| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | MountingType | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | CoilCurrent | CoilType | Features | TerminationStyle | SealRating | CoilInsulation | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | OperatingTemperature | ContactMaterial |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
K47B334K47B334=RELAY, VACUUM, SPST-NC |
3,813 | 435.14 |
RFQ |
Bulk | K47B | Active | Panel Mount | 26.5VDC | SPST-NC (1 Form B) | 12 A | - | 37.5 mA | Non Latching | - | Wire Leads | - | - | 16 VDC | 1 VDC | 10 ms | 10 ms | -55°C ~ 125°C | - | |
|
|
8-1618239-3K43A-06=RELAY, VACUUM, SPST-NO |
2,973 | 435.14 |
RFQ |
Bulk | K43A | Active | Panel Mount | - | SPST-NO (1 Form A) | 25 A | 10000VDC - Max | - | Non Latching | - | Solder Turret | Sealed - Vacuum | - | - | - | 10 ms | 10 ms | -55°C ~ 125°C | - | |
|
|
1618240-5K43B-15=RELAY, VACUUM, SPST-NC |
3,427 | 435.14 |
RFQ |
Bulk | K43B | Active | Panel Mount | - | SPST-NC (1 Form B) | 25 A | 10000VDC - Max | - | Non Latching | - | Solder Turret | Sealed - Vacuum | - | - | - | 10 ms | 10 ms | -55°C ~ 125°C | - | |
|
|
1618013-7PD10P532=RELAY, VACUUM, SPST |
2,216 | 0.00 |
RFQ |
Bulk | PD | Active | Chassis Mount | 125VDC | SPST-NO (1 Form A) | 25 A | 320VDC - Max | 26.6 mA | Latching, Single Coil | - | PC Pin | Sealed - Vacuum | - | 80 VDC | 5 VDC | 10 ms | 10 ms | -40°C ~ 85°C | ||
|
|
1618013-8PD10P534=RELAY, VACUUM, SPST |
2,797 | 0.00 |
RFQ |
Bulk | PD | Active | Chassis Mount | 125VDC | SPST-NO (1 Form A) | 25 A | 320VDC - Max | 26.6 mA | Latching, Single Coil | - | PC Pin | Sealed - Vacuum | - | 80 VDC | 5 VDC | 10 ms | 10 ms | -40°C ~ 85°C | ||
|
|
2-1618241-7K81B-09=RELAY, VACUUM, SPST-NC |
3,338 | 435.74 |
RFQ |
Bulk | K81B | Active | - | - | SPST-NC (1 Form B) | - | 10000VDC - Max | - | Non Latching | - | - | Sealed - Vacuum | - | - | - | 10 ms | 10 ms | -55°C ~ 85°C | - | |
|
|
K81B275K81B275=RELAY, VACUUM, SPST-NC |
2,301 | 435.74 |
RFQ |
Bulk | K81B | Active | Through Hole | 12VDC | SPST-NC (1 Form B) | 30 A | 10000VDC - Max | 171.4 mA | Non Latching | - | PC Pin | Sealed - Vacuum | - | 8 VDC | 0.5 VDC | 10 ms | 10 ms | -55°C ~ 85°C | - | |
|
|
PD5AC47PD5AC47=RELAY, VACUUM, SPST-NO |
3,491 | 438.13 |
RFQ |
Bulk | PD | Active | Panel Mount | 125VDC | SPST-NO (1 Form A) | 15 A | - | 26.6 mA | Non Latching | - | - | Sealed - Vacuum | - | 80 VDC | 5 VDC | 10 ms | 10 ms | -40°C ~ 85°C | - | |
|
|
K81C545K81C545=RELAY, VACUUM, SPDT |
2,282 | 439.23 |
RFQ |
Datasheet |
Bulk | K81C | Active | Through Hole | 115VDC | SPDT (1 Form C) | 30 A | 10000VDC - Max | 24.5 mA | Non Latching | - | PC Pin, Wire Leads | Sealed - Vacuum | - | 80 VDC | 5 VDC | 10 ms | 10 ms | -55°C ~ 85°C | - |
|
|
1617053-7SF5A5201J01 = SF5A RELAY |
2,429 | 442.05 |
RFQ |
