| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BXRC-65C10K1-C-83VERO 29C COOL WHITE LED ARRAY |
3,616 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 6500K 3-Step MacAdam Ellipse | - | Round | 16892lm (Typ) | 1.3A | 25°C | 66.7V | 195 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-30C10K1-C-83VERO 29C WARM WHITE LED ARRAY |
2,697 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 16798lm (Typ) | 1.3A | 25°C | 66.7V | 194 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-27H10K0-C-83VERO 29C WARM WHITE LED ARRAY |
2,635 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Round | 11041lm (Typ) | 1.3A | 25°C | 66.7V | 127 lm/W | 4.75A | 97 (Typ) | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-50E10K1-C-83VERO 29C COOL WHITE LED ARRAY |
3,162 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Round | 16704lm (Typ) | 1.3A | 25°C | 66.7V | 193 lm/W | 4.75A | 80 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-65E10K1-C-83VERO 29C COOL WHITE LED ARRAY |
2,825 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 6500K 3-Step MacAdam Ellipse | - | Round | 16232lm (Typ) | 1.3A | 25°C | 66.7V | 187 lm/W | 4.75A | 80 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-50G10K1-C-83VERO 29C COOL WHITE LED ARRAY |
3,575 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Round | 14439lm (Typ) | 1.3A | 25°C | 66.7V | 167 lm/W | 4.75A | 90 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-57C10K1-C-83VERO 29C COOL WHITE LED ARRAY |
2,524 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 5700K 3-Step MacAdam Ellipse | - | Round | 16892lm (Typ) | 1.3A | 25°C | 66.7V | 195 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-40C10K1-C-83VERO 29C NEUTRAL WHITE LED ARRAY |
2,736 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Round | 17270lm (Typ) | 1.3A | 25°C | 66.7V | 199 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-30H10K0-C-83VERO 29C WARM WHITE LED ARRAY |
3,974 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 11796lm (Typ) | 1.3A | 25°C | 66.7V | 136 lm/W | 4.75A | 97 (Typ) | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-57E10K1-C-83VERO 29C COOL WHITE LED ARRAY |
2,059 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 5700K 3-Step MacAdam Ellipse | - | Round | 16043lm (Typ) | 1.3A | 25°C | 66.7V | 185 lm/W | 4.75A | 80 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
|
BXRC-50C10K1-C-83VERO 29C COOL WHITE LED ARRAY |
2,472 | 41.31 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® 29 Array | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Round | 17364lm (Typ) | 1.3A | 25°C | 66.7V | 200 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 1.90mm | 29.10mm Dia |
|
BXRC-27H10K0-C-83-SEVERO SE 29C WARM WHITE LED ARRAY |
3,085 | 41.44 |
RFQ |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Round | 11014lm (Typ) | 1.3A | 25°C | 66.7V | 127 lm/W | 4.75A | 97 (Typ) | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia | |
|
|
BXRC-30H10K0-C-83-SEVERO SE 29C WARM WHITE LED ARRAY |
3,522 | 41.44 |
RFQ |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Round | 11767lm (Typ) | 1.3A | 25°C | 66.7V | 136 lm/W | 4.75A | 97 (Typ) | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia | |
|
|
BXRC-50G10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
2,352 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Round | 14403lm (Typ) | 1.3A | 25°C | 66.7V | 166 lm/W | 4.75A | 90 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-57C10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
3,193 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 5700K 3-Step MacAdam Ellipse | - | Round | 16850lm (Typ) | 1.3A | 25°C | 66.7V | 194 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-65E10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
2,911 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 6500K 3-Step MacAdam Ellipse | - | Round | 16191lm (Typ) | 1.3A | 25°C | 66.7V | 187 lm/W | 4.75A | 80 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-57E10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
2,975 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 5700K 3-Step MacAdam Ellipse | - | Round | 16003lm (Typ) | 1.3A | 25°C | 66.7V | 185 lm/W | 4.75A | 80 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-65C10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
2,143 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 6500K 3-Step MacAdam Ellipse | - | Round | 16850lm (Typ) | 1.3A | 25°C | 66.7V | 194 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-50C10K1-C-83-SEVERO SE 29C COOL WHITE LED ARRAY |
2,979 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Round | 17321lm (Typ) | 1.3A | 25°C | 66.7V | 200 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
|
|
BXRC-40C10K1-C-83-SEVERO SE 29C NEUTRAL WHITE LED AR |
2,616 | 41.47 |
RFQ |
Datasheet |
Tray | Gen 8 Vero® SE 29 Array | Active | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Round | 17227lm (Typ) | 1.3A | 25°C | 66.7V | 199 lm/W | 4.75A | 70 | 120° | - | 49.20mm Dia | 3.60mm | 29.10mm Dia |
