| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Style | 1stConnector | 1stContactGender | 1stConnectorMountingType | 1stConnectorMountingFeature | 2ndConnector | 2ndContactGender | 2ndConnectorMountingType | 2ndConnectorMountingFeature | Length | CableType | CableImpedance | ConnectorImpedance | OverallImpedance | Frequency-Max | Color | Features | OperatingTemperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
21-20-M1.5CBL ASSY TRB PLUG 1.5M |
2,414 | 170.88 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 59.1 (1.5m) 4.9' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-20-M5.0CBL ASSY TRB PLUG 5M |
3,376 | 173.35 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 196.9 (5.0m) 16.4' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M1.5CBL ASSY TRB PLUG 1.5M |
3,640 | 174.92 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 59.1 (1.5m) 4.9' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M1.0CBL ASSY TRB PLUG 1M |
2,251 | 184.95 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 39.4 (1.0m) 3.3' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M2.5CBL ASSY TRB PLUG 2.5M |
3,442 | 201.65 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 98.4 (2.5m) 8.2' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M3.0CBL ASSY TRB PLUG 3M |
3,452 | 208.33 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 118.1 (3.0m) 9.8' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M3.5CBL ASSY TRB PLUG 11.5' |
2,993 | 210.01 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 137.8 (3.5m) 11.5' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M4.0CBL ASSY TRB PLUG 4M |
2,638 | 211.68 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 157.5 (4.0m) 13.1' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M4.5CBL ASSY TRB PLUG 4.5M |
2,209 | 213.34 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 177.2 (4.5m) 14.8' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-M5.0CBL ASSY TRB PLUG 5M |
2,964 | 215.01 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 196.9 (5.0m) 16.4' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-14-24CABLE ASSEMBLY TRB - TRB 24 |
3,092 | 181.60 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 24.00 (609.60mm) | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-17-24CABLE ASSEMBLY TRS - TRS 24 |
2,149 | 163.99 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRS to TRS | TRS Plug | Male | Free Hanging (In-Line) | - | TRS Plug | Male | Free Hanging (In-Line) | - | 24.00 (609.60mm) | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
|
21-17-72CABLE ASSEMBLY TRS - TRS 72 |
2,505 | 170.88 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRS to TRS | TRS Plug | Male | Free Hanging (In-Line) | - | TRS Plug | Male | Free Hanging (In-Line) | - | 72.0 (1.8m) 6.0' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-20-M3.0CBL ASSY TRB PLUG 3M |
2,990 | 156.86 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 118.1 (3.0m) 9.8' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
21-21-M3.5CBL ASSY TRB PLUG 11.5' |
3,364 | 159.98 |
RFQ |
Datasheet |
Bulk | MIL-STD-1553B | Active | TRB to TRB | TRB Plug | Male | Free Hanging (In-Line) | - | TRB Plug | Male | Free Hanging (In-Line) | - | 137.8 (3.5m) 11.5' | Twinaxial | - | - | 78 Ohms | 500 GHz | Blue | Shielded | - |
|
PCYC-12-50CONNECTOR PATCH |
2,012 | 45.64 |
RFQ |
Bulk | - | Active | BNC to BNC | BNC Plug | Male | - | - | BNC Plug | Male | - | - | 12.00 (304.80mm) | RG-58 | 50 Ohms | - | 50 Ohms | - | Green | - | - | |
|
|
PCYC-24-50CONNECTOR PATCH |
2,785 | 46.21 |
RFQ |
Bulk | - | Active | BNC to BNC | BNC Plug | Male | - | - | BNC Plug | Male | - | - | 24.00 (609.60mm) | RG-58 | 50 Ohms | - | 50 Ohms | - | Green | - | - | |
|
|
PCYC-36-50CONNECTOR PATCH |
3,032 | 46.74 |
RFQ |
Bulk | - | Active | BNC to BNC | BNC Plug | Male | - | - | BNC Plug | Male | - | - | 36.00 (914.40mm) | RG-58 | 50 Ohms | - | 50 Ohms | - | Green | - | - | |
|
|
PCYC-60-50CONNECTOR PATCH |
3,873 | 47.30 |
RFQ |
Bulk | - | Active | BNC to BNC | BNC Plug | Male | - | - | BNC Plug | Male | - | - | 60.0 (1.5m) 5.0' | RG-58 | 50 Ohms | - | 50 Ohms | - | Green | - | - | |
|
|
PCY-12-50CONNECTOR PATCH |
3,143 | 76.18 |
RFQ |
Bulk | - | Active | BNC to BNC | BNC Plug | Male | - | - | BNC Plug | Male | - | - | 12.00 (304.80mm) | RG-58 | 50 Ohms | - | 50 Ohms | - | Green | - | - |
