| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | NumberofOutputs | Voltage-Input(Min) | Voltage-Input(Max) | Voltage-Output1 | Voltage-Output2 | Voltage-Output3 | Voltage-Output4 | Current-Output(Max) | Power(Watts) | Voltage-Isolation | Applications | Features | OperatingTemperature | Efficiency | MountingType | Size/Dimension | ControlFeatures | ApprovalAgency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PES1-S15-S15-M-TRDC DC CONVERTER 15V 1W |
204 | 9.06 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR),Cut Tape (CT),Bulk | PES1-M (1W) | Active | Isolated Module | 1 | 13.5V | 16.5V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 81% | Surface Mount | 0.50 L x 0.33 W x 0.29 H (12.7mm x 8.3mm x 7.3mm) | ||
|
PESE2-S12-S15-M-TRDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
3,195 | 5.42 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 133mA | 1.995 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 84% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S12-M-TRDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,831 | 5.42 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 167mA | 2.004 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 84% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S9-M-TRDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,571 | 5.42 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 9V | - | - | - | 222mA | 1.998 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S24-M-TRDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,360 | 5.42 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 24V | - | - | - | 83mA | 1.992 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 85% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S5-M-TRDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,086 | 5.42 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 400mA | 2 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S15-S15-M-TRDC-DC 3KV ISOLATED, 2 W, 13.5~16 |
3,351 | 5.44 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 13.5V | 16.5V | 15V | - | - | - | 133mA | 1.995 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 84% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S15-S5-M-TRDC-DC 3KV ISOLATED, 2 W, 13.5~16 |
2,497 | 5.44 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR) | PESE2-M (2W) | Active | Isolated Module | 1 | 13.5V | 16.5V | 5V | - | - | - | 400mA | 2 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
.jpg)
|
PDS1-S12-D5-MDC DC CONVERTER +/-5V 1W |
2,433 | 5.44 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tube | PDS1-M (1W) | Active | Isolated Module | 2 | 10.8V | 13.2V | 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 80% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) | ||
|
PCN2-S5-S15-SDC DC CONVERTER 15V 2W |
3,993 | 4.90 |
RFQ |
Datasheet |
6-SIP Module, 4 Leads | Bulk | PCN2-S (2W) | Not For New Designs | Isolated Module | 1 | 4.5V | 5.5V | 15V | - | - | - | 134mA | 2 W | 1 kV | ITE (Commercial) | SCP | -40°C ~ 100°C | 85% | Through Hole | 0.77 L x 0.28 W x 0.40 H (19.6mm x 7.2mm x 10.2mm) | ||
|
PHP1-S12-S5-M-TRDC DC CONVERTER 5V 1W |
3,543 | 5.67 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR),Cut Tape (CT),Bulk | PHP1-M (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 200mA | 1 W | 2 kV | ITE (Commercial) | - | -40°C ~ 100°C | 73% | Surface Mount | 0.50 L x 0.42 W x 0.26 H (12.8mm x 10.7mm x 6.7mm) | ||
|
|
PHP1-S15-S5-M-TRDC DC CONVERTER 5V 1W |
971 | 5.66 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR),Cut Tape (CT),Bulk | PHP1-M (1W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 5V | - | - | - | 200mA | 1 W | 2 kV | ITE (Commercial) | - | -40°C ~ 100°C | 73% | Surface Mount | 0.50 L x 0.42 W x 0.26 H (12.8mm x 10.7mm x 6.7mm) | ||
|
|
PDS1-S5-D24-MDC DC CONVERTER +/-24V 1W |
2,487 | 5.66 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tube | PDS1-M (1W) | Active | Isolated Module | 2 | 4.5V | 5.5V | 24V | -24V | - | - | 21mA, 21mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 81% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) | ||
|
VIBLSD1-S24-S24-DIPDC DC CONVERTER 24V 1W |
3,804 | 5.72 |
RFQ |
Datasheet |
14-DIP Module, 5 Leads | Tube | VIBLSD1-DIP (1W) | Not For New Designs | Isolated Module | 1 | 22.8V | 25.2V | 24V | - | - | - | 42mA | 1 W | 1 kV | ITE (Commercial) | SCP | -40°C ~ 85°C | 68% | Through Hole | 0.79 L x 0.39 W x 0.28 H (20.1mm x 9.9mm x 7.2mm) | ||
Gull Wing12.7mm.jpg)
|
PQM1-S24-S15-M-TRDC DC CONVERTER 15V 1W |
3,045 | 6.25 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tape & Reel (TR) | PQM1-M (1W) | Not For New Designs | Isolated Module | 1 | 22.8V | 25.2V | 15V | - | - | - | 67mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 85°C (With Derating) | 74% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) | ||
|
|
PQM1-S24-S5-M-TRDC DC CONVERTER 5V 1W |
3,549 | 6.25 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tape & Reel (TR) | PQM1-M (1W) | Not For New Designs | Isolated Module | 1 | 22.8V | 25.2V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 85°C (With Derating) | 73% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) | ||
|
|
PQM1-S24-S9-M-TRDC DC CONVERTER 9V 1W |
2,610 | 6.25 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tape & Reel (TR) | PQM1-M (1W) | Not For New Designs | Isolated Module | 1 | 22.8V | 25.2V | 9V | - | - | - | 111mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 85°C (With Derating) | 74% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) | ||
|
PCN1-S12-D15-SDC DC CONVERTER +/-15V 1W |
2,044 | 5.81 |
RFQ |
Datasheet |
6-SIP Module, 5 Leads | Tube | PCN1-S (1W) | Not For New Designs | Isolated Module | 2 | 10.8V | 13.2V | 15V | -15V | - | - | 33mA, 33mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 100°C | 81% | Through Hole | 0.77 L x 0.28 W x 0.40 H (19.5mm x 7.2mm x 10.2mm) | ||
|
|
PES1-S5-S3-M-TRDC DC CONVERTER 3.3V 1W |
3,806 | 9.53 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tape & Reel (TR),Cut Tape (CT),Bulk | PES1-M (1W) | Active | Isolated Module | 1 | 4.5V | 5.5V | 3.3V | - | - | - | 303mA | 1 W | 3 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 76% | Surface Mount | 0.50 L x 0.33 W x 0.29 H (12.7mm x 8.3mm x 7.3mm) | ||
|
|
PQM1-S12-S12-M-TRDC DC CONVERTER 12V 1W |
3,125 | 6.25 |
RFQ |
Datasheet |
10-SMD Module, 6 Leads | Tape & Reel (TR) | PQM1-M (1W) | Not For New Designs | Isolated Module | 1 | 11.4V | 12.6V | 12V | - | - | - | 84mA | 1 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 85°C (With Derating) | 73% | Surface Mount | 0.60 L x 0.33 W x 0.29 H (15.2mm x 8.3mm x 7.3mm) |
