| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CPT600100DDIODE MODULE 100V TO244AB |
3,816 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 Pair Series Connection | Schottky | 100 V | 300A | 850 mV @ 300 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 8 mA @ 100 V | - | Chassis Mount |
|
FST16090ADIODE MODULE 90V TO249 |
2,555 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 Pair Common Anode | Schottky | 90 V | 80A | 960 mV @ 80 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 2 mA @ 90 V | - | Screw Mount |
|
|
MSAD165-18DIODE MODULE 1.8KV 165A D2 |
3,326 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 1800 V | 165A | 1.4 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 9 mA @ 1800 V | - | Chassis Mount |
|
|
MSAD70-16DIODE MODULE 1.6KV 70A D1 |
2,966 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 1600 V | 70A | 1.48 V @ 200 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 mA @ 1600 V | - | Chassis Mount |
|
|
UFT20120DIODE MODULE 200V 100A |
2,850 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 200 V | 100A | 1.25 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 70 ns | 50 µA @ 200 V | - | Screw Mount |
|
|
APTDC902U601GDIODE MODULE 600V 90A SP1 |
2,224 | 0.00 |
RFQ |
Bulk | - | Obsolete | 2 Independent | Silicon Carbide Schottky | 600 V | 90A | 1.8 V @ 90 A | No Recovery Time > 500mA (Io) | 0 ns | 1800 µA @ 600 V | -40°C ~ 175°C | Chassis Mount | |
|
|
UFT7260SM3ADIODE MODULE 600V 35A SM3 |
3,054 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM3CDIODE MODULE 600V 35A SM3 |
2,598 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM3DDIODE MODULE 600V 35A SM3 |
3,827 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Series Connection | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM4CDIODE MODULE 600V 35A SM4 |
3,343 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM4DDIODE MODULE 600V 35A SM4 |
3,235 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Series Connection | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
UFT7260SM5ADIODE MODULE 600V 35A SM5 |
2,146 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM6ADIODE MODULE 600V 35A SM6 |
3,023 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM6CDIODE MODULE 600V 35A SM6 |
2,679 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
|
UFT7260SM6DDIODE MODULE 600V 35A SM6 |
2,324 | 0.00 |
RFQ |
Bulk | - | Obsolete | 1 Pair Series Connection | Standard | 600 V | 35A | 1.35 V @ 35 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 25 µA @ 600 V | - | Chassis Mount | |
|
APT2X20DC120JDIODE MODULE 1.2KV 20A SOT227 |
3,582 | 0.00 |
RFQ |
Bulk | - | Active | 2 Independent | Silicon Carbide Schottky | 1200 V | 20A | 1.8 V @ 20 A | No Recovery Time > 500mA (Io) | 0 ns | 400 µA @ 1200 V | -55°C ~ 175°C | Chassis Mount | |
|
|
APT2X30DC120JDIODE MODULE 1.2KV 30A SOT227 |
2,940 | 0.00 |
RFQ |
Bulk | - | Obsolete | 2 Independent | Silicon Carbide Schottky | 1200 V | 30A | 1.8 V @ 30 A | No Recovery Time > 500mA (Io) | 0 ns | 600 µA @ 1200 V | - | Chassis Mount | |
|
|
APT2X30DC60JDIODE MODULE 600V 30A SOT227 |
3,955 | 0.00 |
RFQ |
Bulk | - | Active | 2 Independent | Silicon Carbide Schottky | 600 V | 30A | 1.8 V @ 30 A | No Recovery Time > 500mA (Io) | 0 ns | 600 µA @ 600 V | - | Chassis Mount | |
|
|
APT2X31DC120JDIODE MODULE 1.2KV 30A SOT227 |
2,956 | 0.00 |
RFQ |
Bulk | - | Obsolete | 2 Independent | Silicon Carbide Schottky | 1200 V | 30A | 1.8 V @ 30 A | No Recovery Time > 500mA (Io) | 0 ns | 600 µA @ 1200 V | - | Chassis Mount | |
|
|
APT2X31DC60JDIODE MODULE 600V 30A SOT227 |
2,913 | 0.00 |
RFQ |
Bulk | - | Active | 2 Independent | Silicon Carbide Schottky | 600 V | 30A | 1.8 V @ 30 A | No Recovery Time > 500mA (Io) | 0 ns | 600 µA @ 600 V | - | Chassis Mount |
