| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Color | CCT(K) | Wavelength | Configuration | LuminousFlux@Current/Temperature | Current-Test | Temperature-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | CRI(ColorRenderingIndex) | ViewingAngle | Features | Size/Dimension | Height | LightEmittingSurface(LES) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BXRE-50E3001-D-24LED ARRAY 3000LM COOL WHITE COB |
2,815 | 0.00 |
RFQ |
Datasheet |
Tray | V15 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Square | 3428lm (Typ) | 700mA | 25°C | 36V | 136 lm/W | 1.4A | 80 | 120° | - | 21.00mm L x 21.00mm W | 1.70mm | 15.20mm Dia |
|
BXRE-50E4000-F-24LED ARRAY 4000LM COOL WHITE COB |
2,140 | 0.00 |
RFQ |
Datasheet |
Tray | V18 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Square | 4305lm (Typ) | 1.05A | 25°C | 29.5V | 139 lm/W | 2.1A | 80 | 120° | - | 21.00mm L x 21.00mm W | 1.70mm | 18.60mm Dia |
|
BXRE-50G2000-C-24LED ARRAY 2000LM COOL WHITE COB |
2,257 | 0.00 |
RFQ |
Datasheet |
Tray | V13 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Square | 2015lm (Typ) | 500mA | 25°C | 32.3V | 125 lm/W | 1.05A | 90 | 120° | - | 15.80mm L x 15.80mm W | 1.70mm | 13.40mm Dia |
|
|
BXRE-50G3001-D-24LED ARRAY 3000LM COOL WHITE COB |
2,863 | 0.00 |
RFQ |
Datasheet |
Tray | V15 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Square | 2898lm (Typ) | 700mA | 25°C | 36V | 115 lm/W | 1.4A | 90 | 120° | - | 21.00mm L x 21.00mm W | 1.70mm | 15.20mm Dia |
|
|
BXRE-50G4000-F-24LED ARRAY 4000LM COOL WHITE COB |
3,546 | 0.00 |
RFQ |
Datasheet |
Tray | V18 Array | Obsolete | Chip On Board (COB) | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Square | 3885lm (Typ) | 1.05A | 25°C | 29.5V | 125 lm/W | 2.1A | 90 | 120° | - | 21.00mm L x 21.00mm W | 1.70mm | 18.60mm Dia |
|
BXRC-30E2000-C-Z3LED ARRAY 2000LM WARM WHITE |
2,960 | 0.00 |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K | - | Round | 1910lm (Typ) | 500mA | 85°C | 31.3V | 122 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
BXRC-30E4000-F-02LED ARRAY 4000LM WARM WHITE |
3,365 | 0.00 |
RFQ |
Datasheet |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Round | 3780lm (Typ) | 1.05A | 25°C | 29.5V | 122 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-30E4000-F-Z2LED ARRAY 4000LM WARM WHITE |
3,944 | 0.00 |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K | - | Round | 3306lm (Typ) | 1.05A | 85°C | 28.8V | 109 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-30E4000-F-Z3LED ARRAY 4000LM WARM WHITE |
3,626 | 0.00 |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 3000K | - | Round | 3306lm (Typ) | 1.05A | 85°C | 28.8V | 109 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-17E4000-F-04LED ARRAY 4000LM WARM WHITE |
3,170 | 0.00 |
RFQ |
Datasheet |
Tray | Décor Food Meat & Deli Vero 18 | Obsolete | Chip On Board (COB) | White, Warm | 1750K 4-Step MacAdam Ellipse | - | Round | 1892lm (Typ) | 1.05A | 85°C | 28.8V | 63 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-17E4000-F-Z4LED ARRAY 4000LM WARM WHITE |
3,373 | 0.00 |
RFQ |
Tray | Décor Food Meat & Deli Vero 18 | Obsolete | Chip On Board (COB) | White, Warm | 1750K | - | Round | 1820lm (Typ) | 1.05A | 85°C | 27.9V | 62 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
|
BXRC-25E4000-F-04LED ARRAY 4000LM WARM WHITE |
3,356 | 0.00 |
RFQ |
Datasheet |
Tray | Décor Food Bread & Bakery Vero 18 | Obsolete | Chip On Board (COB) | White, Warm | 2500K 4-Step MacAdam Ellipse | - | Round | 2340lm (Typ) | 1.05A | 85°C | 27.9V | 80 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-25E4000-F-Z4LED ARRAY 4000LM WARM WHITE |
2,659 | 0.00 |
RFQ |
Tray | Décor Food Bread & Bakery Vero 18 | Obsolete | Chip On Board (COB) | White, Warm | 2500K | - | Round | 2340lm (Typ) | 1.05A | 85°C | 27.9V | 80 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia | |
|
BXRC-27E1000-B-02LED ARRAY 1000LM WARM WHITE |
3,228 | 0.00 |
RFQ |
Datasheet |
Tray | Vero® 10 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Starboard | 1080lm (Typ) | 350mA | 25°C | 26.7V | 116 lm/W | 700mA | 80 | 120° | With Connector | 20.00mm Dia | 1.90mm | 9.90mm Dia |
|
BXRC-27E10K0-L-02LED ARRAY 10000LM WARM WHITE |
2,162 | 0.00 |
RFQ |
Datasheet |
Tray | Vero® 29 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 9380lm (Typ) | 2.1A | 25°C | 38.6V | 116 lm/W | 4.2A | 80 | 120° | With Connector | 49.20mm Dia | 1.90mm | 29.20mm Dia |
|
|
BXRC-27E2000-C-02LED ARRAY 2000LM WARM WHITE |
3,128 | 0.00 |
RFQ |
Datasheet |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 1880lm (Typ) | 500mA | 25°C | 32.5V | 116 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia |
|
|
BXRC-27E2000-C-Z2LED ARRAY 2000LM WARM WHITE |
3,151 | 0.00 |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 1640lm (Typ) | 500mA | 85°C | 30.8V | 106 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-27E2000-C-Z3LED ARRAY 2000LM WARM WHITE |
2,372 | 0.00 |
RFQ |
Tray | Vero® 13 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 1640lm (Typ) | 500mA | 85°C | 30.8V | 106 lm/W | 1.05A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 13.20mm Dia | |
|
|
BXRC-27E4000-F-02LED ARRAY 4000LM WARM WHITE |
2,406 | 0.00 |
RFQ |
Datasheet |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K 2-Step MacAdam Ellipse | - | Round | 3650lm (Typ) | 1.05A | 25°C | 29.5V | 118 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
|
|
BXRC-27E4000-F-Z2LED ARRAY 4000LM WARM WHITE |
2,915 | 0.00 |
RFQ |
Tray | Vero® 18 Array | Obsolete | Chip On Board (COB) | White, Warm | 2700K | - | Round | 3150lm (Typ) | 1.05A | 85°C | 27.9V | 108 lm/W | 2.1A | 80 | 120° | With Connector | 36.20mm Dia | 1.90mm | 18.40mm Dia |
