| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SS14-LTPDIODE SCHOTTKY 40V 1A DO214AC |
34,869 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 52pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 1A | -55°C ~ 125°C | 500 mV @ 1 A | |
.jpg)
|
SK84L-TPDIODE SCHOTTKY 40V 8A DO214AB |
5,074 | 0.74 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 400pF @ 4V, 1MHz | - | 1 mA @ 40 V | 40 V | 8A | -55°C ~ 150°C | 650 mV @ 8 A | |
|
MBRD6100CT-TP6A,100V,SCHOTTKY,DPAK PACKAGE |
3,894 | 0.74 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 100 V | 100 V | 6A | -65°C ~ 150°C | 740 mV @ 3 A | |
|
|
FR10M-TPDIODE GEN PURP 1KV 10A DO214AB |
3,210 | 0.70 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Not For New Designs | Surface Mount | - | 500 ns | 10 µA @ 1000 V | 1000 V | 10A | -55°C ~ 150°C | 1.3 V @ 10 A | |
|
SS14E-TPDIODE SCHOTTKY 40V 1A SMAE |
42,793 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 110pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 1A | -55°C ~ 150°C | 600 mV @ 1 A | |
|
SK54B-LTPDIODE SCHOTTKY 40V 5A DO214AA |
13,625 | 0.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 200pF @ 4V, 1MHz | - | 1 mA @ 40 V | 40 V | 5A | -55°C ~ 150°C | 550 mV @ 5 A | |
|
|
ER1Q-LTP1ASUPERFASTRECOVERYSILICONRECTIF |
4,330 | 0.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 45pF @ 4V, 1MHz | 150 ns | 5 µA @ 1200 V | 1200 V | 1A | -50°C ~ 150°C | 1.85 V @ 1 A | |
|
|
US1Q-TP1AULTRAFASTRECOVERRECTIFIERSMA |
19,300 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 45pF @ 4V, 1MHz | 75 ns | 5 µA @ 1200 V | 1200 V | 1A | -50°C ~ 150°C | 1.9 V @ 1 A | |
|
SK56AFL-TPDIODE SCHOTTKY 60V 5A DO221AC |
21,300 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 210pF @ 4V, 1MHz | - | 500 µA @ 60 V | 60 V | 5A | -55°C ~ 125°C | 700 mV @ 5 A | |
|
|
SK510AFL-TPDIODE SCHOTTKY 100V 5A DO221AC |
32,365 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 170pF @ 4V, 1MHz | - | 200 µA @ 100 V | 100 V | 5A | -55°C ~ 125°C | 850 mV @ 5 A | |
|
1N5822-TPDIODE SCHOTTKY 40V 3A DO201AD |
11,791 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | 200pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 3A | -55°C ~ 125°C | 525 mV @ 3 A | |
|
1N4007-TPDIODE GEN PURP 1KV 1A DO41 |
193,509 | 0.23 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | 15pF @ 4V, 1MHz | 2 µs | 5 µA @ 1000 V | 1000 V | 1A | -55°C ~ 150°C | 1.1 V @ 1 A | |
|
|
1N4004-TPDIODE GEN PURP 400V 1A DO41 |
1,741 | 0.23 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | 15pF @ 4V, 1MHz | 2 µs | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.1 V @ 1 A | |
|
BAS16WX-TPDIODE GEN PURP 75V 100MA SOD323 |
566,576 | 0.23 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 2pF @ 0V, 1MHz | 6 ns | 1 µA @ 75 V | 75 V | 100mA | -55°C ~ 150°C | 1.25 V @ 150 mA | |
|
|
GS1G-LTPDIODE GEN PURP 400V 1A DO214AC |
272,550 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | - | 10 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1 V @ 1 A | |
|
|
SD103AWS-TPDIODE SCHOTTKY 40V 350MA SOD323 |
307,268 | 0.36 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 0V, 1MHz | 10 ns | 5 µA @ 30 V | 40 V | 350mA | -65°C ~ 125°C | 600 mV @ 200 mA | |
|
|
ES1J-LTPDIODE GEN PURP 600V 1A DO214AC |
109,009 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 35 ns | 5 µA @ 600 V | 600 V | 1A | -65°C ~ 175°C | 1.7 V @ 1 A | |
|
|
RB501V-40-TPDIODE SCHOTTKY 40V 100MA SOD323 |
31,508 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 6pF @ 10V, 1MHz | - | 30 µA @ 10 V | 40 V | 100mA | 125°C (Max) | 550 mV @ 100 mA | |
|
|
US1B-TPDIODE GEN PURP 100V 1A DO214AC |
15,000 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 20pF @ 4V, 1MHz | 50 ns | 10 µA @ 100 V | 100 V | 1A | -65°C ~ 175°C | 1 V @ 1 A | |
|
|
US1D-TPDIODE GEN PURP 200V 1A DO214AC |
28,906 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 20pF @ 4V, 1MHz | 50 ns | 10 µA @ 200 V | 200 V | 1A | -65°C ~ 175°C | 1 V @ 1 A |
