Aluminum Electrolytic Capacitors(115368)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
400CXW82MEFR14.5X31.5CAP ALUM 82UF 20% 400V RADIAL |
2,136 | 0.00 |
RFQ |
Datasheet |
Bulk | CXW | Active | 82 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 570 mA @ 120 Hz | 855 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.571 Dia (14.50mm) | 1.319 (33.50mm) | - | Through Hole |
|
350TXW47MEFR10X35CAP ALUM 47UF 20% 350V RADIAL |
2,035 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 47 µF | ±20% | 350 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 410 mA @ 120 Hz | 615 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
25YXM100MEFRTA6.3X11CAP ALUM 100UF 20% 25V RADIAL |
3,766 | 0.00 |
RFQ |
Datasheet |
Tape & Box (TB) | YXM | Active | 100 µF | ±20% | 25 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 147 mA @ 120 Hz | 210 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
250TXW47MEFR8X35CAP ALUM 47UF 20% 250V RADIAL TH |
2,724 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 47 µF | ±20% | 250 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 450 mA @ 120 Hz | 630 mA @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
|
400CXW270MEFR18X50CAP ALUM 270UF 20% 400V RADIAL |
2,324 | 0.00 |
RFQ |
Datasheet |
Bulk | CXW | Active | 270 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
400QXW68MEFR12.5X35CAP ALUM 68UF 20% 400V RADIAL |
3,448 | 0.00 |
RFQ |
Datasheet |
Bulk | QXW | Active | 68 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 540 mA @ 120 Hz | 810 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.457 (37.00mm) | - | Through Hole |
|
450QXW47MEFR12.5X30CAP ALUM 47UF 20% 450V RADIAL |
2,269 | 0.00 |
RFQ |
Datasheet |
Bulk | QXW | Active | 47 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 430 mA @ 120 Hz | 645 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
100YXM1MEFR5X11CAP ALUM 1UF 20% 100V RADIAL |
3,001 | 0.00 |
RFQ |
Datasheet |
Bulk | YXM | Active | 1 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 16.8 mA @ 120 Hz | 40 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
160TXW180MEFR12.5X30CAP ALUM 180UF 20% 160V RADIAL |
2,196 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 180 µF | ±20% | 160 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 770 mA @ 120 Hz | 1.07 A @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.280 (32.50mm) | - | Through Hole |
|
420BXW56MEFR12.5X35CAP ALUM 56UF 20% 420V RADIAL |
3,976 | 0.00 |
RFQ |
Datasheet |
Bulk | BXW | Active | 56 µF | ±20% | 420 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 510 mA @ 120 Hz | 1.275 A @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.457 (37.00mm) | - | Through Hole |
|
|
220TXW390MEFR18X40CAP ALUM 390UF 20% 220V RAD TH |
3,294 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 390 µF | ±20% | 220 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.49 A @ 120 Hz | 2.08 A @ 100 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.673 (42.50mm) | - | Through Hole |
|
|
400CXW100MEFR14.5X40CAP ALUM 100UF 20% 400V RADIAL |
2,543 | 0.00 |
RFQ |
Datasheet |
Bulk | CXW | Active | 100 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 690 mA @ 120 Hz | 1.035 A @ 10 kHz | - | 0.295 (7.50mm) | 0.571 Dia (14.50mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
400CXW120MEFR14.5X45CAP ALUM 120UF 20% 400V RADIAL |
2,833 | 0.00 |
RFQ |
Datasheet |
Bulk | CXW | Active | 120 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 790 mA @ 120 Hz | 1.185 A @ 10 kHz | - | 0.295 (7.50mm) | 0.571 Dia (14.50mm) | 1.850 (47.00mm) | - | Through Hole |
|
|
400TXW22MEFR10X30CAP ALUM 22UF 20% 400V RADIAL TH |
2,535 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 22 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 1.280 (32.50mm) | - | Through Hole |
|
160TXW560MEFR16X50CAP ALUM 560UF 20% 160V RADIAL |
2,177 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 560 µF | ±20% | 160 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.79 A @ 120 Hz | 2.5 A @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 2.067 (52.50mm) | - | Through Hole |
|
|
450TXW22MEFR10X35CAP ALUM 22UF 20% 450V RADIAL TH |
3,280 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 22 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
|
100YXM18MEFR6.3X11CAP ALUM 10UF 20% 100V RADIAL |
3,869 | 0.00 |
RFQ |
Datasheet |
Bulk | YXM | Active | 10 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 63 mA @ 120 Hz | 150 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
400TXW56MEFR12.5X35CAP ALUM 56UF 20% 400V RADIAL |
3,505 | 0.00 |
RFQ |
Datasheet |
Bulk | TXW | Active | 56 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 750 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.476 (37.50mm) | - | Through Hole |
|
|
420CXW68MEFR12.5X40CAP ALUM 68UF 20% 420V RADIAL |
3,920 | 0.00 |
RFQ |
Datasheet |
Bulk | CXW | Active | 68 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 520 mA @ 120 Hz | 780 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.654 (42.00mm) | - | Through Hole |
|
450BXW65MEFR14.5X30CAP ALUM 65UF 20% 450V RADIAL |
3,083 | 0.00 |
RFQ |
Datasheet |
Bulk | BXW | Active | 65 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.295 (7.50mm) | 0.571 Dia (14.50mm) | 1.260 (32.00mm) | - | Through Hole |
