms | 10 kOhms | 30 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | 180 MHz | 250 mW | Surface Mount | |
|
|
PDTD113EUFNOW NEXPERIA PDTD113EUF - SMALL |
3,343 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 500 mA | 50 V | 1 kOhms | 1 kOhms | 33 @ 50mA, 5V | 100mV @ 2.5mA, 50mA | 500nA | 225 MHz | 300 mW | Surface Mount |
|
|
PDTB114EUFNOW NEXPERIA PDTB114EUF - SMALL |
3,937 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | NPN - Pre-Biased | 500 mA | 50 V | 10 kOhms | 10 kOhms | 70 @ 50mA, 5V | 100mV @ 2.5mA, 50mA | 500nA | 140 MHz | 300 mW | Surface Mount |
|
|
PDTA144WT,215NOW NEXPERIA PDTA144WT - SMALL S |
3,604 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | PNP - Pre-Biased | 100 mA | 50 V | 47 kOhms | 22 kOhms | 60 @ 5mA, 5V | 150mV @ 500µA, 10mA | 100nA (ICBO) | - | 250 mW | Surface Mount |
|
PDTC114YM315NOW NEXPERIA PDTC114YM - SMALL S |
3,671 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | Active | NPN - Pre-Biased | 100 mA | 50 V | 10 kOhms | 47 kOhms | 100 @ 5mA, 5V | 100mV @ 250µA, 5mA | 1µA | 230 MHz | 250 mW | Surface Mount |
|
PDTC143EE,115TRANS PREBIAS NPN 150MW SC75 |
2,307 | 0.02 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | NPN - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 4.7 kOhms | 30 @ 10mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 150 mW | Surface Mount |
|
|
PDTC115EE,115TRANS PREBIAS NPN 150MW SC75 |
2,026 | 0.02 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | NPN - Pre-Biased | 20 mA | 50 V | 100 kOhms | 100 kOhms | 80 @ 5mA, 5V | 150mV @ 250µA, 5mA | 1µA | - | 150 mW | Surface Mount |
