| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LHC1-4080-1203LED COB LUXEON NEU WHITE SQUARE |
2,963 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 1300lm (Typ) | 300mA | 85°C | 35.5V | 122 lm/W | 600mA | 80 | 125° | - | 19.00mm L x 16.00mm W | 1.50mm | 9.00mm Dia |
|
LHC1-4080-1204LED COB LUXEON NEU WHITE SQUARE |
3,562 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 1950lm (Typ) | 450mA | 85°C | 35.5V | 122 lm/W | 900mA | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
LHC1-4080-1205LED COB LUXEON NEU WHITE SQUARE |
2,921 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 2600lm (Typ) | 600mA | 85°C | 35.5V | 122 lm/W | 1.2A | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
|
LHC1-5080-1203LED COB LUXEON COOL WHITE SQUARE |
3,921 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 1325lm (Typ) | 300mA | 85°C | 35.5V | 124 lm/W | 600mA | 80 | 125° | - | 19.00mm L x 16.00mm W | 1.50mm | 9.00mm Dia |
|
|
LHC1-5080-1204LED COB LUXEON COOL WHITE SQUARE |
2,843 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 1975lm (Typ) | 450mA | 85°C | 35.5V | 124 lm/W | 900mA | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
|
LHC1-5080-1205LED COB LUXEON COOL WHITE SQUARE |
2,450 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 2650lm (Typ) | 600mA | 85°C | 35.5V | 124 lm/W | 1.2A | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
LHC1-5080-1208LED COB LUXEON COOL WHITE SQUARE |
3,721 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 3950lm (Typ) | 900mA | 85°C | 35.5V | 124 lm/W | 1.8A | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 17.00mm Dia |
|
|
LHC1-4080-1208LED COB LUXEON NEU WHITE SQUARE |
3,255 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 3900lm (Typ) | 900mA | 85°C | 35.5V | 122 lm/W | 1.8A | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 17.00mm Dia |
|
|
LHC1-2780-1205LED COB LUXEON WARM WHITE SQUARE |
3,114 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 2250lm (Typ) | 600mA | 85°C | 35.5V | 106 lm/W | 1.2A | 80 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
|
LHC1-3090-1204LED COB LUXEON WARM WHITE SQUARE |
3,804 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 1475lm (Typ) | 450mA | 85°C | 35.5V | 93 lm/W | 900mA | 90 | 125° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
|
LHC1-3580-1205LED COB LUXEON WARM WHITE SQUARE |
2,859 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 2550lm (Typ) | 600mA | 85°C | 35.5V | 119 lm/W | 1.2A | 80 | 100° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
|
LHC1-3580-1208LED COB LUXEON WARM WHITE SQUARE |
3,060 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 3800lm (Typ) | 900mA | 85°C | 35.5V | 119 lm/W | 1.8A | 80 | 100° | - | 24.00mm L x 20.00mm W | 1.50mm | 15.00mm Dia |
|
|
LHC1-4070-1203LED COB LUXEON NEU WHITE SQUARE |
2,726 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 5-Step MacAdam Ellipse | - | Square | 1375lm (Typ) | 300mA | 85°C | 35.5V | 130 lm/W | 600mA | 70 | 100° | - | 19.00mm L x 16.00mm W | 1.50mm | 9.00mm Dia |
|
|
LHC1-4070-1204LED COB LUXEON NEU WHITE SQUARE |
2,448 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 5-Step MacAdam Ellipse | - | Square | 2050lm (Typ) | 450mA | 85°C | 35.5V | 130 lm/W | 900mA | 70 | 100° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
|
LXS8-PW30-0024NLED MOD LUXEON S3000 WARM WHT |
2,064 | 0.00 |
RFQ |
Datasheet |
Tray | LUXEON S3000 | Obsolete | LED Module | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Rectangle | 4100lm (Typ) | 700mA | 85°C | 67.5V | 87 lm/W | 1.05A | 80 | 105° | - | 17.60mm L x 32.60mm W | 1.31mm | 13.50mm Dia |
|
|
LXS8-PW30-0041NLED MOD LUXEON S5000 WARM WHT |
2,976 | 0.00 |
RFQ |
Datasheet |
Tray | LUXEON S5000 | Obsolete | LED Module | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Rectangle | 7000lm (Typ) | 700mA | 85°C | 115V | 87 lm/W | 1.05A | 80 | 105° | - | 20.90mm L x 34.15mm W | 1.31mm | 17.00mm Dia |
|
|
LXS8-PW30-4LED MOD LUXEON S1000 WARM WHT |
2,687 | 0.00 |
RFQ |
Tray | LUXEON S1000 | Obsolete | LED Module | White, Warm | 3000K 4-Step MacAdam Ellipse | - | Rectangle | 1390lm (Typ) | 700mA | 85°C | 25.6V | 78 lm/W | 900mA | 80 | 105° | - | 12.73mm L x 11.73mm W | 6.09mm | 8.06mm Dia | |
|
|
LXS8-PW35-0017LED MOD LUXEON S2000 WARM WHT |
2,506 | 0.00 |
RFQ |
Datasheet |
Tray | LUXEON S2000 | Obsolete | LED Module | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Rectangle | 3200lm (Typ) | 700mA | 85°C | 47V | 97 lm/W | 1.05A | 80 | 105° | With Connector | 14.40mm L x 30.90mm W | 5.21mm | 10.50mm Dia |
|
|
LHC1-2790-1203LED COB LUXEON WARM WHITE SQUARE |
3,793 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 950lm (Typ) | 300mA | 85°C | 35.5V | 90 lm/W | 600mA | 90 | 100° | - | 19.00mm L x 16.00mm W | 1.50mm | 9.00mm Dia |
|
|
LHC1-2790-1204LED COB LUXEON WARM WHITE SQUARE |
3,083 | 0.00 |
RFQ |
Datasheet |
Tube | LUXEON CoB | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 1425lm (Typ) | 450mA | 85°C | 35.5V | 90 lm/W | 900mA | 90 | 100° | - | 24.00mm L x 20.00mm W | 1.50mm | 13.00mm Dia |