Bulk | SF5 | Active | Through Hole | 26.5VDC | DPDT (2 Form C) | 5 A | 115VAC, 28VDC - Max | 10.6 mA | Non Latching | - | PC Pin | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | Silver (Ag), Gold (Au) | |
|
|
PD5AC57PD5AC57=RELAY, VACUUM, SPST-NO |
2,326 | 442.64 |
RFQ |
Bulk | PD | Active | Panel Mount | 125VDC | SPST-NO (1 Form A) | 15 A | - | 26.6 mA | Non Latching | - | Stud | Sealed - Vacuum | - | 80 VDC | 5 VDC | 10 ms | 10 ms | -40°C ~ 85°C | - | |
|
|
K43A232K43A232=RELAY, VACUUM, SPST-NO |
2,343 | 442.65 |
RFQ |
Bulk | K43A | Active | Chassis Mount | 12VDC | SPST-NO (1 Form A) | 25 A | 10000VDC - Max | 171.4 mA | Non Latching | - | Wire Leads | Sealed - Vacuum | - | 8 VDC | 0.5 VDC | 10 ms | 10 ms | -55°C ~ 125°C | - | |
|
|
K43A332K43A332=RELAY, VACUUM, SPST-NO |
2,737 | 442.65 |
RFQ |
Bulk | K43A | Active | Chassis Mount | 26.5VDC | SPST-NO (1 Form A) | 25 A | 10000VDC - Max | 91.4 mA | Non Latching | - | Wire Leads | Sealed - Vacuum | - | 16 VDC | 1 VDC | 10 ms | 10 ms | -55°C ~ 125°C | - | |
|
|
K43B332K43B332=RELAY, VACUUM, SPST-NC |
2,657 | 442.65 |
RFQ |
Datasheet |
Bulk | K43B | Active | Chassis Mount | 26.5VDC | SPST-NC (1 Form B) | 25 A | 10000VDC - Max | 91.4 mA | Non Latching | - | Wire Leads | Sealed - Vacuum | - | 16 VDC | 1 VDC | 10 ms | 10 ms | -55°C ~ 125°C | - |
|
|
4-1617003-1B07B935BZ1-1023 = 07 RELAY |
3,527 | 406.83 |
RFQ |
Bulk,Bulk | B07 | Active | Through Hole | 18VDC | DPDT (2 Form C) | 10 A | 115VAC, 28VDC - Max | 105.9 mA | Non Latching | - | PC Pin | Sealed - Hermetically | - | 9.7 VDC | 1.15 VDC | 10 ms | 10 ms | -65°C ~ 125°C | Silver Cadmium Oxide (AgCdO) | |
|
|
1423156-3RELAY 4PDT 10A 120V |
3,390 | 444.89 |
RFQ |
Bulk | GP, AGASTAT | Active | Socketable | 120VAC | 4PDT (4 Form C) | 10 A | - | - | - | - | Plug In | - | - | - | - | 15 ms | 30 ms | 0°C ~ 60°C | Silver (Ag) | |
|
PD5A235RELAY GEN PURPOSE SPST 5A 12V |
3,732 | 448.04 |
RFQ |
Bulk | PD5, KILOVAC | Active | Through Hole | 12VDC | SPST-NO (1 Form A) | 5 A | 1800VDC - Max | - | Non Latching | - | PC Pin | Sealed - Vacuum | - | 8 VDC | 0.5 VDC | 10 ms | 10 ms | -40°C ~ 85°C | - | |
|
PD5A335RELAY GEN PURPOSE SPST 5A 24V |
2,492 | 448.04 |
RFQ |
Bulk | PD5, KILOVAC | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 5 A | 1800VDC - Max | - | Non Latching | - | PC Pin | Sealed - Vacuum | - | 16 VDC | 1 VDC | 10 ms | 10 ms | -40°C ~ 85°C | - | |
|
|
5-1618239-9K41P-01=RELAY VACUUM SPST LATC |
2,393 | 450.86 |
RFQ |
Bulk | K41P | Active | Panel Mount | - | SPST-NO (1 Form A) | 30 A | 5000VDC - Max | - | Latching, Single Coil | - | Solder Turret | Sealed - Vacuum | - | - | - | 6 ms | - | -55°C ~ 125°C | - | |
|
K43A732RELAY GEN PURPOSE SPST 25A 12V |
3,457 | 452.11 |
RFQ |
Bulk | K43, KILOVAC | Active | Panel Mount | 12VDC | SPST-NO (1 Form A) | 25 A | 10000VDC - Max | - | Non Latching | - | Solder Turret | - | - | 8 VDC | 0.5 VDC | 10 ms | 10 ms | -55°C ~ 125°C | - |
