| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Technology | Type | IsolatedPower | NumberofChannels | Inputs-Side1/Side2 | ChannelType | Voltage-Isolation | CommonModeTransientImmunity(Min) | DataRate | PropagationDelaytpLH/tpHL(Max) | PulseWidthDistortion(Max) | Rise/FallTime(Typ) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ADM2687EBRIZDGTL ISO 5KV RS422/RS485 16SOIC |
2,317 | 18.39 |
RFQ |
Datasheet |
Tube | isoPower® | Active | Magnetic Coupling | RS422, RS485 | Yes | 3 | 2/1 | Unidirectional | 5000Vrms | 25kV/µs | 500kbps | 700ns, 700ns | - | 1.1µs, 1.1µs (Max) | 3.3V, 5V | -40°C ~ 85°C | Surface Mount |
|
ADUM5402WCRWZ-1DGTL ISO 2500VRMS 4CH GP 16SOIC |
3,454 | 19.28 |
RFQ |
Datasheet |
Tube | Automotive | Active | Magnetic Coupling | General Purpose | Yes | 4 | 2/2 | Unidirectional | 2500Vrms | 25kV/µs | 25Mbps | 60ns, 60ns | 6ns | 2.5ns, 2.5ns | 3V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
|
ADM2682EBRIZDGTL ISO 5KV RS422/RS485 16SOIC |
2,315 | 21.15 |
RFQ |
Datasheet |
Tube | isoPower® | Active | Magnetic Coupling | RS422, RS485 | Yes | 3 | 2/1 | Unidirectional | 5000Vrms | 25kV/µs | 16Mbps | 100ns, 100ns | - | 15ns, 15ns (Max) | 3.3V, 5V | -40°C ~ 85°C | Surface Mount |
|
LTM2881CY-3#PBFDGTL ISO 2.5KV RS422/RS485 32BGA |
3,415 | 22.15 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 3V ~ 3.6V | 0°C ~ 70°C | Surface Mount |
|
LTM2881IV-3#PBFDGTL ISO 2.5KV RS422/RS485 32LGA |
2,994 | 24.02 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 3V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
|
LTM2882IY-5#PBFDGT ISO 2500VRMS 4CH RS232 32BGA |
2,722 | 24.02 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS232 | Yes | 4 | 2/2 | Unidirectional | 2500Vrms | 30kV/µs | 10Mbps | 100ns, 100ns | - | 60ns, 60ns | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
LTM2882IY-3#PBFDGT ISO 2500VRMS 4CH RS232 32BGA |
2,631 | 24.02 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS232 | Yes | 4 | 2/2 | Unidirectional | 2500Vrms | 30kV/µs | 10Mbps | 100ns, 100ns | - | 60ns, 60ns | 3V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
|
LTM2881IY-3#PBFDGTL ISO 2.5KV RS422/RS485 32BGA |
2,988 | 24.02 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 3V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
|
LTM2883CY-5S#PBFDGTL ISOL 2500VRMS 6CH SPI 32BGA |
3,048 | 28.78 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | SPI | Yes | 6 | 3/3 | Unidirectional | 2500Vrms | 30kV/µs | 4MHz, 8MHz | 100ns, 100ns | - | 3ns, 3ns | 4.5V ~ 5.5V | 0°C ~ 70°C | Surface Mount |
|
|
LTM2881HY-3#PBFDGTL ISO 2.5KV RS422/RS485 32BGA |
2,275 | 28.83 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 3V ~ 3.6V | -40°C ~ 105°C | Surface Mount |
|
|
LTM2881HY-5#PBFDGTL ISO 2.5KV RS422/RS485 32BGA |
2,230 | 28.83 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 4.5V ~ 5.5V | -40°C ~ 105°C | Surface Mount |
|
LTM2894CY#PBFDGTL ISOL 7500VRMS 2CH USB 24BGA |
2,328 | 29.38 |
RFQ |
Datasheet |
Tray | - | Active | Magnetic Coupling | USB | No | 1 | 1/1 | Bidirectional | 7500Vrms | 50kV/µs | 12Mbps | 115ns, 115ns | - | 20ns, 20ns (Max) | 4.4V ~ 36V | 0°C ~ 70°C | Surface Mount |
|
|
LTM2883IY-5S#PBFDGTL ISOL 2500VRMS 6CH SPI 32BGA |
2,947 | 31.67 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | SPI | Yes | 6 | 3/3 | Unidirectional | 2500Vrms | 30kV/µs | 4MHz, 8MHz | 100ns, 100ns | - | 3ns, 3ns | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
LTM2885IY#PBFDGTL ISO 6.5KV RS422/RS485 42BGA |
2,629 | 34.04 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 6500Vrms | 50kV/µs | 20Mbps | - | - | 4ns, 4ns | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
LTM2884CY#PBFDGTL ISOL 2500VRMS 1CH USB 44BGA |
3,750 | 38.69 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | USB | Yes | 1 | 1/1 | Bidirectional | 2500Vrms | 30kV/µs | 12Mbps | 115ns, 115ns | - | 20ns, 20ns (Max) | 4.4V ~ 16.5V | 0°C ~ 70°C | Surface Mount |
|
ADN4624BRNZQUAD 2.5GBPS 4+0 LVDS ISOLATOR |
3,912 | 40.21 |
RFQ |
Datasheet |
Tube | - | Active | Magnetic Coupling | LVDS | No | 4 | 4/0 | Unidirectional | 5700Vrms | 40kV/µs | 2.5Gbps | 2.8ns, 2.8ns | - | 180ns, 180ns (Max) | 1.7V ~ 1.9V | -40°C ~ 125°C | Surface Mount |
|
|
LTM2884IY#PBFDGTL ISOL 2500VRMS 1CH USB 44BGA |
2,311 | 42.65 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | USB | Yes | 1 | 1/1 | Bidirectional | 2500Vrms | 30kV/µs | 12Mbps | 115ns, 115ns | - | 20ns, 20ns (Max) | 4.4V ~ 16.5V | -40°C ~ 85°C | Surface Mount |
|
|
LTM2881MPY-3#PBFDGTL ISO 2.5KV RS422/RS485 32BGA |
3,818 | 47.19 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | RS422, RS485 | Yes | 2 | 1/1 | Unidirectional | 2500Vrms | 30kV/µs | 20Mbps | - | - | - | 3V ~ 3.6V | -55°C ~ 105°C | Surface Mount |
|
|
LTM2884HY#PBFDGTL ISOL 2500VRMS 1CH USB 44BGA |
2,155 | 51.13 |
RFQ |
Datasheet |
Tray | µModule® | Active | Magnetic Coupling | USB | Yes | 1 | 1/1 | Bidirectional | 2500Vrms | 30kV/µs | 12Mbps | 115ns, 115ns | - | 20ns, 20ns (Max) | 4.4V ~ 16.5V | -40°C ~ 105°C | Surface Mount |
|
ADUM121N0BRZ-RL7DGTL ISO 3000VRMS 2CH GP 8SOIC |
3,689 | 2.81 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | iCoupler® | Active | Magnetic Coupling | General Purpose | No | 2 | 1/1 | Unidirectional | 3000Vrms | 75kV/µs | 150Mbps | 13ns, 13ns | 3ns | 2.5ns, 2.5ns | 1.7V ~ 5.5V | -40°C ~ 125°C | Surface Mount |
