| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PMEG4002AESFYLNEXPERIA PMEG4002AESF - 40 V, 0. |
1,197,000 | 0.03 |
RFQ |
Datasheet |
Bulk | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 18pF @ 1V, 1MHz | 1.25 ns | 80 µA @ 40 V | 40 V | 200mA | 150°C (Max) | 525 mV @ 200 mA | |
|
MUR3010PTRECTIFIER DIODE |
109 | 3.96 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | - | 100 V | 30A | - | - | |
|
ES1D-F080ES1D - RECTIFIER DIODE, 1A, 200V |
75,000 | 0.06 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
SB140RECTIFIER DIODE, SCHOTTKY, 1A, 4 |
137,477 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 40 V | 40 V | 1A | -50°C ~ 150°C | 500 mV @ 1 A | |
|
BAS28,215NEXPERIA BAS28 - RECTIFIER DIODE |
961,635 | 0.03 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
|
SB160RECTIFIER DIODE, SCHOTTKY, 1A, 6 |
128,618 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 60 V | 60 V | 1A | -50°C ~ 150°C | 700 mV @ 1 A | |
|
BAS116QAZBAS116QA - LOW-LEAKAGE DIODE |
440,000 | 0.03 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 2pF @ 0V, 1MHz | 3 µs | 5 nA @ 75 V | 75 V | 300mA (DC) | -55°C ~ 150°C | 1.25 V @ 150 mA |
|
RGP10ARECTIFIER DIODE, 1A, 50V, DO-41 |
55,870 | 0.06 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 15pF @ 4V, 1MHz | 150 ns | 5 µA @ 50 V | 50 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | |
|
|
RURU10040RECTIFIER DIODE |
1,406 | 4.01 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Chassis Mount | - | 100 ns | 500 µA @ 400 V | 400 V | 100A | -65°C ~ 175°C | 1.6 V @ 100 A | |
|
PMEG2015EH,115NEXPERIA PMEG2015EH - RECTIFIER |
114,000 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 1V, 1MHz | - | 70 µA @ 20 V | 20 V | 1.5A (DC) | 150°C (Max) | 660 mV @ 1.5 A | |
|
BAS40-05W,115NEXPERIA BAS40-05W - RECTIFIER D |
291,000 | 0.03 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
PMEG1020EJ,115NEXPERIA PMEG1020EJ - DIODE SCHO |
51,226 | 0.06 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 5V, 1MHz | - | 3 mA @ 10 V | 10 V | 2A (DC) | 150°C (Max) | 460 mV @ 2 A | |
|
|
RHRU10050RECTIFIER DIODE |
209 | 4.01 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 60 ns | 500 µA @ 500 V | 500 V | 100A | -65°C ~ 175°C | 2.1 V @ 100 A | |
|
|
UF4003RECTIFIER DIODE, 1A, 200V, DO-41 |
109,151 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 50 ns | 5 µA @ 200 V | 200 V | 1A | -50°C ~ 175°C | 1 V @ 1 A | |
|
1N458AHIGH CONDUCTANCE LOW LEAKAGE DIO |
273,640 | 0.03 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 25 µA @ 125 V | 150 V | 500mA | 175°C (Max) | 1 V @ 100 mA | |
|
|
RGP10DRECTIFIER DIODE, 1A, 200V, DO-41 |
41,974 | 0.06 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 15pF @ 4V, 1MHz | 150 ns | 5 µA @ 200 V | 200 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | |
|
1PS74SB23,125NEXPERIA 1PS74SB23 - RECTIFIER D |
68,975 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 100pF @ 4V, 1MHz | - | 1 mA @ 25 V | 25 V | 1A (DC) | 125°C (Max) | 450 mV @ 1 A | |
|
BAS40-06E6327BAS40 - HIGH SPEED SWITCHING, CL |
39,599 | 0.06 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
RURP3010RECTIFIER DIODE |
6,015 | 2.26 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Avalanche | Active | Through Hole | - | 50 ns | 500 µA @ 100 V | 100 V | 30A | -55°C ~ 175°C | 1 V @ 30 A | |
|
|
UF4002RECTIFIER DIODE, 1A, 100V, DO-41 |
51,180 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 50 ns | 5 µA @ 100 V | 100 V | 1A | -50°C ~ 175°C | 1 V @ 1 A |
