| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CXM-27-27-95-36-AA00-F2-2LED COB WHT 26.5MM 2700K 95CRI |
2,469 | 19.86 |
RFQ |
Datasheet |
Tray | CXM-27 | Active | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Square | 5148lm (5015lm ~ 5280lm) | 1.8A | 85°C | 35V | 82 lm/W | 2.7A | 95 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.50mm Dia |
|
|
CXM-27-30-95-36-AA00-F2-2LED COB WHT 26.5MM 3000K 95CRI |
2,760 | 19.86 |
RFQ |
Datasheet |
Tray | CXM-27 | Active | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Square | 5820lm (5670lm ~ 5970lm) | 1.8A | 85°C | 35V | 92 lm/W | 2.7A | 95 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.50mm Dia |
|
CHM-27-27-95-36-AA00-F2-3LED COB CHM27 WARM WHITE SQUARE |
3,811 | 20.01 |
RFQ |
Datasheet |
Tray | CHM-27 | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 7140lm (Typ) | 2.7A | 85°C | 35V | 76 lm/W | 5.4A | 95 | 120° | - | 27.90mm L x 27.90mm W | 1.37mm | 26.50mm Dia |
|
|
CHM-27-30-95-36-AA00-F2-3LED COB CHM27 WARM WHITE SQUARE |
2,676 | 20.01 |
RFQ |
Datasheet |
Tray | CHM-27 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 8085lm (Typ) | 2.7A | 85°C | 35V | 86 lm/W | 5.4A | 95 | 120° | - | 27.90mm L x 27.90mm W | 1.37mm | 26.50mm Dia |
|
CHM-27-27-95-36-AB00-F2-3LED COB |
3,948 | 20.01 |
RFQ |
Datasheet |
Tray | CHM-27 | Not For New Designs | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 7140lm (Typ) | 2.7A | 85°C | 35V | 76 lm/W | 4A | 95 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.50mm Dia |
|
|
CHM-27-30-95-36-AB00-F2-3LED COB |
3,712 | 20.01 |
RFQ |
Datasheet |
Tray | CHM-27 | Not For New Designs | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 8085lm (Typ) | 2.7A | 85°C | 35V | 86 lm/W | 4A | 95 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.50mm Dia |
|
CXM-18-30-80-36-AA30-F4-3LED COB 3000K SQUARE |
3,174 | 20.17 |
RFQ |
Datasheet |
Tray | CXM-18 Gen3 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 4605lm (Typ) | 900mA | 85°C | 34V | 150 lm/W | 2A | 80 | 120° | - | 21.50mm L x 21.50mm W | 1.37mm | 17.50mm Dia |
|
|
CXM-27-27-80-54-AC30-F4-3LED COB |
2,491 | 20.84 |
RFQ |
Tray | CXM-11 Gen3 | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | - | - | 85°C | 51V | - | 3.2A | 80 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.49mm Dia | |
|
|
CXM-27-27-90-54-AC30-F4-3LED COB |
3,515 | 20.84 |
RFQ |
Tray | CXM-11 Gen3 | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | - | - | 85°C | 51V | - | 3.2A | 90 | 120° | - | 31.50mm L x 31.50mm W | 1.37mm | 26.49mm Dia | |
|
CXM-27-30-80-54-AA30-F4-3LED COB 3000K SQUARE |
2,104 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 12400lm (Typ) | 1.6A | 85°C | 51V | 152 lm/W | 3.2A | 80 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-30-90-54-AA30-F4-3LED COB 3000K SQUARE |
3,972 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 10430lm (Typ) | 1.6A | 85°C | 51V | 128 lm/W | 3.2A | 90 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-35-80-54-AA30-F4-3LED COB 3500K SQUARE |
3,551 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 12770lm (Typ) | 1.6A | 85°C | 51V | 156 lm/W | 3.2A | 80 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-35-90-54-AA30-F4-3LED COB 3500K SQUARE |
3,837 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 10640lm (Typ) | 1.6A | 85°C | 51V | 130 lm/W | 3.2A | 90 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-40-70-54-AA30-F4-3LED COB 4000K SQUARE |
2,532 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 13875lm (Typ) | 1.6A | 85°C | 51V | 170 lm/W | 3.2A | 70 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-40-80-54-AA30-F4-3LED COB 4000K SQUARE |
3,148 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 12935lm (Typ) | 1.6A | 85°C | 51V | 159 lm/W | 3.2A | 80 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-40-90-54-AA30-F4-3LED COB 4000K SQUARE |
2,147 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 11220lm (Typ) | 1.6A | 85°C | 51V | 138 lm/W | 3.2A | 90 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-50-70-54-AA30-F4-5LED COB 5000K SQUARE |
3,288 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Cool | 5000K 5-Step MacAdam Ellipse | - | Square | 14105lm (Typ) | 1.6A | 85°C | 51V | 173 lm/W | 3.2A | 70 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-50-80-54-AA30-F4-5LED COB 5000K SQUARE |
3,999 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Cool | 5000K 5-Step MacAdam Ellipse | - | Square | 13025lm (Typ) | 1.6A | 85°C | 51V | 160 lm/W | 3.2A | 80 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-50-90-54-AA30-F4-5LED COB 5000K SQUARE |
2,130 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Cool | 5000K 5-Step MacAdam Ellipse | - | Square | 11280lm (Typ) | 1.6A | 85°C | 51V | 138 lm/W | 3.2A | 90 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
|
|
CXM-27-65-70-54-AA30-F4-5LED COB 6500K SQUARE |
2,653 | 20.84 |
RFQ |
Datasheet |
Tray | CXM-27 Gen3 | Active | Chip On Board (COB) | White, Cool | 6500K 5-Step MacAdam Ellipse | - | Square | 14120lm (Typ) | 1.6A | 85°C | 51V | 173 lm/W | 3.2A | 70 | 120° | - | 31.50mm L x 31.50mm W | - | 26.50mm Dia |
