| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP3910(C20,EPHOTOVOLTAIC COUPLER; HIGH VOC; |
3,732 | 1.93 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 5000Vrms | - | - | 300µs, 100µs | - | DC | Photovoltaic | 24V | - | 3.3V | 30 mA | - | -40°C ~ 125°C | Surface Mount |
|
|
TLP590B(C,F)OPTOISOLATOR 2.5KV PHVOLT 6-DIP |
3,157 | 2.27 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 2500Vrms | - | - | 200µs, 1ms | - | DC | Photovoltaic | 7V | 12µA | 1.4V | 50 mA | - | -55°C ~ 125°C | Through Hole |
|
TLP759(D4-LF1,J,F)PHOTOCOUPLER LOGIC 8DIP GW |
2,384 | 0.00 |
RFQ |
Datasheet |
Tube | - | Last Time Buy | 1 | 5000Vrms | 20% @ 16mA | - | 200ns, 300ns | - | DC | Transistor | 20V | 8mA | 1.65V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
TLP190B(U,C,F)OPTOISOLTR 2.5KV PHVOLT 6-MFSOP |
2,976 | 0.00 |
RFQ |
Datasheet |
Tube | - | Last Time Buy | 1 | 2500Vrms | - | - | 200µs, 1ms | - | DC | Photovoltaic | 8V | 12µA | 1.4V | 50 mA | - | -40°C ~ 85°C | Surface Mount |
|
TLP627(F)OPTOISOLTR 5KV DARLINGTON 4-DIP |
2,857 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 1000% @ 1mA | - | 50µs, 15µs | 40µs, 15µs | DC | Darlington | 300V | 150mA | 1.15V | 60 mA | 1.2V | -55°C ~ 100°C | Through Hole |
|
|
TLP127TPRUFOPTOISOLTR 2.5KV DARLNG 6-MFSOP |
3,464 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 | 2500Vrms | 1000% @ 1mA | - | 50µs, 15µs | 40µs, 15µs | DC | Darlington | 300V | 150mA | 1.15V | 50 mA | 1.2V | -55°C ~ 100°C | Surface Mount |
|
4N32(SHORT,F)OPTOISO 2.5KV DARL W/BASE 6DIP |
3,642 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 500% @ 10mA | - | 5µs, 100µs (Max) | - | DC | Darlington with Base | 30V | 100mA | 1.15V | 80 mA | 1V | -55°C ~ 100°C | Through Hole |
|
|
4N35(SHORT,F)OPTOISO 2.5KV TRANS W/BASE 6DIP |
2,499 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 40% @ 10mA | - | 3µs, 3µs | - | DC | Transistor with Base | 30V | 100mA | 1.15V | 60 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
|
4N38(SHORT,F)OPTOISO 2.5KV TRANS W/BASE 6DIP |
3,569 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 10% @ 10mA | - | 3µs, 3µs | - | DC | Transistor with Base | 80V | 100mA | 1.15V | 80 mA | 1V | -55°C ~ 100°C | Through Hole |
|
6N136FOPTOISO 2.5KV TRANS W/BASE 8DIP |
2,346 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 19% @ 16mA | - | 200ns, 500ns | - | DC | Transistor with Base | 15V | 8mA | 1.65V | 25 mA | - | -55°C ~ 100°C | Through Hole |
|
|
6N138FOPTOISO 2.5KV DARL W/BASE 8DIP |
3,024 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 300% @ 1.6mA | - | 1µs, 4µs | - | DC | Darlington with Base | 18V | 60mA | 1.65V | 20 mA | - | 0°C ~ 70°C | Through Hole |
|
|
6N139(F)OPTOISO 2.5KV DARL W/BASE 8DIP |
2,082 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 500% @ 1.6mA | - | 200ns, 1µs | - | DC | Darlington with Base | 18V | 60mA | 1.65V | 20 mA | - | 0°C ~ 70°C | Through Hole |
|
|
TLP126(F)OPTOISOLTR 3.75KV TRANS 6-MFSOP |
3,339 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 3750Vrms | 100% @ 1mA | 1200% @ 1mA | 10µs, 8µs | 8µs, 8µs | AC, DC | Transistor | 80V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
TLP137(F)OPTOISO 3.75KV TRANS 6-MFSOP |
2,448 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 3750Vrms | 100% @ 1mA | 1200% @ 1mA | 10µs, 8µs | 8µs, 8µs | DC | Transistor with Base | 80V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
TLP280-4(GB,J,F)OPTOISO 2.5KV 4CH TRANS 16-SOP |
2,224 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 4 | 2500Vrms | 100% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | AC, DC | Transistor | 80V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
|
TLP331(F)OPTOISO 5KV TRANS W/BASE 6DIP |
3,777 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 100% @ 1mA | 1200% @ 1mA | 10µs, 8µs | 8µs, 8µs | DC | Transistor with Base | 55V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
TLP332(F)OPTOISOLATR 5KV TRANSISTOR 6-DIP |
2,211 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 100% @ 1mA | 1200% @ 1mA | 10µs, 8µs | 8µs, 8µs | DC | Transistor | 55V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
|
TLP371FOPTOISO 5KV DARL W/BASE 6DIP |
3,725 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 1000% @ 1mA | - | 50µs, 15µs | 40µs, 15µs | DC | Darlington with Base | 300V | 150mA | 1.15V | 60 mA | 1.2V | -55°C ~ 100°C | Through Hole |
.jpg)
|
TLP371(TP1,F)OPTOISO 5KV DARL W/BASE 6SMD |
3,990 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 | 5000Vrms | 1000% @ 1mA | - | 50µs, 15µs | 40µs, 15µs | DC | Darlington with Base | 300V | 150mA | 1.15V | 60 mA | 1.2V | -55°C ~ 100°C | Surface Mount |
|
TLP504A-2(GB,F)OPTOISO 2.5KV 4CH TRANS 16-DIP |
2,778 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 4 | 2500Vrms | 100% @ 5mA | 600% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 55V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Through Hole |
