| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BAS70-07WSCHOTTKY DIODE - HIGH SPEED SWIT |
3,269 | 0.03 |
RFQ |
Datasheet |
Bulk | - | Active | 2 Independent | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C | Surface Mount |
|
BAT64-04E6433RECTIFIER DIODE, SCHOTTKY, 2 ELE |
2,067 | 0.07 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Series Connection | Schottky | 40 V | 120mA | 750 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 30 V | 150°C | Surface Mount |
|
BAS70-06E6327BAS70 - HIGH SPEED SWITCHING, CL |
3,993 | 0.08 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Anode | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C | Surface Mount |
|
|
BAS70-05E6433SCHOTTKY DIODE - HIGH SPEED SWIT |
3,708 | 0.08 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C | Surface Mount |
|
BAS40-05WBAS40 - HIGH SPEED SWITCHING, CL |
2,659 | 0.08 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 1 µA @ 30 V | 150°C | Surface Mount |
|
|
BAS40-06E6327BAS40 - HIGH SPEED SWITCHING, CL |
2,296 | 0.08 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Anode | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 1 µA @ 30 V | 150°C | Surface Mount |
|
|
BAS70-06E6433SCHOTTKY DIODE - HIGH SPEED SWIT |
3,501 | 0.08 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Anode | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C | Surface Mount |
|
BAW101E6433BAW101 - HIGH VOLTAGE DOUBLE DIO |
2,915 | 0.10 |
RFQ |
Datasheet |
Bulk | - | Active | 2 Independent | Standard | 300 V | 250mA (DC) | 1.3 V @ 100 mA | Standard Recovery >500ns, > 200mA (Io) | 1 µs | 150 nA @ 250 V | 150°C | Surface Mount |
|
|
BAS40-07E6327BAS40 - HIGH SPEED SWITCHING, CL |
3,054 | 0.11 |
RFQ |
Datasheet |
Bulk | - | Active | 2 Independent | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 1 µA @ 30 V | 150°C | Surface Mount |
|
|
BAS70-07E6433SCHOTTKY DIODE - HIGH SPEED SWIT |
2,589 | 0.11 |
RFQ |
Datasheet |
Bulk | - | Active | 2 Independent | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C | Surface Mount |
|
BAS7004WH6327XTSA1DIODE ARRAY SCHOTTKY 70V SOT323 |
3,740 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C (Max) | Surface Mount |
|
BAS7005E6327HTSA1DIODE ARRAY SCHOTTKY 70V SOT23 |
2,534 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C (Max) | Surface Mount |
|
BAS28E6327HTSA1DIODE ARRAY GP 80V 200MA SOT143 |
2,283 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Not For New Designs | 2 Independent | Standard | 80 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 75 V | 150°C (Max) | Surface Mount |
|
|
BAT6405WH6327XTSA1DIODE ARRAY SCHOTTKY 40V SOT323 |
2,075 | 0.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, BAT64 | Active | 1 Pair Common Cathode | Schottky | 40 V | 120mA | 750 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 30 V | 150°C (Max) | Surface Mount |
|
|
BAS4007E6327HTSA1DIODE ARRAY SCHOTTKY 40V SOT143 |
3,902 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 Independent | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 1 µA @ 30 V | 150°C (Max) | Surface Mount |
|
|
BAS12504WH6327XTSA1DIODE ARRAY SCHOTTKY 25V SOT323 |
3,948 | 0.77 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Schottky | 25 V | 100mA (DC) | 950 mV @ 35 mA | Small Signal =< 200mA (Io), Any Speed | - | 150 nA @ 25 V | 150°C (Max) | Surface Mount |
|
DD350N12K-KRECTIFIER DIODE MODULE |
222 | 150.33 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Series Connection | Standard | 1200 V | 350A | 1.28 V @ 1000 A | Standard Recovery >500ns, > 200mA (Io) | - | 30 mA @ 1200 V | 150°C | Chassis Mount |
|
DD600N16KHPSA3DIODE MODULE GP 1600V 600A |
3,307 | 319.46 |
RFQ |
Datasheet |
Tray | - | Active | 1 Pair Series Connection | Standard | 1600 V | 600A | 1.32 V @ 1800 A | Standard Recovery >500ns, > 200mA (Io) | - | 40 mA @ 1600 V | -40°C ~ 150°C | Chassis Mount |
|
IDP20C65D2XKSA1DIODE 650V 20A RAPID2 TO220-3 |
3,782 | 1.77 |
RFQ |
Datasheet |
Tube | Rapid 2 | Active | 1 Pair Common Cathode | Standard | 650 V | 10A | 2.2 V @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | 28 ns | 40 µA @ 650 V | -40°C ~ 175°C | Through Hole |
|
DD170N16SHPSA1BRIDGE RECT 1P 1.6KV 165A PB34SB |
3,328 | 55.46 |
RFQ |
Datasheet |
Tray | - | Active | 1 Pair Series Connection | Standard | 1600 V | 165A | - | - | - | 9 mA @ 1600 V | 135°C (Max) | Chassis Mount |
