| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | MountingType | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | CoilCurrent | CoilType | Features | TerminationStyle | SealRating | CoilInsulation | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | OperatingTemperature | ContactMaterial |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3-1617590-8HMS1206S01=RELAY |
2,409 | 176.26 |
RFQ |
Datasheet |
Bulk | HMS, CII | Active | - | - | DPDT (2 Form C) | 2 A | - | - | Non Latching | - | PC Pin | Sealed - Hermetically | - | - | - | 6 ms | 5 ms | -65°C ~ 125°C | - |
|
|
1617032-4HFW1201S105 = HFW 1/2 SIZE REL |
3,849 | 176.80 |
RFQ |
Bulk | HFW, CII | Active | Through Hole | - | DPDT (2 Form C) | 2 A | - | - | - | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 4 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) | |
|
1617792-6SSR RELAY DPDT 1A |
2,020 | 176.91 |
RFQ |
Bulk | - | Active | Through Hole | 5VDC | DPDT (2 Form C) | 1 A | - | - | Non Latching | - | PC Pin | Sealed - Hermetically | - | 2.7 VDC | 0.22 VDC | 2 ms | 1.5 ms | -65°C ~ 125°C | - | |
|
|
1617028-1HFW1003S01 = HFW 1/2 SIZE RELA |
2,553 | 178.04 |
RFQ |
Bulk | HFW, CII | Active | - | - | DPDT (2 Form C) | 2 A | - | - | - | - | - | Sealed - Hermetically | - | - | - | 4 ms | 4 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) | |
|
|
6-1617532-7HFW1025S03=HFW 1/2 SIZE RELAY |
2,703 | 178.04 |
RFQ |
Bulk | HFW, CII | Active | - | - | DPDT (2 Form C) | 2 A | - | - | - | - | - | Sealed - Hermetically | - | - | - | 4 ms | - | -65°C ~ 125°C | - | |
|
|
7-1617589-6HFW1301D00=RELAY |
3,856 | 178.35 |
RFQ |
Datasheet |
Bulk | HFW | Active | Through Hole | 26.5 ~ 32VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | - | Non Latching | - | PC Pin | Sealed - Hermetically | - | 14 VDC | 1.5 VDC | 4 ms | 4 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) |
|
|
HMS1201S111LHMS1201S111L = M39016/44-035L |
3,170 | 179.26 |
RFQ |
Bulk | HMS, CII | Active | Through Hole | - | DPDT (2 Form C) | 2 A | - | - | - | - | PC Pin | Sealed - Hermetically | - | - | - | 6 ms | 5 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) | |
|
|
JMSWT-18XPJMSWT-18XP = M28776/3-021P |
2,684 | 180.38 |
RFQ |
Bulk | Military, MIL-R-28776/3, MST, CII | Active | Through Hole | 18VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 13.1 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 10 VDC | 0.91 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
JMSPT-5XPJMSPT-5XP = M28776/3-025P |
3,701 | 180.38 |
RFQ |
Bulk | Military, MIL-R-28776/3, MST, CII | Active | Through Hole | 5VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 59.3 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 2.8 VDC | 0.22 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
JMSCT-5XPJMSCT-5XP = M28776/3-033P |
2,452 | 180.38 |
RFQ |
Bulk | Military, MIL-R-28776/3, MST, CII | Active | Through Hole | 5VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 59.3 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 2.8 VDC | 1.5 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
JMSCT-26XPJMSCT-26XP = M28776/3-038P |
3,157 | 180.38 |
RFQ |
Bulk | Military, MIL-R-28776/3, MST, CII | Active | Through Hole | 26.5VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 9.5 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 14.2 VDC | 1.37 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
J1MSWT-5XPJ1MSWT-5XP = M28776/4-017P |
2,430 | 180.38 |
RFQ |
Bulk | 1MS | Active | Through Hole | 5VDC | SPDT (1 Form C) | 1 A | 115VAC, 28VDC - Max | 79.4 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 3 VDC | 0.24 VDC | 2 ms | 4 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
1617168-2JMSCT-12XP = M28776/3-036P |
2,678 | 180.38 |
RFQ |
Bulk | MSC | Active | Through Hole | 12VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 14.1 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 7.4 VDC | 0.63 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
1617168-6JMSCT-18XP = M28776/3-037P |
2,098 | 180.38 |
RFQ |
Bulk | MSC | Active | Through Hole | 18VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 11.3 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 10 VDC | 0.91 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
1617170-4JMSWT-26XP = M28776/3-022P |
2,458 | 180.38 |
RFQ |
Bulk | MSW | Active | Through Hole | 26.5VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 8 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 14.2 VDC | 1.37 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
1617170-6JMSWT-5XP = M28776/3-017P |
3,996 | 180.38 |
RFQ |
Bulk | MSW | Active | Through Hole | 5VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 50 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 2.8 VDC | 0.22 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
9-1617543-9JMSWT-6XP=M28776/3-018P |
2,605 | 180.38 |
RFQ |
Bulk | MSW | Active | Through Hole | 6VDC | DPDT (2 Form C) | 1 A | 115VAC, 28VDC - Max | 30 mA | Non Latching | Diode | PC Pin | Sealed - Hermetically | - | 3.8 VDC | 0.28 VDC | 4 ms | 7.5 ms | -65°C ~ 125°C | Silver Palladium (AgPd), Gold (Au) | |
|
|
2-1617032-7HFW1201S250 = HFW 1/2 SIZE REL |
3,566 | 180.65 |
RFQ |
Bulk | HFW | Active | Through Hole | - | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | - | Non Latching | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 4 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) | |
|
|
1-1617024-0HF1201D00 = HF 1/2 SIZE RELAY |
2,724 | 181.32 |
RFQ |
Bulk | - | Active | Through Hole | 26.5VDC | DPDT (2 Form C) | 2 A | - | - | - | - | PC Pin | - | - | 14 VDC | 1.5 VDC | - | - | -65°C ~ 125°C | - | |
|
|
1617030-6HFW1201B22 = HFW 1/2 SIZE RELA |
2,386 | 181.35 |
RFQ |
Bulk | HFW, CII | Active | Through Hole | 12 ~ 15VDC | DPDT (2 Form C) | 2 A | - | - | - | - | PC Pin | Sealed - Hermetically | - | 6.8 VDC | 0.68 VDC | 4 ms | 4 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) |
