| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTDR5F-680KRADIAL LEADED DRUM CORE INDUCTOR |
2,141 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 68 µH | ±10% | 21 A | 23A | Unshielded | 15mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-392KRADIAL LEADED DRUM CORE INDUCTOR |
3,411 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 3.9 mH | ±10% | 4 A | 3A | Unshielded | 699mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-3R3MRADIAL LEADED DRUM CORE INDUCTOR |
2,630 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 3.3 µH | ±20% | 35 A | 125A | Unshielded | 2mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-822KRADIAL LEADED DRUM CORE INDUCTOR |
2,920 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 8.2 mH | ±10% | 2.8 A | 2.1A | Unshielded | 1.26Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-561KRADIAL LEADED DRUM CORE INDUCTOR |
2,711 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 560 µH | ±10% | 9 A | 8.1A | Unshielded | 105mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-270KRADIAL LEADED DRUM CORE INDUCTOR |
2,792 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 27 µH | ±10% | 27 A | 35A | Unshielded | 8mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-391KRADIAL LEADED DRUM CORE INDUCTOR |
3,829 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 390 µH | ±10% | 11.4 A | 9.7A | Unshielded | 70mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-272KRADIAL LEADED DRUM CORE INDUCTOR |
2,769 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 2.7 mH | ±10% | 4.5 A | 3.7A | Unshielded | 459mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-4R7MRADIAL LEADED DRUM CORE INDUCTOR |
2,358 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 4.7 µH | ±20% | 35 A | 87A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-472KRADIAL LEADED DRUM CORE INDUCTOR |
3,485 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 4.7 mH | ±10% | 4 A | 2.8A | Unshielded | 775mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-271KRADIAL LEADED DRUM CORE INDUCTOR |
2,347 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 270 µH | ±10% | 13.5 A | 11A | Unshielded | 44mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-2R2MRADIAL LEADED DRUM CORE INDUCTOR |
3,284 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 2.2 µH | ±20% | 35 A | 155A | Unshielded | 2mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-332KRADIAL LEADED DRUM CORE INDUCTOR |
3,376 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 3.3 mH | ±10% | 4 A | 3.4A | Unshielded | 642mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-471KRADIAL LEADED DRUM CORE INDUCTOR |
3,028 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 470 µH | ±10% | 11.4 A | 8.8A | Unshielded | 78mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-2R7MRADIAL LEADED DRUM CORE INDUCTOR |
3,012 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 2.7 µH | ±20% | 35 A | 125A | Unshielded | 2mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-221KRADIAL LEADED DRUM CORE INDUCTOR |
3,977 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 220 µH | ±10% | 13.5 A | 13A | Unshielded | 40mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-390KRADIAL LEADED DRUM CORE INDUCTOR |
2,849 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 39 µH | ±10% | 27 A | 30A | Unshielded | 10mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-330KRADIAL LEADED DRUM CORE INDUCTOR |
2,314 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 33 µH | ±10% | 27 A | 34A | Unshielded | 9mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-222KRADIAL LEADED DRUM CORE INDUCTOR |
3,022 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 2.2 mH | ±10% | 5.5 A | 4.1A | Unshielded | 338mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
|
|
CTDR5F-331KRADIAL LEADED DRUM CORE INDUCTOR |
2,170 | 15.53 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTDR5F | Active | Drum Core, Wirewound | - | 330 µH | ±10% | 13.5 A | 10A | Unshielded | 49mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial |
