| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DrivenConfiguration | ChannelType | NumberofDrivers | GateType | Voltage-Supply | LogicVoltage-VILVIH | Current-PeakOutput(SourceSink) | InputType | HighSideVoltage-Max(Bootstrap) | Rise/FallTime(Typ) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IR2136JTRIC GATE DRVR HALF-BRIDGE 44PLCC |
2,049 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 3V | 200mA, 350mA | Inverting | 600 V | 125ns, 50ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR2136STRIC GATE DRVR HALF-BRIDGE 28SOIC |
3,491 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 3V | 200mA, 350mA | Inverting | 600 V | 125ns, 50ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR21814STRIC GATE DRVR HALF-BRIDGE 14SOIC |
3,306 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.7V | 1.9A, 2.3A | Non-Inverting | 600 V | 40ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR2183STRIC GATE DRVR HALF-BRIDGE 8SOIC |
2,058 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.7V | 1.9A, 2.3A | Inverting, Non-Inverting | 600 V | 40ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR2301IC GATE DRV HI-SIDE/LO-SIDE 8DIP |
2,442 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | High-Side or Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 5V ~ 20V | 0.8V, 2.9V | 200mA, 350mA | Non-Inverting | 600 V | 130ns, 50ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IR2302IC GATE DRVR HALF-BRIDGE 8DIP |
2,871 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Synchronous | 2 | IGBT, N-Channel MOSFET | 5V ~ 20V | 0.8V, 2.9V | 200mA, 350mA | Non-Inverting | 600 V | 130ns, 50ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
98-0343IC GATE DRVR HALF-BRIDGE 8SOIC |
3,029 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 5V ~ 20V | 0.8V, 2.9V | 200mA, 350mA | Non-Inverting | 600 V | 130ns, 50ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2302SIC GATE DRVR HALF-BRIDGE 8SOIC |
2,534 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Synchronous | 2 | IGBT, N-Channel MOSFET | 5V ~ 20V | 0.8V, 2.9V | 200mA, 350mA | Non-Inverting | 600 V | 130ns, 50ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2301STRIC GATE DRVR HI/LOW SIDE 8SOIC |
3,582 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | High-Side or Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 5V ~ 20V | 0.8V, 2.9V | 200mA, 350mA | Non-Inverting | 600 V | 130ns, 50ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2085SIC GATE DRVR HALF-BRIDGE 8SOIC |
2,310 | 0.00 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q100 | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 10V ~ 15V | - | 1A, 1A | RC Input Circuit | 100 V | 40ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2085STRIC GATE DRVR HALF-BRIDGE 8SOIC |
2,804 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q100 | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 10V ~ 15V | - | 1A, 1A | RC Input Circuit | 100 V | 40ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2304IC GATE DRVR HALF-BRIDGE 8DIP |
2,371 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.3V | 60mA, 130mA | Non-Inverting | 600 V | 200ns, 100ns | -40°C ~ 150°C (TJ) | Through Hole |
|
IR3101IC GATE DRVR HALF-BRIDGE 11SIP |
2,282 | 0.00 |
RFQ |
Datasheet |
Tube | iMOTION™ | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.9V | - | Non-Inverting | 500 V | - | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IR2011IC GATE DRV HI-SIDE/LO-SIDE 8DIP |
2,341 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | High-Side or Low-Side | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.7V, 2.2V | 1A, 1A | Inverting | 200 V | 35ns, 20ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IR2011SIC GATE DRVR HI/LOW SIDE 8SOIC |
2,283 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | High-Side or Low-Side | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.7V, 2.2V | 1A, 1A | Inverting | 200 V | 35ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2011STRIC GATE DRVR HI/LOW SIDE 8SOIC |
2,391 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | High-Side or Low-Side | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.7V, 2.2V | 1A, 1A | Inverting | 200 V | 35ns, 20ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR22141SSIC GATE DRVR HALF-BRIDGE 24SSOP |
2,031 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Independent | 2 | IGBT | 11.5V ~ 20V | 0.8V, 2V | 2A, 3A | Non-Inverting | 1200 V | 24ns, 7ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IR2214SSIC GATE DRVR HALF-BRIDGE 24SSOP |
3,670 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Independent | 2 | IGBT | 11.5V ~ 20V | 0.8V, 2V | 2A, 3A | Non-Inverting | 1200 V | 24ns, 7ns | -40°C ~ 150°C (TJ) | Surface Mount |
|
IR2110-1PBFIC GATE DRVR HALF-BRIDGE 14DIP |
2,654 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 3.3V ~ 20V | 6V, 9.5V | 2A, 2A | Non-Inverting | 500 V | 25ns, 17ns | -40°C ~ 150°C (TJ) | Through Hole |
|
|
IR3103IC GATE DRVR HALF-BRIDGE 11SIP |
3,597 | 0.00 |
RFQ |
Datasheet |
Tube | iMOTION™ | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.9V | - | Non-Inverting | 500 V | - | -40°C ~ 150°C (TJ) | Through Hole |
