| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BXRC-50G2001-D-74-SEVERO SE 13D COOL WHITE LED ARRAY |
2,564 | 4.10 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Round | 2046lm (Typ) | 500mA | 85°C | 30.9V | 132 lm/W | 1A | 90 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-57C2001-D-74-SEVERO SE 13D COOL WHITE LED ARRAY |
3,437 | 4.10 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Cool | 5700K 4-Step MacAdam Ellipse | - | Round | 2476lm (Typ) | 500mA | 85°C | 30.9V | 160 lm/W | 1A | 70 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-57E2001-D-74-SEVERO SE 13D COOL WHITE LED ARRAY |
3,496 | 4.10 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Cool | 5700K 4-Step MacAdam Ellipse | - | Round | 2375lm (Typ) | 500mA | 85°C | 30.9V | 154 lm/W | 1A | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-65C2001-D-74-SEVERO SE 13D COOL WHITE LED ARRAY |
3,166 | 4.10 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Cool | 6500K 4-Step MacAdam Ellipse | - | Round | 2519lm (Typ) | 500mA | 85°C | 30.9V | 163 lm/W | 1A | 70 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-65E2001-D-74-SEVERO SE 13D COOL WHITE LED ARRAY |
3,342 | 4.10 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Cool | 6500K 4-Step MacAdam Ellipse | - | Round | 2418lm (Typ) | 500mA | 85°C | 30.9V | 156 lm/W | 1A | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
BXRE-40E2000-C-83V13C NEUTRAL WHITE LED ARRAY |
3,215 | 4.11 |
RFQ |
Datasheet |
Tube | V Series™ Gen 8 | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 3078lm (Typ) | 500mA | 25°C | 33.4V | 183 lm/W | - | 80 | - | - | - | - | 13.00mm Dia |
|
BXRE-30E3000-D-83V15D WARM WHITE LED ARRAY |
2,046 | 4.11 |
RFQ |
Datasheet |
Tube | V Series™ Gen 8 | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 3010lm (Typ) | 500mA | 25°C | 33.7V | 178 lm/W | - | 80 | - | - | - | - | 15.00mm Dia |
|
BXRC-27H2000-B-73-SELED COB VERO SE 2700K ROUND |
3,793 | 4.12 |
RFQ |
Datasheet |
Tray | Décor Series™ Vero® SE 13 | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Round | 1611lm (Typ) | 450mA | 85°C | 34.1V | 105 lm/W | 900mA | 97 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
BXRC-30G200C-B-73-SELED COB VERO 13 SE 3000K ROUND |
2,870 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 1672lm (Typ) | 450mA | 85°C | 34.1V | 109 lm/W | 900mA | 90 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-27E2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
2,970 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 2128lm (Typ) | 450mA | 85°C | 33.9V | 139 lm/W | 900mA | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-27G2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
2,241 | 4.12 |
RFQ |
Datasheet |
Tray | Gen 7 Vero® 13 Array | Active | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 1776lm (Typ) | 450mA | 85°C | 33.9V | 116 lm/W | 900mA | 90 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-30A2001-B-73-SEVERO SE 13B WARM WHITE LED ARRAY |
2,295 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 1663lm (Typ) | 450mA | 85°C | 33.9V | 109 lm/W | 900mA | 93 (Typ) | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-30E2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
2,752 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 2213lm (Typ) | 450mA | 85°C | 33.9V | 145 lm/W | 900mA | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-30G2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
2,873 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 1846lm (Typ) | 450mA | 85°C | 33.9V | 121 lm/W | 900mA | 90 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-30H2000-B-73-SEVERO SE 13B WARM WHITE LED ARRAY |
2,112 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 1649lm (Typ) | 450mA | 85°C | 33.9V | 108 lm/W | 900mA | 97 (Typ) | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-35A2001-B-73-SEVERO SE 13B WARM WHITE LED ARRAY |
3,939 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Round | 1790lm (Typ) | 450mA | 85°C | 33.9V | 117 lm/W | 900mA | 93 (Typ) | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-35E2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
3,360 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3500K 2-Step MacAdam Ellipse | - | Round | 2283lm (Typ) | 450mA | 85°C | 33.9V | 150 lm/W | 900mA | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-35G2000-B-72-SEVERO SE 13B WARM WHITE LED ARRAY |
2,981 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Warm | 3500K 2-Step MacAdam Ellipse | - | Round | 1903lm (Typ) | 450mA | 85°C | 33.9V | 125 lm/W | 900mA | 90 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-40A2001-B-73-SEVERO SE 13B NEUTRAL WHITE LED AR |
2,826 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Round | 1917lm (Typ) | 450mA | 85°C | 33.9V | 126 lm/W | 900mA | 93 (Typ) | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
|
|
BXRC-40E2000-B-72-SEVERO SE 13B NEUTRAL WHITE LED AR |
3,188 | 4.12 |
RFQ |
Datasheet |
Tray | Vero® SE 13 Array | Active | Chip On Board (COB) | White, Neutral | 4000K 2-Step MacAdam Ellipse | - | Round | 2297lm (Typ) | 450mA | 85°C | 33.9V | 151 lm/W | 900mA | 80 | 120° | - | 36.20mm Dia | 3.60mm | 13.40mm Dia |
