| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STTH1R06AF600 V, 1 A SOD128FLAT TURBO 2 UL |
5,056 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 45 ns | 1 µA @ 600 V | 600 V | 1A | 175°C (Max) | 1.9 V @ 1 A | |
|
STPS20SM60DDIODE SCHOTTKY 60V 20A TO220AC |
11,264 | 1.43 |
RFQ |
Datasheet |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 85 µA @ 60 V | 60 V | 20A | 150°C (Max) | 630 mV @ 20 A | |
|
STTH6010WDIODE GEN PURP 1KV 60A DO247 |
653 | 5.59 |
RFQ |
Datasheet |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 115 ns | 20 µA @ 1000 V | 1000 V | 60A | 175°C (Max) | 2 V @ 60 A | |
|
FERD40H100STSDIODE RECT 100V 40A TO220AB |
1,900 | 1.47 |
RFQ |
Datasheet |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | FERD (Field Effect Rectifier Diode) | Active | Through Hole | - | - | 190 µA @ 100 V | 100 V | 40A | 175°C (Max) | 705 mV @ 40 A | |
|
STPS1545FPDIODE SCHOTTKY 45V 15A TO220FP |
14,494 | 1.48 |
RFQ |
Datasheet |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 200 µA @ 45 V | 45 V | 15A | 175°C (Max) | 840 mV @ 30 A | |
|
STPSC6H065DLFSILICON CARBIDE DIODES |
5,759 | 2.87 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ECOPACK®2 | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Surface Mount | 350pF @ 0V, 1MHz | 0 ns | 60 µA @ 650 V | 650 V | 6A | -40°C ~ 175°C | 1.55 V @ 6 A |
|
|
STTH6010WYDIODE GEN PURP 1KV 60A DO247 |
495 | 7.01 |
RFQ |
Datasheet |
Tube | Q Automotive | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 115 ns | 20 µA @ 1000 V | 1000 V | 60A | -40°C ~ 175°C | 2 V @ 60 A |
|
|
STPSC10H12DYDIODE SCHOTTKY 1.2KV 10A TO220AC |
742 | 7.37 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101, ECOPACK® | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 725pF @ 0V, 1MHz | 0 ns | 60 µA @ 1200 V | 1200 V | 10A | -40°C ~ 175°C | 1.5 V @ 10 A |
|
STPSC15H12WLDIODE SCHOTTKY 1.2KV 15A DO247 |
221 | 8.66 |
RFQ |
Datasheet |
Tube | ECOPACK®2 | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 1200pF @ 0V, 1MHz | 0 ns | 90 µA @ 1200 V | 1200 V | 15A | -40°C ~ 175°C | 1.5 V @ 15 A |
|
|
STPSC20H12WLDIODE SCHOTTKY 1.2KV 20A DO247 |
192 | 11.30 |
RFQ |
Datasheet |
Tube | ECOPACK®2 | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 1650pF @ 0V, 1MHz | 0 ns | 120 µA @ 1200 V | 1200 V | 20A | -40°C ~ 175°C | 1.5 V @ 20 A |
|
STPS15L25DDIODE SCHOTTKY 25V 15A TO220AC |
3,961 | 3.15 |
RFQ |
Datasheet |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 1.3 mA @ 25 V | 25 V | 15A | 150°C (Max) | 460 mV @ 15 A | |
|
1N5818RLDIODE SCHOTTKY 30V 1A DO41 |
3,297 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Through Hole | - | - | 500 µA @ 30 V | 30 V | 1A | 150°C (Max) | 500 mV @ 1 A | |
|
|
1N5818DIODE SCHOTTKY 30V 1A DO41 |
7,340 | 0.38 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 30 V | 30 V | 1A | 150°C (Max) | 500 mV @ 1 A | |
|
|
STTH102RLDIODE GEN PURP 200V 1A DO41 |
6,563 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 20 ns | 1 µA @ 200 V | 200 V | 1A | 175°C (Max) | 970 mV @ 1 A | |
|
STPS340AFN40 V, 3 A SMD POWER SCHOTTKY REC |
29,047 | 0.50 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 20 µA @ 40 V | 40 V | 3A | 150°C | 630 mV @ 3 A | |
|
STPS3L60RLDIODE SCHOTTKY 60V 3A DO201AD |
2,674 | 0.63 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Through Hole | - | - | 150 µA @ 60 V | 60 V | 3A | 150°C (Max) | 620 mV @ 3 A | |
|
STTH25M06FP600V, 25A, ULTRAFAST DIODE |
1,980 | 1.67 |
RFQ |
Tube | ECOPACK®2 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 50 ns | 60 µA @ 600 V | 600 V | 25A | 175°C (Max) | 3.4 V @ 25 A | |
|
|
STTH3R04RLDIODE GEN PURP 400V 3A DO201AD |
5,535 | 0.77 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 35 ns | 5 µA @ 400 V | 400 V | 3A | 175°C (Max) | 1.5 V @ 3 A | |
|
STPS20M100SG-TRDIODE SCHOTTKY 100V 20A D2PAK |
2,738 | 2.93 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 40 µA @ 100 V | 100 V | 20A | 150°C (Max) | 850 mV @ 20 A | |
|
STPS2L30AFN30 V, 2 A LOW DROP POWER SCHOTTK |
621 | 0.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 30 V | 30 V | 2A | 150°C | 450 mV @ 2 A |
