| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | NumberofOutputs | Voltage-Input(Min) | Voltage-Input(Max) | Voltage-Output1 | Voltage-Output2 | Voltage-Output3 | Voltage-Output4 | Current-Output(Max) | Power(Watts) | Voltage-Isolation | Applications | Features | OperatingTemperature | Efficiency | MountingType | Size/Dimension | ControlFeatures | ApprovalAgency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AM1DS-1205D-NZDC DC CONVERTER +/-5V 1W |
3,145 | 2.88 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 2 | 10.8V | 13.2V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
AM1DS-1215D-NZDC DC CONVERTER +/-15V 1W |
2,039 | 2.88 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 2 | 10.8V | 13.2V | -15 ~ 15V | -15V | - | - | 34mA, 34mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.38 H (19.5mm x 6.0mm x 9.6mm) | ||
|
AM1/4SS-0503S-NZDC DC CONVERTER 3.3V 251MW |
2,759 | 2.88 |
RFQ |
Datasheet |
4-SIP Module | Tube | AM1/4SS-NZ (0.25W) | Active | Isolated Module | 1 | 4.5V | 5.5V | 3.3V | - | - | - | 76mA | 251 mW | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 74% | Through Hole | 0.46 L x 0.24 W x 0.40 H (11.6mm x 6.0mm x 10.2mm) | ||
|
|
AM1DS-1515D-NZDC DC CONVERTER +/-15V 1W |
3,678 | 2.88 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 2 | 13.5V | 16.5V | -15 ~ 15V | -15V | - | - | 34mA, 34mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.38 H (19.5mm x 6.0mm x 9.6mm) | ||
|
|
AM1DS-1512D-NZDC DC CONVERTER +/-12V 1W |
2,112 | 2.88 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 2 | 13.5V | 16.5V | -12 ~ 12V | -12V | - | - | 42mA, 42mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.38 H (19.5mm x 6.0mm x 9.6mm) | ||
|
AM1LS-0505DH30-NZDC DC CONVERTER +/-5V 1W |
2,479 | 5.81 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tube | AM1LS-N(J)Z (1W) | Active | Isolated Module | 2 | 4.5V | 5.5V | 5V | -5V | - | - | 100mA, 100mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 82% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.5mm x 7.3mm) | ||
|
|
AM1LS-2405S-NZDC DC CONVERTER 5V 1W |
2,770 | 6.21 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tube | AM1LS-N(J)Z (1W) | Active | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 80% | Surface Mount | 0.50 L x 0.33 W x 0.29 H (12.7mm x 8.3mm x 7.3mm) | ||
|
AM1DS-1215S-NZDC DC CONVERTER 15V 1W |
2,222 | 2.91 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.38 H (19.5mm x 6.0mm x 9.6mm) | ||
|
|
AM1DS-0509S-NZDC DC CONVERTER 9V 1W |
3,528 | 2.91 |
RFQ |
6-SIP Module, 4 Leads | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | |||
|
AM1PS-2403S-NZDC DC CONVERTER 3.3V 1W |
3,304 | 2.91 |
RFQ |
Datasheet |
8-DIP Module | Tube | AM1PS-NZ (1W) | Active | Isolated Module | 1 | 21.6V | 26.4V | 3.3V | - | - | - | 303mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 76% | Through Hole | 0.50 L x 0.39 W x 0.32 H (12.7mm x 10.0mm x 8.2mm) | ||
|
|
AM1DS-1205S-NZDC DC CONVERTER 5V 1W |
3,937 | 2.91 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
AM1D-0515D-NZDC DC CONVERTER +/-15V 1.1W |
3,773 | 2.91 |
RFQ |
Datasheet |
7-SIP Module, 5 Leads | Tube | AM1D-NZ (1W) | Active | Isolated Module | 2 | 4.5V | 5.5V | 15V | -15V | - | - | 35mA, 35mA | 1.1 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 80% | Through Hole | 0.77 L x 0.24 W x 0.39 H (19.5mm x 6.0mm x 10.0mm) | ||
|
|
AM1D-0505D-NZDC DC CONVERTER +/-5V 1W |
3,053 | 2.91 |
RFQ |
Datasheet |
7-SIP Module, 5 Leads | Tube | AM1D-NZ (1W) | Active | Isolated Module | 2 | 4.5V | 5.5V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.39 H (19.5mm x 6.0mm x 10.0mm) | ||
|
|
AM1PS-1212S-NZDC DC CONVERTER 12V 1W |
3,946 | 2.93 |
RFQ |
Datasheet |
8-DIP Module | Tube | AM1PS-NZ (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 83mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 81% | Through Hole | 0.50 L x 0.39 W x 0.32 H (12.7mm x 10.0mm x 8.2mm) | ||
|
|
AM1PS-1215S-NZDC DC CONVERTER 15V 1W |
2,570 | 2.93 |
RFQ |
Datasheet |
8-DIP Module | Tube | AM1PS-NZ (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.50 L x 0.39 W x 0.32 H (12.7mm x 10.0mm x 8.2mm) | ||
|
|
AM1DS-1212S-NZDC DC CONVERTER 12V 1W |
2,283 | 2.96 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 84mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
|
AM1DS-2405S-NZDC DC CONVERTER 5V 1W |
3,694 | 2.96 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 21.6V | 26.4V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
|
AM1DS-2415S-NZDC DC CONVERTER 15V 1W |
2,434 | 2.96 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 21.6V | 26.4V | 15V | - | - | - | 67mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
|
AM1DS-2412S-NZDC DC CONVERTER 12V 1W |
3,088 | 2.96 |
RFQ |
Datasheet |
7-SIP Module | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 21.6V | 26.4V | 12V | - | - | - | 84mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) | ||
|
|
AM1DS-0524S-NZDC DC CONVERTER 24V 1W |
2,137 | 2.96 |
RFQ |
6-SIP Module, 4 Leads | Tube | AM1DS-NZ (1W) | Active | Isolated Module | 1 | 4.5V | 5.5V | 24V | - | - | - | 42mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 81% | Through Hole | 0.77 L x 0.24 W x 0.37 H (19.5mm x 6.0mm x 9.4mm) |
