| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
H11F1OPTOISOLTR 5.3KV PHOTO FET 6-DIP |
3,118 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | - | - | 25µs, 25µs (Max) | - | DC | MOSFET | 30V | - | 1.3V | 60 mA | - | -55°C ~ 100°C | Through Hole |
|
4N36OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,606 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 100% @ 10mA | - | 2µs, 2µs | - | DC | Transistor with Base | 30V | - | 1.18V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
MCT2OPTOISO 5.3KV TRANS W/BASE 6DIP |
2,678 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 20% @ 10mA | - | 1.1µs, 50µs | - | DC | Transistor with Base | 30V | 50mA | 1.25V | 100 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT2EOPTOISO 5.3KV TRANS W/BASE 6DIP |
2,572 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 20% @ 10mA | - | 1.1µs, 50µs | - | DC | Transistor with Base | 30V | 50mA | 1.25V | 100 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT26TRANSISTOR OPTOISOLATOR |
2,825 | 0.00 |
RFQ |
Tube | - | Obsolete | 1 | 5300Vrms | 6% @ 10mA | - | - | - | DC | Transistor with Base | 30V | 50mA | - | - | 400mV | - | Through Hole | |
|
MCT4ROPTOISO 1KV TRANSISTOR TO206AA |
3,570 | 0.00 |
RFQ |
Datasheet |
- | - | Obsolete | 1 | 1000VDC | 15% @ 10mA | - | - | - | DC | Transistor | 30V | - | 1.3V | 40 mA | 500mV | -55°C ~ 125°C | Through Hole |
|
|
MCT4OPTOISO 1KV TRANSISTOR TO206AA |
2,624 | 0.00 |
RFQ |
Datasheet |
- | - | Obsolete | 1 | 1000VDC | 15% @ 10mA | - | - | - | DC | Transistor | 30V | - | 1.3V | 40 mA | 500mV | -55°C ~ 125°C | Through Hole |
|
|
MCT210OPTOISO 5.3KV TRANS W/BASE 6DIP |
2,408 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 150% @ 10mA | - | 1µs, 50µs | 1µs, 11µs | DC | Transistor with Base | 30V | 50mA | 1.33V | 100 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
CNY171300OPTOISO 5.3KV TRANS W/BASE 6DIP |
2,170 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 40% @ 10mA | 80% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
CNY172300OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,627 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 63% @ 10mA | 125% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
CNY173300OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,622 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 100% @ 10mA | 200% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
CNY173OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,231 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 100% @ 10mA | 200% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
CNY174300OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,290 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 160% @ 10mA | 320% @ 10mA | 2µs, 3µs | 1µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.35V | 100 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
H11A1300OPTOISO 5.3KV TRANS W/BASE 6DIP |
2,756 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 50% @ 10mA | - | 2µs, 2µs | - | DC | Transistor with Base | 30V | - | 1.18V | 100 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
H11D1300OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,910 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 20% @ 10mA | - | 5µs, 5µs | - | DC | Transistor with Base | 300V | 100mA | 1.15V | 80 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
H11D2300OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,282 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 20% @ 10mA | - | 5µs, 5µs | - | DC | Transistor with Base | 300V | 100mA | 1.15V | 80 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT2200300OPTOISO 5.3KV TRANS W/BASE 6DIP |
2,680 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 20% @ 10mA | - | 2µs, 2µs | - | DC | Transistor with Base | 30V | 50mA | 1.25V | 100 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT5200OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,554 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 75% @ 10mA | - | 1.6µs, 18µs | 1.3µs, 16µs | DC | Transistor with Base | 30V | 150mA | 1.25V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT5201OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,729 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 120% @ 5mA | - | 3µs, 12µs | 2.5µs, 16µs | DC | Transistor with Base | 30V | 150mA | 1.25V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
MCT5210OPTOISO 5.3KV TRANS W/BASE 6DIP |
3,985 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5300Vrms | 70% @ 3mA | - | 10µs, 400ns | - | DC | Transistor with Base | 30V | 150mA | 1.25V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
