| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Voltage-OffState | Voltage-GateTrigger(Vgt)(Max) | Current-GateTrigger(Igt)(Max) | Voltage-OnState(Vtm)(Max) | Current-OnState(It(AV))(Max) | Current-OnState(It(RMS))(Max) | Current-Hold(Ih)(Max) | Current-OffState(Max) | Current-NonRepSurge5060Hz(Itsm) | SCRType | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
N8440FA240SCR 2.4KV W119 |
2,532 | 1401.90 |
RFQ |
Box | - | Active | 2.4 kV | - | - | - | 8440 A | - | - | - | 110000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
R2475ZD28NSCR 2.8KV 4978A W46 |
3,397 | 1404.15 |
RFQ |
Box | - | Active | 2.8 kV | 3 V | 300 mA | 2.8 V | 2475 A | 4978 A | 1 A | 300 mA | 34100A @ 50Hz | Standard Recovery | -40°C ~ 125°C | Chassis Mount | |
|
|
N7585FE240SCR 2.4KV W119 |
3,388 | 1425.00 |
RFQ |
Box | - | Active | 2.4 kV | - | - | - | 7535 A | - | - | - | 110000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
N8440FA280SCR 2.8KV W119 |
2,749 | 1430.55 |
RFQ |
Box | - | Active | 2.8 kV | - | - | - | 8440 A | - | - | - | 110000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
N7585FE280SCR 2.8KV W119 |
3,583 | 1454.10 |
RFQ |
Box | - | Active | 2.8 kV | - | - | - | 7535 A | - | - | - | 110000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
K4005EA480SCR 4.8KV W107 |
3,664 | 1474.35 |
RFQ |
Box | - | Active | 4.8 kV | - | - | - | 4005 A | - | - | - | 43200A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
K4005EA520SCR 5.2KV W107 |
3,575 | 1504.50 |
RFQ |
Box | - | Active | 5.2 kV | - | - | - | 4005 A | - | - | - | 43200A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
N5910FA420SCR 4.2KV W118 |
2,881 | 1590.75 |
RFQ |
Box | - | Active | 4.2 kV | - | - | - | 5910 A | - | - | - | 78000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
N5320FE420SCR 4.2KV W119 |
3,682 | 1613.70 |
RFQ |
Box | - | Active | 4.2 kV | - | - | - | 5320 A | - | - | - | 78000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
N5320FE450SCR 4.5KV W119 |
3,765 | 1646.70 |
RFQ |
Box | - | Active | 4.5 kV | - | - | - | 5320 A | - | - | - | 78000A @ 50Hz | Standard Recovery | - | Chassis Mount | |
|
|
G3000TF450SCR 4.5MV 2770A W86 |
3,780 | 2443.80 |
RFQ |
Box | - | Active | 4.5 kV | 1 V | 3 A | 4 V | 1381 A | 2770 A | 40 A | 60 mA | 32000A, 24000A | Standard Recovery | -40°C ~ 125°C | Chassis Mount | |
|
CS8-08IO2SCR 800V 25A TO64 |
2,087 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 800 V | 2.5 V | 30 mA | 1.6 V | 16 A | 25 A | 80 mA | 3 mA | 250A, 270A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
CS8-12IO2SCR 1.2KV 25A TO64 |
2,331 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1.2 kV | 2.5 V | 30 mA | 1.6 V | 16 A | 25 A | 80 mA | 3 mA | 250A, 270A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
CS23-08IO2SCR 800V 50A TO208AA |
3,392 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 800 V | 2.5 V | 50 mA | 1.8 V | 32 A | 50 A | 100 mA | 3 mA | 450A, 480A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
|
CS23-12IO2SCR 1.2KV 50A TO208AA |
3,968 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1.2 kV | 2.5 V | 50 mA | 1.8 V | 32 A | 50 A | 100 mA | 3 mA | 450A, 480A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
|
CS23-16IO2SCR 1.6KV 50A TO208AA |
3,663 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1.6 kV | 2.5 V | 50 mA | 1.8 V | 32 A | 50 A | 100 mA | 3 mA | 450A, 480A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
CS35-08IO4SCR 800V 120A TO208AC |
2,411 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 800 V | 1.5 V | 100 mA | 1.5 V | 69 A | 120 A | 80 mA | 10 mA | 1200A, 1340A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
|
CS35-12IO4SCR 1.2KV 120A TO208AC |
3,067 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1.2 kV | 1.5 V | 100 mA | 1.5 V | 69 A | 120 A | 80 mA | 10 mA | 1200A, 1340A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
|
CS35-14IO4SCR 1.4KV 120A TO208AC |
2,101 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1.4 kV | 1.5 V | 100 mA | 1.5 V | 69 A | 120 A | 80 mA | 10 mA | 1200A, 1340A | Standard Recovery | -40°C ~ 125°C | Chassis, Stud Mount |
|
CS19-08HO1CSCR 800V 35A ISOPLUS220 |
2,195 | 0.00 |
RFQ |
Datasheet |
Tube | - | Active | 800 V | 1.5 V | 25 mA | 1.65 V | 13 A | 35 A | 50 mA | 1 mA | 100A, 105A | Standard Recovery | -40°C ~ 125°C | Through Hole |
