| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AKPB002016101R5TA6INDUCTOR POWER |
3,582 | 0.16 |
RFQ |
Datasheet |
0806 (2016 Metric) | Tape & Reel (TR) | AKPx | Active | Multilayer | Ferrite | 1.5 µH | ±30% | 1.2 A | 600mA | Shielded | 110mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 3 MHz | - | Surface Mount | 0806 |
|
|
AKPB002016102R2MA6INDUCTOR POWER |
3,868 | 0.16 |
RFQ |
Datasheet |
0806 (2016 Metric) | Tape & Reel (TR) | AKPx | Active | Multilayer | Ferrite | 2.2 µH | ±20% | 1.2 A | 400mA | Shielded | 110mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 3 MHz | - | Surface Mount | 0806 |
|
BDHE00201208R24MQ1INDUCTOR POWER |
3,980 | 0.17 |
RFQ |
Datasheet |
0805 (2012 Metric) | Tape & Reel (TR) | BDHE | Active | Molded | - | 240 nH | ±20% | 4.2 A | 4.8A | Unshielded | 25mOhm Max | - | - | - | -40°C ~ 125°C | 2 MHz | - | Surface Mount | 0805 |
|
|
BDHE00201210R24MQ1INDUCTOR POWER |
3,195 | 0.17 |
RFQ |
Datasheet |
0805 (2012 Metric) | Tape & Reel (TR) | BDHE | Active | Molded | - | 240 nH | ±20% | 3.7 A | 4.5A | Unshielded | 28mOhm Max | - | - | - | -40°C ~ 125°C | 2 MHz | - | Surface Mount | 0805 |
|
|
BDHE003225101R5MQ1INDUCTOR POWER |
2,037 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BDHE | Active | Molded | - | 1.5 µH | ±20% | 3.2 A | 3.5A | Unshielded | 58mOhm Max | - | - | - | -40°C ~ 125°C | 2 MHz | - | Surface Mount | 1210 |
|
BDUE002520101R0MQ1INDUCTOR POWER |
2,598 | 0.17 |
RFQ |
Datasheet |
1008 (2520 Metric) | Tape & Reel (TR) | BDUE | Active | Molded | - | 1 µH | ±20% | 4 A | 4.7A | Unshielded | 46mOhm Max | - | - | - | -40°C ~ 125°C | 2 MHz | - | Surface Mount | 1008 |
|
BWQC00322516100TH1INDUCTOR RF |
2,429 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±30% | 750 mA | - | Unshielded | 380mOhm Max | - | 30MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQV00322520R47M00INDUCTOR RF |
3,531 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQV | Active | Drum Core, Wirewound | Ferrite | 470 nH | ±20% | 1.1 A | - | Unshielded | 60mOhm Max | 20 @ 1MHz | 150MHz | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC003225163R3TH1INDUCTOR RF |
2,367 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 1.25 A | - | Unshielded | 120mOhm Max | - | 50MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQV00322520R82M00INDUCTOR RF |
3,241 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQV | Active | Drum Core, Wirewound | Ferrite | 820 nH | ±20% | 450 mA | - | Unshielded | 250mOhm Max | 20 @ 1MHz | 120MHz | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322516100MH1INDUCTOR RF |
3,106 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 750 mA | - | Unshielded | 380mOhm Max | - | 30MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322516470MH1INDUCTOR RF |
3,806 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 280 mA | - | Unshielded | 1.48Ohm Max | - | 11MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC003225163R3MH1INDUCTOR RF |
3,712 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 1.25 A | - | Unshielded | 120mOhm Max | - | 50MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC003225163R3M00INDUCTOR RF |
3,142 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 1.25 A | - | Unshielded | 120mOhm Max | - | 50MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322516100M00INDUCTOR RF |
2,572 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 350 mA | - | Unshielded | 300mOhm | - | 26MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322516470TH1INDUCTOR RF |
3,437 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±30% | 280 mA | - | Unshielded | 1.48Ohm Max | - | 11MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322516100K00INDUCTOR RF |
3,469 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±10% | 350 mA | - | Unshielded | 300mOhm | - | 26MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322520100KL1INDUCTOR RF |
3,031 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±10% | 450 mA | - | Unshielded | 300mOhm Max | - | 26MHz | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC00322520100M00INDUCTOR RF |
2,751 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 300 mA | - | Unshielded | 440mOhm | - | 26MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
|
|
BWQC003225166R8TH1INDUCTOR RF |
2,661 | 0.17 |
RFQ |
Datasheet |
1210 (3225 Metric) | Tape & Reel (TR) | BWQC | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 850 mA | - | Unshielded | 240mOhm Max | - | 40MHz | - | -25°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 |
