| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BAT120C,115DIODE ARRAY SCHOTTKY 25V SOT223 |
3,806 | 0.67 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 25 V | 1A (DC) | 450 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 25 V | 125°C (Max) | Surface Mount |
|
PNE20060CPEZPNE20060CPE/SOT1289B/CFP15 |
3,357 | 0.84 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 1 Pair Common Cathode | Standard | 200 V | 3A | 940 mV @ 3 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | 1 µA @ 200 V | 175°C (Max) | Surface Mount |
|
|
PNE20080CPEZPNE20080CPE/SOT1289B/CFP15 |
2,683 | 0.93 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 1 Pair Common Cathode | Standard | 200 V | 4A | 930 mV @ 4 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | 1 µA @ 200 V | 175°C (Max) | Surface Mount |
|
BAV170MYLBAV170M - DUAL COMMON CATHODE LO |
2,654 | 0.02 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
BAV70QAZBAV70QA - DUAL COMMON CATHODE HI |
3,544 | 0.03 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
BAV70S/ZLXBAV70 - HIGH-SPEED SWITCHING DIO |
2,929 | 0.03 |
RFQ |
Bulk | - | Obsolete | 2 Pair Common Cathode | Standard | 100 V | 100mA (DC) | 1 V @ 50 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 500 nA @ 80 V | 150°C | Surface Mount | |
|
BAV23CVLBAV23C - DUAL HIGH-VOLTAGE SWITC |
2,312 | 0.03 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
|
PMEG3010AESAYLPMEG3010AESA - 30 V, 1 A LOW VF |
3,755 | 0.04 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
BAV23QAZBAV23QA - DUAL COMMON CATHODE HI |
3,915 | 0.04 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
1PS70SB85,115NEXPERIA 1PS70SB85 - MIXER DIODE |
3,667 | 0.08 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
BAT54SW,115DIODE ARRAY SCHOTTKY 30V SOT323 |
2,960 | 0.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | Automotive, AEC-Q101 | Active | 1 Pair Series Connection | Schottky | 30 V | 200mA (DC) | 800 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 25 V | 150°C (Max) | Surface Mount |
|
|
BAT120S,115DIODE ARRAY SCHOTTKY 25V SOT223 |
681 | 0.67 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Schottky | 25 V | 1A (DC) | 450 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 25 V | 125°C (Max) | Surface Mount |
|
BAV23,235DIODE ARRAY GP 200V 225MA SOT143 |
234 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 Independent | Standard | 200 V | 225mA (DC) | 1.25 V @ 200 mA | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 100 nA @ 200 V | 150°C (Max) | Surface Mount |
|
|
BAV199W,115DIODE ARRAY GP 75V 110MA SOT323 |
250 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Standard | 75 V | 110mA (DC) | 1.1 V @ 50 mA | Small Signal =< 200mA (Io), Any Speed | 3 µs | 5 nA @ 75 V | 150°C (Max) | Surface Mount |
|
PMBD7100,215DIODE ARRAY GP 100V 215MA SOT23 |
2,411 | 0.18 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 100 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 2.5 µA @ 100 V | 150°C (Max) | Surface Mount |
|
|
BAS21AW,115DIODE ARRAY GP 250V 225MA SOT323 |
560 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 250 V | 225mA (DC) | 1.25 V @ 200 mA | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 100 nA @ 200 V | 150°C (Max) | Surface Mount |
|
|
BAS101S,215DIODE ARRAY GP 300V 200MA SOT23 |
551 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Standard | 300 V | 200mA (DC) | 1.1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 50 ns | 150 nA @ 250 V | 150°C (Max) | Surface Mount |
|
|
PNE200100CPEZPNE200100CPE/SOT1289B/CFP15 |
541 | 1.02 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 1 Pair Common Cathode | Standard | 200 V | 5A | 950 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | 1 µA @ 200 V | 175°C (Max) | Surface Mount |
|
|
BAV99,235DIODE ARRAY GP 100V 215MA SOT23 |
2,073 | 0.16 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, BAV99 | Active | 1 Pair Series Connection | Standard | 100 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 500 nA @ 80 V | 150°C (Max) | Surface Mount |
|
|
BAV99,215DIODE ARRAY GP 100V 215MA SOT23 |
2,615 | 0.16 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | Automotive, AEC-Q101, BAV99 | Active | 1 Pair Series Connection | Standard | 100 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 500 nA @ 80 V | 150°C (Max) | Surface Mount |
