| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RURG302030A, 200V ULTRAFAST DIODE |
575 | 2.68 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Through Hole | - | 50 ns | 250 µA @ 200 V | 200 V | 30A | -65°C ~ 175°C | 1 V @ 30 A | |
|
PMEG2010EPASXNOW NEXPERIA PMEG2010EPASX - REC |
15,000 | 0.09 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 175pF @ 1V, 1MHz | 50 ns | 335 µA @ 20 V | 20 V | 1A | 150°C (Max) | 375 mV @ 1 A |
|
US2FARECTIFIER DIODE, 1.5A, 300V, DO- |
14,617 | 0.09 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 300 V | 300 V | 1.5A | -55°C ~ 150°C | 1 V @ 1.5 A |
|
RURG8040RECTIFIER DIODE |
7,789 | 6.27 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Through Hole | - | 85 ns | 500 µA @ 400 V | 400 V | 80A | -65°C ~ 175°C | 1.6 V @ 80 A | |
|
|
SS12RECTIFIER DIODE, SCHOTTKY, 1A, 2 |
9,030 | 0.09 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 20 V | 20 V | 1A | -65°C ~ 125°C | 500 mV @ 1 A | |
|
|
RURU15040RA150A, 400V ULTRAFAST DIODE |
420 | 6.35 |
RFQ |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | ||
|
SBR50-16JSRECTIFIER DIODE, SCHOTTKY, 1 PHA |
2,848 | 1.04 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
IDT08S60CRECTIFIER DIODE, SCHOTTKY |
5,066 | 2.84 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
SMMBD330T1GSMMBD330 - 30 V SCHOTTKY DIODE |
228,000 | 0.10 |
RFQ |
Datasheet |
Bulk | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 1.5pF @ 15V, 1MHz | - | 200 nA @ 25 V | 30 V | 200mA (DC) | -55°C ~ 125°C | 600 mV @ 10 mA | |
|
HSC119JTRF-EHSC119 - RECTIFIER DIODE, 1 ELEM |
80,000 | 0.10 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
RHRU5060RECTIFIER DIODE |
734 | 2.85 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Chassis Mount | - | 50 ns | 500 µA @ 600 V | 600 V | 50A | -65°C ~ 175°C | 2.1 V @ 50 A | |
|
|
SB10-04A3-BTSB10-04A3 - SCHOTTKY DIODE 1A 40 |
48,000 | 0.10 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | 45pF @ 10V, 1MHz | - | 800 µA @ 40 V | 40 V | 1A | 125°C (Max) | 550 mV @ 1 A | |
|
|
RURG8070RECTIFIER DIODE |
977 | 2.86 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Through Hole | - | 200 ns | 500 µA @ 700 V | 700 V | 80A | -65°C ~ 175°C | 1.9 V @ 80 A | |
|
IDW15E65D2IDW15E65 - SILICON POWER DIODE |
19,680 | 1.09 |
RFQ |
Datasheet |
Bulk | CoolSiC™+ | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 47 ns | 40 µA @ 650 V | 650 V | 30A | -40°C ~ 175°C | 2.3 V @ 15 A |
|
|
US2BARECTIFIER DIODE, 1.5A, 100V, DO- |
4,967 | 0.10 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 50pF @ 4V, 1MHz | 50 ns | 5 µA @ 100 V | 100 V | 1.5A | -55°C ~ 150°C | 1 V @ 1.5 A |
|
|
RURG8080RECTIFIER DIODE |
703 | 2.86 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Through Hole | - | 200 ns | 500 µA @ 800 V | 800 V | 80A | -65°C ~ 175°C | 1.9 V @ 80 A | |
|
PMEG3020EPA,115NEXPERIA PMEG3020EPA - RECTIFIER |
3,000 | 0.10 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 150pF @ 1V, 1MHz | 47 ns | 2.5 mA @ 30 V | 30 V | 2A | 150°C (Max) | 470 mV @ 2 A | |
|
|
RURU5050RECTIFIER DIODE |
580 | 2.94 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Chassis Mount | - | 75 ns | 500 µA @ 500 V | 500 V | 50A | -65°C ~ 175°C | 1.6 V @ 50 A | |
|
|
RHRU50100RECTIFIER DIODE |
280 | 2.98 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Chassis Mount | - | 95 ns | 500 µA @ 1000 V | 1000 V | 50A | -65°C ~ 175°C | 3 V @ 50 A | |
|
|
GBPC1208BRIDGE RECTIFIER DIODE, 1 PHASE, |
500 | 1.16 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - |
