| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTGS137F-100M10UH SMD UNSHLD POWER INDUCTOR |
3,923 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 10 µH | ±20% | 5.6 A | 9.2A | Unshielded | 21mOhm | 22 @ 2.52MHz | 22MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-150M15UH SMD UNSHLD POWER INDUCTOR |
2,325 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 15 µH | ±20% | 4.5 A | 7.5A | Unshielded | 34mOhm | 28 @ 2.52MHz | 17MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-221K220UH SMD UNSHLD POWER INDUCTOR |
3,858 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 220 µH | ±10% | 1.3 A | 2.1A | Unshielded | 360mOhm | 15 @ 796kHz | 3.8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-1R5M1.5UH SMD UNSHLD POWER INDUCTOR |
2,313 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 1.5 µH | ±20% | 9.5 A | 20A | Unshielded | 5mOhm | 20 @ 7.96MHz | 65MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-220M22UH SMD UNSHLD POWER INDUCTOR |
3,991 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 22 µH | ±20% | 3.6 A | 6.5A | Unshielded | 47mOhm | 40 @ 2.52MHz | 15MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-151K150UH SMD UNSHLD POWER INDUCTOR |
3,017 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 150 µH | ±10% | 1.6 A | 2.6A | Unshielded | 250mOhm | 20 @ 796kHz | 4.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-181K180UH SMD UNSHLD POWER INDUCTOR |
3,113 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 180 µH | ±10% | 1.5 A | 2.3A | Unshielded | 280mOhm | 18 @ 796kHz | 4MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-180M18UH SMD UNSHLD POWER INDUCTOR |
2,513 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 18 µH | ±20% | 4.2 A | 7A | Unshielded | 36mOhm | 28 @ 2.52MHz | 16MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-121K120UH SMD UNSHLD POWER INDUCTOR |
3,224 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 120 µH | ±10% | 1.8 A | 2.8A | Unshielded | 210mOhm | 20 @ 796kHz | 5.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTGS137F-120M12UH SMD UNSHLD POWER INDUCTOR |
2,582 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 12 µH | ±20% | 4.8 A | 8A | Unshielded | 30mOhm | 25 @ 2.52MHz | 20MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
CTCDRH5D28F-560N56UH SMD SHIELDED POWR INDUCTOR |
3,240 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTCDRH5D28F | Active | - | - | 56 µH | ±30% | - | 580mA | Shielded | 305mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - |
|
|
CTCDRH5D28F-390N39UH SMD SHIELDED POWR INDUCTOR |
2,452 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTCDRH5D28F | Active | - | - | 39 µH | ±30% | - | 700mA | Shielded | 212mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - |
|
|
CTGS137F-270M27UH SMD UNSHLD POWER INDUCTOR |
2,542 | 0.84 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGS137F | Active | Wirewound | - | 27 µH | ±20% | 3.3 A | 5.5A | Unshielded | 60mOhm | 35 @ 2.52MHz | 11MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
CTRFB1010F-123K12000UH RADIAL FIXED INDUCTR |
2,415 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 12 mH | ±10% | 170 mA | 170mA | Unshielded | 22Ohm Max | - | 500kHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-562K5600UH RADIAL FIXED INDUCTOR |
3,222 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 5.6 mH | ±10% | 300 mA | 260mA | Unshielded | 10Ohm Max | - | 800kHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-470K47UH RADIAL FIXED INDUCTOR |
2,449 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 47 µH | ±10% | 3.5 A | 2.8A | Unshielded | 82mOhm Max | - | 9.5MHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-182K1800UH RADIAL FIXED INDUCTOR |
3,945 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 1.8 mH | ±10% | 550 mA | 450mA | Unshielded | 3.5Ohm Max | - | 1.3MHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-102K1000UH RADIAL FIXED INDUCTR |
2,377 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 1 mH | ±10% | 670 mA | 600mA | Unshielded | 1.45Ohm Max | - | 2MHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-150K15UH RADIAL FIXED INDUCTOR |
3,927 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 15 µH | ±10% | 5.4 A | 5A | Unshielded | 28mOhm Max | - | 19MHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
|
|
CTRFB1010F-151K150UH RADIAL FIXED INDUCTOR |
3,843 | 0.85 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | CTRFB1010F | Active | - | - | 150 µH | ±10% | 1.9 A | 1.6A | Unshielded | 245mOhm Max | - | 5MHz | - | -40°C ~ 85°C | 100 kHz | - | Through Hole | Radial |
